- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Bushnell All Purpose 10x42 o cerca il tuo prodotto tra le migliori offerte di Binocoli e Cannocchiali BINOCULAR INSTRUCTION MANUAL 05-17...
- Page 2 NEVER LOOK DIRECTLY AT THE SUN WITH YOUR BINOCULAR, AS IT MAY CAUSE SERIOUS DAMAGE TO YOUR EYES...
- Page 3 An Engaging New View of the Outdoors ED Prime Glass. ED Prime Extra-Low Dispersion The new Engage™ line of binoculars from Bushnell® deliver fluorite glass delivers amazing color resolution an unmatched price/performance ratio, with a wide range of and contrast, and virtually eliminates chromatic...
- Page 4 Center Focus Knob Eyecup (Twist-Up) Ocular Lens (Eyepiece) Diopter Adjustment Ring (Locking) Strap Lug Tripod Adapter Socket Objective Lens (under cap)
- Page 5 Read the instructions carefully before using your binocular. Eyecup Adjustment Your Bushnell Engage binocular is fitted with twist-up eyecups that provide a comfortable view of the full image and help to exclude extraneous light. For use without eyeglasses or sunglasses, twist the eyecups up, rotating the eyecups counter-clockwise until they lock into the fully “up”...
- Page 6 Wide IPD Narrow IPD Fig. 3 Interpupillary Distance Adjustment UNLOCKED LOCKED Fig. 4 Diopter Adjustment Ring Focus and Diopter Adjustment 1. First, adjust the eyecups and IPD as described in the previous sections. 2. Using the attached lens cap or your hand, cover the objective lens on the right side of the binocular. 3.
-
Page 7: Neckstrap Attachment
7. Once the diopter adjustment ring is set for your eyesight, push the ring back down to lock it in place (Fig. 4, “LOCKED”). 8. Your binocular should now be adjusted for your eyes. Focusing for any distance can now be done simply by turning the center focus knob. -
Page 8: Tripod Mounting
(Fig. 8), and set it aside in a safe place. Use a compatible binocular tripod adapter accessory, such as the Bushnell model #161001CM, to attach your Engage binocular to any standard tripod in a horizontal position to provide a stable image during prolonged viewing. - Page 9 Cleaning 1. First, blow or brush away any dust or debris on the lens (using “canned air” or a soft lens brush). 2. To remove dirt or finger prints, clean with the supplied soft storage bag (made of washable micro-fiber cloth), rubbing in a circular motion.
-
Page 10: Technical Specifications
Technical Specifications BEN842 42 MM Roof BaK-4 Fully 426 / 142 6.5 / 1.9 23.5 / 5.5' 53-72 Multi BEN1042 42 MM Roof BaK-4 Fully 340 / 113 8 / 2.4 23.5 / 5.5' 53-72 Multi BEN1050 50 MM Roof BaK-4 Fully 341 / 114... - Page 11 BUSHNELL IRONCLAD WARRANTY Products manufactured on or after April 2017 are covered by the Bushnell Ironclad Warranty. The Ironclad Warranty is a full lifetime warranty that covers the lifetime of this Product. Each Product has a defined lifetime; lifetimes can range from 1 to 30 years. This Product’s lifetime can be found at the website listed below and/or on the Bushnell webpage specific to this Product.
- Page 12 For further questions or additional information please contact: Bushnell Outdoor Products 9200 Cody, Overland Park, Kansas 66214 (800) 423-3537 • www.bushnell.com U.S. Patent Numbers 6,906,862 / 6,816,310 / 6,542,302 ©2017 Bushnell Holdings, Inc.
