INSTALLATION GUIDE
GB
SEALED PELLET STOVE
HALO AIR 8 M2
PART 1 - REGULATIONS AND ASSEMBLY
Instructions in English

Advertisement

Table of Contents
loading

Related Manuals for MCZ HALO AIR 8 M2

Summary of Contents for MCZ HALO AIR 8 M2

  • Page 1 INSTALLATION GUIDE SEALED PELLET STOVE HALO AIR 8 M2 PART 1 - REGULATIONS AND ASSEMBLY Instructions in English...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................II INTRODUCTION ......................1 1-WARNINGS AND WARRANTY CONDITIONS ..............2 2-INSTALLATION ......................9 3-DRAWINGS AND TECHNICAL FEATURES ..............18 4-UNPACKING ......................20 5-CLADDING INSTALLATION/REMOVAL ...............23 6-OPENING THE DOORS .....................30 7-REMOVING THE BACK FOR MAINTENANCE ...............31 8-CONNECTIONS TO ADDITIONAL DEVICES ..............32 9-LOADING THE PELLETS ...................34...

  • Page 3: Introduction

    No part of this manual may be translated into other languages, adapted and/or reproduced, even in part, in other mechanical and/or electronic form or media, for photocopies, recordings or other, without the prior written authorisation of MCZ Group Spa. The company reserves the right to make changes to the product at any time without prior notice. The owner company reserves its rights according to law.

  • Page 4: 1-Warnings And Warranty Conditions

    1-WARNINGS AND WARRANTY CONDITIONS SAFETY WARNINGS • The installation, electrical connection, operating test and maintenance must only be carried out by a qualified operator. • Install the product in compliance with the laws and regulations in force. • Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator.
  • Page 5 1-WARNINGS AND WARRANTY CONDITIONS • Do not dry laundry on the product. Any drying racks or the like must be kept at a safe distance from the product. Fire hazard. • The product maintenance operations must be exclusively carried out by a qualified operator on a yearly basis.
  • Page 6 1-WARNINGS AND WARRANTY CONDITIONS • Do not allow the product to come into contact with water, it contains live electrical parts. • Do not wash the product with water (or other liquids) as they could penetrate inside the unit, damaging the electrical insulation with the risk of electrocution. • Do not use detergents to wash the stove, they could damage the aesthetic parts of the product.
  • Page 7 1-WARNINGS AND WARRANTY CONDITIONS • The sound pressure level of this appliance does not exceed 70 dB(A). • Live electrical parts: only power the product once it has been fully assembled. • Disconnect the product from the 230V power supply before performing any maintenance operations.
  • Page 8 1-WARNINGS AND WARRANTY CONDITIONS INFORMATION: • Please contact the retailer or qualified personnel for any information, problem or malfunction. • Only use the fuel specified by the manufacturer. • When the product is switched on for the first time, it is normal for it to emit smoke due to the paint heating up for the first time. Therefore make sure the room it is installed in is well-ventilated.
  • Page 9 1-WARNINGS AND WARRANTY CONDITIONS WARRANTY CONDITIONS For the duration, terms, conditions, limitations of the MCZ conventional warranty, please refer to the specific warranty card that is included with the product. Information for management of waste electrical and electronic equipment containing batteries and accumulators This symbol appears on the product, on the batteries, on the accumulators or on their packaging or on their documentation;...
  • Page 10 1-WARNINGS AND WARRANTY CONDITIONS WARNINGS FOR THE CORRECT DISPOSAL OF THE PRODUCT The owner is the sole party responsible for demolishing and disposing of the product. This must be performed in compliance with laws related to safety and environmental protection in force in his/her country. At the end of its working life, the product must not be disposed of as urban waste.
  • Page 11 1-WARNINGS AND WARRANTY CONDITIONS LEGENDA WHERE TO DISPOSE MATERIALS Metal Glass If there is any, to be disposed of separately based on the material used: Tiles or ceramics OUTER CLADDING Stone Glass ceramic (fire door): to be disposed of with inert or mixed waste If there is any, to be disposed of separately based on the material used: Tempered glass (oven door): to be disposed...
  • Page 12 The EC Declaration of Conformity, the Declaration of Performance required by EU Regulation 305/2011 and all other product certification documents can be downloaded by scanning the QR code on this page (also found on the product label) or by accessing the website page www.mczgroup.com/support/mcz Having specified the above, we highlight and report that: • This manual and technical data sheet, also available on our website, bear all of the specific indications and necessary and...

