- Page 1 Trem-Drive Deluxe OWNER’S MANUAL...
- Page 2 You will immediately feel how flexible the amp can be, and so many of the iconic tones are very easy to dial in. The Trem-Drive Deluxe comes in different power levels, from 22w to 100w and can be found in head or combo form factor. The higher wattage amps have increased headroom as you go up in power, with increased sonic presence.
- Page 3 DC. Do not attempt to service, repair or conduct tube biasing unless you are qualified to do so. Please contact Amplified Nation beforehand with questions in this regard. Amplified Nation takes no responsibility or shall be held liable for any personal harm caused or damage to this amplifier as a result of unauthorized service, repair or internal adjustments made to this amplifier.
-
Page 4: Front Panel Functions
Front Panel Functions Low Input: Lower gain input to the amplifier. Plug in your instrument here to skip the first gain stage. High Input: Higher gain input to the amplifier. Plug in your instrument here to experience all gain stages. Overdrive: Adjusts the initial overdrive gain stages of the amplifier, to increase the amount of gain and saturation turn this control clockwise. - Page 5 Front Panel Functions (CONTINUED) Accent: Higher settings of the accent control will add extra brilliance to the amplifier, and can be useful when changing guitars. Power Indicator Lamp: The replacement light bulb is a 6.3v A/C. NOTE: All switches are ON in the “up” position.
-
Page 6: Rear Panel Functions
Rear Panel Functions Mains: Connects the amplifier to A/C power with included IEC power cord. Fuse: See Fuse Chart page 7. Power Switch: Turns the A/C mains power on to the amplifier. Standby Switch: The standby switch can be used when powering up the amplifier and allows the tubes to warm before hitting them with DC voltage. -
Page 7: Fuse Chart
Fuse Chart All Fuses are 3AG Type 250 Volt, SLO-BLO Domestic 120v Fuses: Export 230v, 240v Fuses: 2A – 22 Watt 1A - 22 Watt 3A - 50 Watt 1.5A - 50 Watt 3A - 100 Watt 1.5A - 100 Watt Tube Complement POWER TUBES BIAS... - Page 8 Bias Adjustment Procedure All of our amps are equipped with external bias test points and an external bias adjustment pot. The adjustment pot is located in between the power tube sockets and should be adjusted using an insulated flat tip screwdriver. •...
- Page 9 It is the customer’s responsibility to pay to ship the product to us, and if it is determined the warranty doesn’t apply, the customer is responsible for the return shipping. If the product is a warranty repair, Amplified Nation will cover the return shipping. CONTACT US This manual is a resource for some of your questions.
