- Page 1 FAST AND RELIABLE EV CHARGER INSTALLATION MANUAL 7.2KW | V1.0...
-
Page 2: Specifications
SPECIFICATIONS FAST AND RELIABLE A great addition to any smart home The EV Charger is a new member of the GivEnergy family. Compatible with most plug-in electric cars, the EV charger is a great addition to your smart home system and GivEnergy ecosystem. Its... - Page 3 BOX CONTENTS & COMPONENTS Item Item Name EV Charger Mounting Bracket Components PV LED Grid LED EV LED Status 4G Sim Meter Comms EV Supply AC Supply EV Cable Comms Cable AC Supply Cable...
-
Page 4: General Information
EV Charger. Please retain this manual for future reference. Legal Disclaimer: This document is the property of GivEnergy, reproduction is prohibited. Installation Requirements Installation of the GivEnergy EV Charger must be carried out by a qualified electrician and in accordance with the IEE Wiring Regulations. Unit Information The EV Charger is used to supply power from a source of electricity to electric vehicles. -
Page 5: Safety And Installation
Extra care and attention must be taken when installing and maintaining any GivEnergy equipment. The system is capable of retaining voltage, even when disconnected If you suspect something is wrong with the charger, contact GivEnergy on 01377 252 874 or email support@givenergy.co.uk. - Page 6 STEP-BY-STEP INSTALLATION Place the wall mounting bracket horizontally onto the wall and mark the position of the bracket holes. Drill 3 holes at the marked positions, at least 75mm deep. Fix the mounting bracket to the wall using the expansion bolts. Mount the charger onto the mounting bracket.
- Page 7 Pass the power cable through the rubber grommet. Remove the 12mm insulation layer on the wire. Insert the wire into the corresponding terminal as shown in the diagram below. Tighten the screws to ensure there is a stable connection. Please note: It is recommended to install a miniature circuit breaker on the input cable Gland Input power cable Charging cable...
-
Page 8: Operation
Stop Charging To stop charging the electric vehicle, swipe the RFID card across the RFID reader on the charger unit while it is charging. The process can also be stopped by pressing ‘Stop Charging’ on the GivEnergy App. Remove the charging cable from the charging socket of the electric vehicle and replace the cable back... - Page 9 GivEnergy is the main supplier and manufacturer of the product. GivEnergy warrants that your product is (a) of acceptable quality and (b) does not have any latent defects. If you suspect something is wrong with the charger, contact GivEnergy on 01377 252 874 or email support@givenergy.co.uk.
