- Page 1 REPLACING YOUR X1 PRO’s PLANETARY GEARS Installation Guide for Brass Gears...
- Page 2 REPLACING YOUR X1 PRO’S PLANETARY GEARS How to Replace your X1 PRO’s Planetary Gears Installation Guide for Brass Gears Requirements 1. 3x brass gears provided by CYCMOTOR 2. Circlip pliers or similar tool 3. Bearing puller (optional) 4. 2x flat head screwdrivers 5.
- Page 3 REPLACING YOUR X1 PRO’S PLANETARY GEARS Step 2 – Rotate & remove the cover. Rotate the cover then hold it as shown below. Slightly strike the shaft with a mallet to remove the cover. Step 3 – Remove the planetary carrier or proceed to Step 4 if you have a bearing puller.
- Page 4 REPLACING YOUR X1 PRO’S PLANETARY GEARS Step 4 – Remove the circlips & the steel gears. For demonstration purposes, we’ve used a clean planetary carrier. Remove the inner circlips with circlip pliers or similar tool. Again, be careful not to yield the circlip if you do not have spares.
- Page 5 REPLACING YOUR X1 PRO’S PLANETARY GEARS Once all brass gears are inserted with the circlips in the correct position, be sure to add some more grease. CYCMOTOR uses MOLYKOTE BR2 Plus grease. Reassembly the ring gear & close the gearbox. MOLYKOTE BR2 Plus grease Step 6 –...
