- Page 1 International Surface Technologies eyond the surface SUCTION CABINET ECONOBLAST SERIES 120 V Service Parts Warranty Accessory Information Safety Registration Form Operation INSTRUCTION MANUAL 2024-01-02...
-
Page 2: Table Of Contents
BAGHOUSE DUST COLLECTOR DC50 - GENERAL PARTS LIST ...................24 PNEUMATIC DIAGRAM ..................................25 ELECTRICAL SCHEMATIC: DRAWING ............................26, 27 ISTBLAST LIMITED WARRANTY ..............................28 ISTBLAST WARRANTY REGISTRATION ............................29 INFORMATION / TECHNICAL ASSISTANCE ..........................30 OUR MAP LOCATION ..................................31 ABOUT THE COMPANY ..................................32 ECONOBLAST Series - Instruction Manual... -
Page 3: Cabinet Technica Data
67’’ x 72’’ x 78’’ 79’’ x 72’’ x 78’’ DOOR OPENING (W X H) 20" x 29" 30’’ x 29’’ 42’’ x 29’’ WEIGHT (lb) VOLTAGE 110 V / 1 ph / 60 Hz / 15 A ECONOBLAST Series - Instruction Manual... -
Page 4: Notice To Purchasers - Safety And Warning
1. Carefully inspect the shipping carton for any signs of transport damage. The damage to the carton often indicates possibility of transport damage to the equipment inside. 2. Carefully remove your IST SANDBLASTING CABINET from the shipping carton and skid. 3. Check your equipment immediately to ensure that it is free of transport damage. Report any transport damage to the carrier without delay for possible claim procedures. -
Page 5: Danger And Warning Labels
« READ ALL INSTRUCTIONS » Failure to follow the SAFETY RULES identified by a BULLET ( ) symbol listed BELOW and other safety precautions may result in serious personal injury. « SAVE THESE INSTRUCTIONS » ECONOBLAST Series - Instruction Manual... -
Page 6: General Safety Rules - Unit Use And Care
Only trained repairmen should attempt ( ) ALL REPAIRS, electrical or mechanical. Contact the nearest IST ISTblast repair service facility. Use only IST ISTblast replacement parts; any other parts may create a hazard. ENVIRONMENTAL CONDITIONS FOR WHICH THE EQUIPMENT IS DESIGNED Indoor location ... -
Page 7: Installation - Pneumatic Connection
Secure both ends with the supplied clamps. See dust collector section for more details All IST ECONO Series cabinets are equipped with a dust collector and a 400 cfm fan motor. -
Page 8: Electrical Connections - Air Consumption
For detailed electrical connections wiring requirements, overload and starter, Refer to electrical drawings on pages 22 and 23. It is important to connect the IST system to an Earth Ground to bleed off static electricity, which may be generated while blasting. The Earth Ground may also reduce the discomfort an operator may experience when static electricity is discharged. -
Page 9: Loading Abrasive Media
2. SLOWLY add approximately half a bag of 1. Turn on the cabinet to activate the vacuum abrasive media through the grating inside system. the cabinet. NOTE: Some cabinets can hold more than half a bag when added gradually. ECONOBLAST Series - Instruction Manual... -
Page 10: Operation
CABINET DUST BAG AR¾ ADJUSTMENT ON/OFF Switch Air inlet hole Storage Hopper The clip must cover 2/3 of the hole. See parts numbers on page 17 Foot Pedal ECONOBLAST Series - Instruction Manual... -
Page 11: Shut Down
7. Shake bags of your dust collector (disregard if you system is equipped with a DB13 dust bag ) PROPER AIRJET/NOZZLE COMBINATIONS Make sure you have a proper air jet/nozzle combination. Standard IST suction cabinets are equipped with 5/32’’ air jets and 5/16’’ nozzles. - Page 14 Never use non-recyclable abrasive in IST cabinets, such as slag, silica sand, recycled glass, or other like them. IST cabinets are designed to be used exclusively with recyclable abrasive that generates a limited amount of dust. Ask your IST representative for more information.
- Page 15 1. If the nozzle is damaged by excessive wear from the outside, replace it. 2. If the internal diameter of the nozzle exceeds 1/16’’ of its original size, replace it. ECONOBLAST Series - Instruction Manual...
-
Page 16: Troubleshooting
Too much abrasive in Incorrect adjustment Slightly open the orifice of the AR ¾ valve : the mix (the jet is jerky of the AR ¾ abrasive More air = less abrasive discharges metering valve much abrasive) ECONOBLAST Series - Instruction Manual... - Page 17 ’’ X 3’’ Nipple 610288 Standard ISTblast ® Complete Door Lock 600115 OPTION Factory Mounted Pedal Kit & G5 Blast Gun 910223 Door Latch Rubber Bumper Screw 600215 OPTION Pedal Kit & G5 Blast Gun (parts only) ECONOBLAST Series - Instruction Manual...
