HomLiCon LCH5LP-S Manual

www.homlicon.com
–
Control of groups LED and LED strips
–
Control dynamic illuminated advertising signs
–
Sound activated Light Show
LED sequencer mode number of Channels
Sound activated Light Show number of channels
Supply voltage
Maximum output current per channel
Maximum total output current
Line-in Nominal level
Line-in Maximum level
Mic-in range of sound level (with an added
module MACL - not included in the kit)
Current consumption
Ambient temperature

LED sequencer mode suitable for use with advertisement lighting, party lights, etc.

Ability to choose separate settings for speed and number of repetitions for each program.

Sound activated Light Show

Control all settings and functions with the IR remote control included in the kit.

Activation of Light Show controlled by sound from microphone

Level Meter with / without AGC (Automatic gain control).

Automatic or manual switching between different programs of Light Show.

Possibility to select a mode to be activated when applied to the supply voltage..

LED on each one of the channels connected to the microcontroller pins for indication and diagnostics.

Power MOSFET for the output of each channel.
2023 mc-kit.net
5 Channel LED Controller
HomLiCon LCH5LP-S
Application
Technical Specifications
Controller Features
HomLiCon LCH5LP-S v2
4 or 5
5
8 − 16V DC
2A
10A
0.3V
RMS
1.5V
RMS
60 - 120 dB (with additional module)
15mA
5 − 40°C
(1)
, Line-in or unsynchronized.
(1)
Page 1
