- Page 1 Operation manual Daikin room air conditioner CTXM15A2V1B CTXM15A5V1B FTXM20A2V1B FTXM20A5V1B FTXM25A2V1B FTXM25A5V1B FTXM35A2V1B FTXM35A5V1B FTXM42A2V1B FTXM42A5V1B Operation manual FTXM50A2V1B English Daikin room air conditioner FTXM50A5V1B...
-
Page 2: Table Of Contents
To mount the wireless remote control holder ......INFORMATION To set the clock ................. To set the brightness of the Daikin eye ........This appliance is intended to be used by expert or trained To turn on the power supply............ -
Page 3: Instructions For Safe Operation
Always have qualified service personnel confirm that the point of leakage has been repaired or corrected before resuming operation. CTXM-A, FTXM-A Operation manual Daikin room air conditioner 3P728539-3 – 2023.06... - Page 4 Splashed detergent on electric components, such as motors, may WARNING cause failure, smoke or ignition. ▪ Do NOT pierce or burn refrigerant cycle parts. Operation manual CTXM-A, FTXM-A Daikin room air conditioner 3P728539-3 – 2023.06...
-
Page 5: About The System
10 seconds, it returns to the colour of the operation cause injury. mode for 3 minutes. Example: When the timer is set during cooling operation, the Daikin eye will periodically light orange for INFORMATION 10 seconds, and then switch to blue for 3 minutes. -
Page 6: Components: Wireless Remote Control
To insert the batteries Note: Holding down increases or decreases the time setting rapidly. The batteries will last for about 1 year. 5 Press 1 Remove the front cover. Operation manual CTXM-A, FTXM-A Daikin room air conditioner 3P728539-3 – 2023.06... -
Page 7: To Set The Brightness Of The Daikin Eye
Result: Setting is complete. blinks. Cooling and Heating (a)(b) drying Outdoor temperature –10~50°C DB –20~24°C DB –21~18°C WB To set the brightness of the Daikin Indoor temperature 18~32°C DB 10~30°C DB 14~23°C WB Indoor humidity ≤80% — 1 Keep pressed for at least 2 seconds every time you need to A safety device might stop the operation of the system if the unit change the setting. -
Page 8: To Start/Stop Operation Mode And To Set The Temperature
When. Adjust the airflow direction as desired. What. The system directs the airflow differently, depending on the user selection (swinging or fixed position). It does so by moving horizontal blades (flaps) or vertical blades (louvers). Operation manual CTXM-A, FTXM-A Daikin room air conditioner 3P728539-3 – 2023.06... -
Page 9: Comfort Airflow And Intelligent Eye Operation
Note: If there are people close to the front of the indoor unit or there are too many people, use both operations at the same time. CTXM-A, FTXM-A Operation manual Daikin room air conditioner 3P728539-3 – 2023.06... -
Page 10: To Start/Stop Econo And Outdoor Unit Quiet Operation
Result: The set time and disappear from the LCD. and the day of the week are displayed on the LCD. The Daikin eye stops ▪ If the airflow becomes weak, the Streamer discharge lighting orange. may stop temporarily to prevent ozone smell. -
Page 11: Hour Countdown Off/On Timer Setting
LCD. and the time) day of the week are displayed on the LCD. The Daikin eye stops lighting orange. Note: If the timer setting is active, the current time is NOT displayed To combine OFF timer and ON timer on the LCD. -
Page 12: To Set Weekly Timer Operation
30°C, even if is set to 31~32°C. 9 Press Result: The temperature and time are set for the ON timer. The time is set for the OFF timer. The Daikin eye lights orange. Operation manual CTXM-A, FTXM-A Daikin room air conditioner 3P728539-3 –... -
Page 13: To Deactivate And Reactivate Weekly Timer Operation
1 To deactivate the Weekly timer, press while is displayed on the LCD. Result: disappears from the LCD and the Daikin eye stops The customer is responsible for providing: lighting orange. ▪ Smartphone or tablet with minimum supported version of Android 2 To reactivate the Weekly timer, press again. - Page 14 4 Open the ONECTA application on your smart device and follow the steps on the screen. ▪ via the WPS button on the Result: If the connection was successful, the Daikin eye colour router. alternates between blue and partly green.
-
Page 15: Energy Saving And Optimum Operation
3 Hold for at least 2 seconds to confirm the selection. Overview: Maintenance and Result: is blinking. The Daikin eye colour alternates between service red and partly green. The setting is reset to the factory default. 4 Press to exit the menu. -
Page 16: To Clean The Indoor Unit And Wireless Remote Control
Before cleaning, be sure to stop the operation, turn the 2 Pull out the air filters. breaker OFF or pull out the supply cord. Otherwise, an electrical shock and injury may result. Operation manual CTXM-A, FTXM-A Daikin room air conditioner 3P728539-3 – 2023.06... -
Page 17: To Clean The Titanium Apatite Deodorising Filter And The Silver Particle Filter (Ag-Ion Filter)
INFORMATION Clean the filter with water every 6 months. 1 Remove the titanium apatite deodorising filter and the silver allergen removal air purifying filter from all 4 claws. CTXM-A, FTXM-A Operation manual Daikin room air conditioner 3P728539-3 – 2023.06... - Page 18 The operation switch does NOT work Turn OFF the power well. supply. The Daikin eye flashes and you can Notify your installer and check the error code by the wireless report the error code. remote control. To display the error code see the user reference guide of the indoor unit.
