DSPPA MP9813C Quick Start Manual

Description
MP9813C broadcast partitioner has 2 channels of inputs and 10 channels of outputs. With override function,
it can input emergency broadcast signal. Besides, it has 10 zone selection buttons with independent volume
control.
Features
 With 2-channel inputs (A & B), and 10-channel outputs.
 With override function.
 With ALL ON/OFF function control.
 With independent volume control for 10-channel zones (valid for the channel A input audio source).
Support automatic switching of the corresponding channel to the channel B when there is an alarm

signal input.
Specifications
Package Dimensions (mm)
Machine Dimensions (mm)
export@dsppa.com /
Broadcast Partitioner
Model
Number of Channels
Input Capacity
Output Capacity
Alarm Signal
Protection
Power
Gross Weight
Net Weight
www.dsppatech.com
MP9813C
10 channels, which can be selected arbitrarily.
70-100V, 5A for each channel
The specifications will be subject to changes without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights served.
MP9813C
70-100V, 10A
Valid for 0V (short circuit)
AC Fuse
AC 220V/50Hz
(L×W×H) 530×440×195
(L×W×H) 484×365×88
11.2kg
9.4kg