- Page 18 ****** G15 Trigger Operated Sandblast Gun (see next page) 606104 ½” Diameter PVC Abrasive Hose (sold per foot) 606103 3/8 ” Ø Air Hose (sold per foot) 624128 T128 8 ” Ø Clamp for gloves ECONOBLAST Series - Instruction Manual...
-
Page 19: Schematic Of Unit- Exploded View & Parts
Electric Motor 120V AC, 60 Hz, 3450 rpm 610523 hp ECONOBLAST ® Turbine, ½ ” shaft 610522 High-Efficiency ECONOBLAST Turbine 601315 DB-13 Dust Bag 601310 Dust Pail 624137 T188 (11 ¼”) Clamp for Dust Pail 624117 T64 (4”) Ø clamp ECONOBLAST Series - Instruction Manual... -
Page 20: G15 Gun & Nozzles List
Cost-effi cient nozzle for occasional use with soft abrasive media, such as glass beads, wallnut shell, and steel shot / grit. TUNGSTEN CARBIDE NOZZLE Higher durability nozzle for regular use with highly abrasive me- dia, such as aluminum oxide and GMA Garnet. ECONOBLAST Series - Instruction Manual... -
Page 21: G5 Gun Parts
1/8” 610127 Boron carbide BN2-5 5/16” 605011 610117 5/32” 610168 Boron carbide BN2-6 3/8” 605021 610109 3/16” 610128 Boron carbide BN2-7 7/16” 605012 610118 7/32” *Pre-assembled blast guns include all parts, plus a B-C combination. ECONOBLAST Series - Instruction Manual... -
Page 22: Foot Pedal & Options : Pressure Regulator, Air Blower
¼’’ Blue Poly. Tube 324571 (sold/fo.) ¼’’ x ¼’’ TU Bulkhead 324503 Push-in Fitting ¼” MPT x ¼” TU Hose 632270 Barb Fitting ¼’’ Multipur. Hose 606147 (sold/fo.) Air Blowgun 610275 c/w Fitting Optional Air Blowgun Kit ECONOBLAST Series - Instruction Manual... -
Page 23: Recommended Spare Parts
606148 Safety Glass 610205 All Models Window Shield 613026 Dust Collector DB13 601315 Filtering Bag DC50 601316 Dust Carrying Hose DC50 606167 *Corresponds to the standard items and may not reflect your actual cabinet configuration. ECONOBLAST Series - Instruction Manual... -
Page 24: Baghouse Dust Collector Dc50 - General Parts List
TYPE ‘‘D’’ RUBBER SEAL (SOLD BY FOOT) 618321 601309 ‘‘S’’ HOOK DUST DRAWER 612427 LEVELING LEG ACCESS DOOR 601316 DB6HP 56’’LG X 5¼’’ Ø DUST BAG MANUAL SHAKER HANDLE 610269 TOGGLE STEM (All items are sold by the foot or individually) ECONOBLAST Series - Instruction Manual... -
Page 25: Pneumatic Diagram
International Surface Technologies eyond the surface PNEUMATIC DIAGRAM ECONOBLAST Series - Instruction Manual... -
Page 26: Electrical Schematic: Drawing
International Surface Technologies eyond the surface ELECTRICAL SCHEMATIC - 1 PH / 120 V - DIAGRAM ECONOBLAST Series - Instruction Manual... - Page 27 International Surface Technologies eyond the surface ELECTRICAL SCHEMATIC - 1 PH / 120 V - PARTS LIST ECONOBLAST Series - Instruction Manual...
-
Page 28: Istblast Limited Warranty
Report all accidents or “near misses” which involve ISTblast products to : - Technical Assistance The following items are not covered under the ISTblast warranty policy : - Parts or chassis replacement due to normal wears. ECONOBLAST Series - Instruction Manual... -
Page 29: Istblast Warranty Registration
International Surface Technologies 1050 Des Forges Street Hwy. 640 Industrial Park Terrebonne, Quebec J6Y 0P6 Canada Phone : 800 361-1185 General Email : info@istsurface.com ECONOBLAST Series - Instruction Manual... -
Page 30: Information / Technical Assistance
International Surface Technologies For more information, pricing or technical support, contact your local IST distributor or call / fax to our Consumer Information numbers: TEL.: 1 877 629-8202 & 450 963-4400 Or visit us at: istsurface.com ECONOBLAST Series - Instruction Manual... -
Page 31: Our Map Location
International Surface Technologies eyond the surface OUR MAP LOCATION ECONOBLAST Series - Instruction Manual... -
Page 32: About The Company
ABOUT THE COMPANY WHO WE ARE IST is a leading manufacturer of equipment for the surface treatment industry and the solvent recycling industry. Our extensive line of equipment includes batch units and automated machines designed to achieve the highest manufacturing standards.
