- Page 1 Mullen ONE Emergency Response Guide...
-
Page 2: Table Of Contents
Moving Damaged Vehicles ..........................7 Damaged Vehicle Storage ..........................8 High Volt Battery Handling & Storage ........................ 8 Component Index .............................. 8 Explanation of Pictograms ..........................9 Contact Information ............................9 © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved. -
Page 3: Rescue Sheet
Rescue Sheet Mullen Automotive, Inc. (Mullen) electric vehicles use an electric motor for power and the electricity required to power this electric motor is stored in a high voltage battery pack. Lack of engine noise does not mean the vehicle is off. Silent movement or instant restart capability exists until the vehicle is fully shut down using the Manual Service Disconnect (MSD). -
Page 4: High And Low Voltage Battery Hazards
• When the 12-volt (low-voltage) cables are cut at the battery, the high-voltage system will be disabled due to low-voltage actuating the high-voltage contactors inside the high-voltage battery pack. • The high-voltage battery cells contain a base electrolyte consisting of lithium hexafluorophosphate © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved. -
Page 5: Disabling High And Low Voltage Systems
4. Turn the key in the ignition to the “OFF” position and remove the key from the ignition. 5. Position wheel and tire chocks to prevent rolling or shifting of the vehicle. © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved. - Page 6 5. Rotate the black locking lever up (3). 6. Pull straight out on the body of the MSD to remove it (4). 7. Wait a minimum 15 minutes to allow charges to dissipate. © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved.
-
Page 7: Occupant Removal
Mullen One Cargo Van’s have a unique badge. • The Mullen logo is located on the front the vehicle below the hood and on the rear cargo door above the license plate. © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved. -
Page 8: Stored Energy / Liquids / Gases / Solid
Disengage high voltage components by removing the MSD and disconnecting the 12-volt battery. WHEN TOWING THE VEHICLE, USE A FLATBED TRAILER OR TOW FROM THE FRONT WHEELS. TOWING FROM THE REAR WHEELS CAN DAMAGE THE VEHICLE. © Copyright 2023 Mullen Automotive, Inc. All Rights Reserved. -
Page 9: Damaged Vehicle Storage
• battery from a charge station. Auxiliary Drive System (3 in 1) – There are three major components in this one device: (1) the On- • Board Charger (OBC). (2) the Power Distribution Unit (PDU) and (3) the DC-to-DC Converter. These components can be controlled independently through CAN or analog inputs to power vehicle devices, as well as charge both the high and low voltage batteries. -
Page 10: Explanation Of Pictograms
These instructions are applicable to Mullen ONE vehicles. Certain devices, facilities or functions introduced in these instructions may not be installed on your vehicle due to different vehicle configurations. Mullen reserves the right to modify any and all information shown without notification. Options subject to change. - Page 11 Part# AGID-013X-AA...