  • Page 13: 2-Installation

    2-INSTALLATION The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case, always observe the regulations in force in the country of installation. PELLETS The pellet is obtained from natural dried wood sawdust (without paint). The compactness of the material is guaranteed by the lignin contained in the wood itself, without glue or binders.
  • Page 14 2-INSTALLATION FOREWORD The heating system (generator + combustion air supply + combustion product expulsion system + any hydraulic/aeraulic system) must be installed in compliance with the laws and regulations in force , and carried out by a qualified technician, who must issue a declaration of conformity of the system to the system manager and shall undertake full responsibility for final installation and consequent good operation of the product.
  • Page 15 2-INSTALLATION MINIMUM DISTANCES Observe the distances from flammable objects (sofas, furniture, wood panelling, etc..) as specified in the following diagram. If objects considered to be particularly sensitive to heat are present, such as furniture, curtains or sofas, as a precaution, increase the stove clearances substantially to avoid possible deterioration due to the effect of heat.
  • Page 16 2-INSTALLATION In any case, ensure adequate distance to facilitate access during cleaning and extraordinary maintenance. If this is not possible, it must still be possible to distance the product from adjacent walls/elements. This operation must be performed by a technician qualified to disconnect the combustion product expulsion ducts and their subsequent restoration.
  • Page 17 2-INSTALLATION Below 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Above 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 18 2-INSTALLATION Preparing the smoke expulsion system The combustion product expulsion system is a particularly important element for the proper operation of the appliance and must be correctly sized according to EN 13384-1. Its creation/adaptation/verification must always be carried out by a legally qualified operator and must comply with the regulations in force in the country where the appliance is installed.
  • Page 19 2-INSTALLATION Chimneypot The chimneypot, meaning the end part of the flue, must meet the following characteristics: • the smoke outlet section must be at least double the internal section of the chimney; • prevent the penetration of rain or snow; •...
  • Page 20 2-INSTALLATION EXAMPLES OF INSTALLATION (DIAMETERS AND LENGTHS TO BE SIZED) 1. Flue installation with hole for the passage of the pipe increased by: • minimum 100mm around the pipe if next to non-flammable parts such as cement, brick, etc.; or •...

  • Page 21: 3-Drawings And Technical Features

    3-DRAWINGS AND TECHNICAL FEATURES DRAWINGS AND CHARACTERISTICS HALO AIR 8 M2 STOVE DIMENSIONS Ø80 Ø50 Ø520 Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 22 3-DRAWINGS AND TECHNICAL FEATURES TECHNICAL CHARACTERISTICS HALO AIR 8 M2 Energy Efficiency Class Nominal output power 8.1 kW (6966 kcal/h) Minimum power output 3.5 kW (3010 kcal/h) Efficiency at Max 90.9% Efficiency at Min 91.5% Temperature of exhaust smoke at Max 188 °C...
  • Page 23 ACCORDING TO COMMISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) Manufacturer: MCZ GROUP SpA Trademak: Model Identifier: HALO AIR 8 M2 Indirect heating functionality: Direct heat output (space heat output): Indirect heat output (water heat output): CPR harmonised standard:...

  • Page 24: 4-Unpacking

    4-UNPACKING INSTRUCTIONS FOR PACKAGING DISPOSAL The material that the appliance’s packaging is made of must be managed correctly, in order to make collection, reuse, recovery and recycling easier, where possible. The table below illustrates the possible components that the packaging is made of, and the relative instructions for correct disposal. DESCRIPTION CODE MATERIAL SYMBOL...
  • Page 25 4-UNPACKING Handle the product with suitable means paying attention to the applicable safety regulations in force. Do not turn the packaging over and handle the majolica parts with care. The stove is delivered in two packages: one for the stove structure and the other for the cladding. Open the package, remove the cardboard, polystyrene and any straps and position the stove in the preset place making sure that it complies with the requirements.
  • Page 26 4-UNPACKING REMOVING THE FASTENING BRACKETS To remove the stove from the pallet, you must remove the two screws “u” and plate “s” from the stove’s foot. There are four brackets “s”.
  • Page 27 4-UNPACKING Position the stove and connect it to the flue pipe. Use the 4 adjustable feet (J), to level the stove correctly so that the smoke outlet is lined up with the connecting pipe. If the stove needs to be connected to an outlet pipe which goes through the rear wall (to connect to the flue), take utmost care to make sure that the joint is not forced.

