- Page 1 EV CHARGER INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Contents 1 Installation 1.1 Package Contents and Inspection 1.1.1 Packaging List 1.1.2 Packaging 1.2 Preparing the EV Charger 1.3 Power Supply 1.3.1 Connecting the Communications Cable 1.4 Installation 1.5 Charging Port 2 Operation 2.1 Powering on the EV Charger 2.2 EV Charger Interface 2.2.1 Overview 2.2.2 LED Indicators 2.2.3 RFID Card Reader... -
Page 3: Installation
1 Installation 1.1 Package Contents and Inspection 1.1.1 Packaging List Package Quantity Chargeron 1 pc Charge plug dock 1 pc RFID card 2 pcs Wall-mounting accessories 1 set (including A+B+C+D as Fig. 1.1 shown) User manualn 1 pc Fig. 1.1 Wall-mounting accessories... -
Page 4: Packaging
The model and specification of the charger’s nameplate match the order specifications If any damaged or missing parts are found, do not start the charger. Contact GivEnergy on 01377 252 874 or email support@givenergy.co.uk immediately. Please retain the packaging for future purpose. - Page 5 Fig. 1.2 Minimum space requirements for wall mounting • It is suggested that the charging station should be be installed in a place with good ventilation, no direct sunlight and shelter from wind and rain. • In order to ensure good ventilation conditions, you should mount the charging station vertically and leave enough space.
-
Page 6: Power Supply
Sr No. Tools Name Schematic Picture Main Users Diagonal Cut the cable plier Wire Strip cables stripper Crimping Press cable terminal tool Crosshead Fasten screws screwdriver 1.3 Power Supply The EV Charger is available for installation in any TN power supply system. a) TN-S power supply system wiring mode Fig. -
Page 7: Connecting The Communications Cable
EM115 meter, in order for the charger to charge the vehicle from excess solar. Additionally, the charger can be wired directly to the GivEnergy inverter in to the meter communication port so that the charger can be controlled by the... -
Page 8: Installation
1.4 Installation Install the charging station on the wall following the steps below: Step 1: Installing the Charging Station Mount Fig. 1.5 The fixing holes of accessories-D Drill 4 holes with a diameter of 10mm and depth of at least 50mm on the wall with spacing of 143mm x 152mm, secure the accessories-D to the wall with expansion screws. -
Page 9: Charging Port
• Loosen the gland [B] and pass the prepared power cable through it • Remove 10-12mm of insulation from the wire conductor [H] • Pull up the level [G] to open the terminal, plug the wire conductors into each terminal, press the lever down [G] to make sure every wire conductor is securely connected to the terminal •... -
Page 10: Operation
2 Operation 2.1 Powering On the EV Charger After the charging station has been installed, switch on the power supply. The indicator light [A] lights up and the charging station switches to standby state. 2.2 EV Charger Interface 2.2.1 Overview The EV Charger interface is configured with multiple LED indicators as shown in Fig. -
Page 11: Led Indicators
2.2.2 LED Indicators The LED indicators on the panel are used to indicate the status of the charging station. The various combinations of indicators are described below: Indicator Indicator Connotation Icon Colour Status Standby status Green Ground fault status Blinking Connected to an EV Charging status BLN control... -
Page 12: Rfid Tag
2.3 Connecting your EV Charger to WiFi Step 1: Connect via the GivEnergy App Follow the step by step guide in the GivEnergy App. If you don’t have the GivEnergy App, go to Step 2. Step 2: Connect to WiFi hotspot Within two minutes after powering on, the charging station provides a WiFi hotspot. - Page 13 Step 4: Configure your EV Charging Station You will need to contact GivEnergy support on 01377 252 874 or email support@givenergy.co.uk for a temporary login password. The password must be changed after first login. Fig. 2.5 Set parameters to configure the EV charging station After entering the above credentials, click the “SAVE”...
-
Page 14: Charging Connectors
As shown in Fig 2.7. plug the vehicle connector into the vehicle inlet • You can control the charging process via the GivEnergy App (QR code can be found on page 13) by swiping the RFID card across the card reader on the front of the charging station Fig. -
Page 15: Stopping The Ev Charger
Swipe your RFID card across the card reader on the front of the charging station • Press the ‘stop’ button on the EV Dashboard in the GivEnergy App Please return the vehicle connector to the vehicle port next to the charging station once charging has stopped. -
Page 16: Fault Handling
3 Fault Handling The charging station is automatically protected in the event of a fault. The fault information and handling methods are as follows. LED indicator Handling method Fault code information No LED None • Check whether the power supply lights and distribution are normal •... - Page 17 IEC standard supported • This device is damaged and needs 2 x slow Fault code 23: to be returned to GivEnergy 3 x fast Vehicle is not supported • The RCD is damaged and needs to 2 x slow...
- Page 18 www.givenergy.co.uk...
