Installation guide
Please read through before installation. Please read safety guidelines leaflet.
What's in the box? Getting to know the energiser
1
8
11
- Type HLB3
- 47HLB500/525 - Falcon/Buzzard
2
9
Key
1.
Base
2.
Ground connection terminal
3.
Fence connection terminal
4.
On off switch
5.
Low battery/pulse indicator
6.
High/low switch
7.
Thumbscrews for removing base
8.
Ground connection leads
9.
Fence connection lead
10.
12v connection leads
11.
Battery input connection (base removed)
3
5
4
6
7
10

Advertisement

loading
Need help?

Need help?

Do you have a question about the Falcon 47HLB525 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hotline Falcon 47HLB525

  • Page 1 Installation guide - Type HLB3 - 47HLB500/525 - Falcon/Buzzard Please read through before installation. Please read safety guidelines leaflet. What’s in the box? Getting to know the energiser Base Ground connection terminal Fence connection terminal On off switch Low battery/pulse indicator High/low switch Thumbscrews for removing base Ground connection leads...
  • Page 2 Connecting it all together The energiser can be operated from a 6 or 12v battery. 6v (47P44)batteries fit into the battery box for easy portability. Standard size leisure batteries are run from outside of the battery box. 12v battery connection (external) Unscrew the thumb screws and remove the energiser top from the battery box.
  • Page 3 Connection to the fence Lead connection Unscrew the terminals enough to slide in the fork terminals on the earth and fence leads. Securely tighten. Fence connection Connect the lead with the red croc clip to the fence (from red terminal) & the green croc clip (from the green terminal) to the ground rod.
  • Page 4 Trouble shooting You should have a minimum of 3kv on your fence line to be effective. In principle, electric fencing is a simple concept. If your energiser is working then there can only be two other places to look - your fence line or ground system. Checking the energiser Sound and sight - Most energisers emit an audible tick caused by the firing of the output transformer.