  • Page 28: 5-Cladding Installation/Removal

    5-CLADDING INSTALLATION/REMOVAL On delivery, the Halo stove is without the two front panels of the cladding, as shown in the image below. The following are indications for installing the cladding and removing some parts of the stove for technical interventions, parts replacement and/or cleaning.
  • Page 29 5-CLADDING INSTALLATION/REMOVAL DISASSEMBLING THE TOP The top is fixed to the structure by four screws “u”, so lift the pellet loading door “D” and remove the screws “u”. Put the top “C” in a safe place while it is not used. Caution! Lower the control panel before opening the pellet cover “D”...
  • Page 30 5-CLADDING INSTALLATION/REMOVAL INSTALLING THE FRONT LOWER PANEL To install the front lower panel “B” proceed as follows: • approach the panel “B” to the bracket on the left side of the stove structure, making sure the holes match • Fix the panel “B” with the two screws “v” supplied •...
  • Page 31 5-CLADDING INSTALLATION/REMOVAL INSTALLING THE FRONT UPPER PANEL To install the upper panel “A” proceed as follows: • remove the top “C” • open the decorative door “F” of the stove • fix the panel “A” at the top with the two screws “s” supplied •...
  • Page 32 5-CLADDING INSTALLATION/REMOVAL REMOVING THE SIDE PANEL To remove the side panels for cleaning and/or technical interventions, proceed as follows: • remove the top (as indicated in the dedicated paragraph) • remove the three screws “h” and washers “r” at the top of the stove structure •...
  • Page 33 5-CLADDING INSTALLATION/REMOVAL Remove the control panel on the rear part • eliminate the 4 grub screws “g” • release the panel “P” • remove the screws “x” and the bracket “s” Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 34 5-CLADDING INSTALLATION/REMOVAL • open the decorative door “F” • open the lower door “B” with the cold handle “z” supplied (see dedicated paragraph) • remove the screw “y” from the bottom part • remove the screw “r”from the top part...
  • Page 35 5-CLADDING INSTALLATION/REMOVAL • lift the panel “E” upwards to remove the hooks “w” on the stove structure from the holes “K” on the panel • at this point the panel “E” can be put in a safe place until it is used again. Technical Dept.

  • Page 36: 6-Opening The Doors

    6-OPENING THE DOORS The Halo stove has two doors; to open the decorative door “F” and/or the firebox door “G”, insert the cold handle “z” in the slot and pull. Also to open the door “B” insert the cold handle in the slot at the top of the door and pull (the decorative door “F” must be open). Attention! Only open the doors when the stove is switched off and cold.

  • Page 37: 7-Removing The Back For Maintenance

    7-REMOVING THE BACK FOR MAINTENANCE REAR PANEL If it is necessary to intervene on any stove component, proceed as follows to remove the rear panel “L”. • remove the two screws “i”, so that element “O” can be removed • remove the 8 screws “p”...
  • Page 38 7-REMOVING THE BACK FOR MAINTENANCE ACCESS TO THE GEAR MOTOR When performing maintenance, the gear motor can be accessed directly by undoing the six screws “x” and removing the cover “S”.

  • Page 39: 8-Connections To Additional Devices

    8-CONNECTIONS TO ADDITIONAL DEVICES ELECTRICAL CONNECTION First connect the power cable to the back of the stove and then to a wall socket. It is recommended to disconnect the power cable when the stove is not used. The cable must never come into contact with the smoke exhaust pipe or any other part of the stove. ELECTRICAL STOVE CONNECTION STOVE POWER SUPPLY Connect the power cable to the back of the stove and then to a wall socket.
  • Page 40 8-CONNECTIONS TO ADDITIONAL DEVICES USB SOCKET There is a USB socket on the back of the stove, if a software update is required; the ceramic/metal parts do not have to be removed to reach the socket directly in the circuit board (pos. 13 in the PCB). Attention! The USB socket must be used by skilled technicians.

  • Page 41: 9-Loading The Pellets

    9-LOADING THE PELLETS LOADING THE PELLETS Fuel is loaded from the upper part of the stove by lifting the pellet loading door “D”. Use the supplied glove to open the door “D”. Pour the pellets in slowly so that they are deposited at the bottom of the hopper. If loading pellets when the stove is running, open the door of the tank using the glove supplied with the stove itself.
  • Page 44 MCZ GROUP S.p.A. Via La Croce n°8 33074 Vigonovo di Fontanafredda (PN) – ITALY Telephone: 0434/599599 a.s. Fax: 0434/599598 Internet: www.mcz.it e-mail: mcz@mcz.it 8902257000 REV.0 24/11/2022...
