MEET Technology MS-912 Quick Start Manual

Mini Light Meter With Temperature
Model No.: MS-912
Thank you for purchasing MEET Mini Light Meter

1. Contents

- Light meter
- Operating manual

2. Descriptions

This Light Meter is designed to meet the measurement requirements of safety engineers, health,
industrial safety offices and light quality control in various environments like factory, school,
construction stits, etc.

3. Advanced Features

- 0 to 200,000 Lux
- Auto range
- Measures Lux or Foot-Candles (FC)
- Automatically revise parameters for nonstandard illumination
- High accuracy and rapid response sampling time
- Temperature measurement
- Convert temp. in °C / °F
- Color LCD display with backlight
- Over range indication
- MAX / MIN record reading
- Enable / Disable auto power off (APO)
- Low battery indication
- Hold / Freeze reading
1

4. Specifications

Display 4 digits color LCD display
Measuring Range (Lux/Fc) 0~200K Lux / 0~20K Fc
Accuracy (<10,000Lux) ±3% rdg ±8d ; (>10,000Lux) ±4% rdg ±10d
Range (Temp.) -20ºC ~ 70ºC / 4ºF ~ 158ºF
Accuracy (Temp.) ±1.5ºC / 2.7ºF
Spectral Accuracy CIE V function ( fl' ≤6%, f2' ≤ 2%)
Sampling Rate 500ms
Photo detector Silicon photo-diode with spectral response filter
The meter shuts off automatically after 15 minutes inactivity
Enable / Disable Auto power off
under auto power off mode, disable auto power off is available
Resolution (Lux) <1000 : 0.1 ; >1000 : 1
Resolution (Temp.) 0.1
Operating Condition -20ºC ~ 60ºC / -4ºF ~ 140ºF; 10%RH ~ 90%RH
Storage Condition -30ºC ~ 60ºC / -4ºF ~ 140ºF; 10%RH ~ 75%RH
Battery Powered / Battery Life 3 x AAA (R03 / LR03) / > 60 hours
Demensions (L x W x D) mm
174.5x56x31
(apprpx.)
Weight (approx.) grams 85
5. Descriptions
1
8
2
3
7
4
HOLD
5
6
Light sensor
①
LCD display
②
Hold button
③
Power ON/OFF button
④
MAX / MIN button
⑤
Fc / Lux button
⑥
Battery compartment
⑦
Sensor protective cover
⑧
2
