IRON-GRIP
O W N E R ' S
DIAGRAM
(QTY) PART NAME
NUMBER
(1) Base
B
(1) Top Plate
C
(2) Top Track
D
(1) Acrylic Guide
E
(6) Spacer Tube
F
(2) Bridge Handle
G
(1) Fence
H
(1) Bridge
I
(1) Work Holding Block
(1) Ball Shaft
(1) Ball End Cage
(1) Spring Clamp
J
(1) Black Woodpecker Knob, 5/16
(1) Hex Nut, 3/8-16
(4) Button Head Screw, 8-32 x 5/16"
---
(2) Steel Dowel Pin, 1/4 x 2"
---
(5) Flat Head Machine Screw, 1/4-20 x 5/8"
(3) Spoil Board
K
(4) Knob, 1/4-20
L
---
(1) Ball Wrench 3/16"
---
(1) Allen Wrench 5/32"
You can also call us at 800-752-0725 from 9:00 a.m. to 4:00 p.m. EST Monday - Friday.
HARDWARE BAG A
HARDWARE BAG B
HARDWARE BAG C
HARDWARE BAG D
If you think you're missing anything, email us at mailroom@woodpeck.com.
COPING SLED
TM
M A N U A L
(QTY) PART NAME
(6) Weldnut, 1/4-20
(4) Flat Head Machine Screw, 1/4-20 x 2-3/4"
(2) Button Head Screw, 1/4-20 x 2-1/2"
(2) Hex Head Bolt-A, 1/4 x 20 x 2-1/2"
(2) Nylon Washer-A (black), 1/4 x 7/8"
(2) Hex Head Bolt-B, 1/4-20 x 1"
(2) Nylon Washer-B, 1/4 x 3/4"
(2) Flat Head Machine Screw 1/4-20 x 1-1/2"
(2) Nylon Washer, 1/4 x 1-3/8"
(2) Fender Washer, 1/4 x 1-1/4"
(2) Kept Nut, 1/4-20
(2) SAE Washer, #10
(8) Weldnut, 1/4-20
(5) Flat Head Screw, 1/4-20 x 5/8
(3) Cap Screw, 1/4-20 x 3/4"
Scan the QR code above
to watch the video
or visit woodpeck.com
under the video tab towards
the bottom of the product page.
