- Page 1 Nina Barstool Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - Sep 2023...
- Page 2 ● Regularly check and ensure that all bolts and fittings are tightend properly. • Maximum user weight 100kg ● This product is compliant EN12520 Habitat, Argos limited and Sainsbury’s Supermarkets Ltd, London EC1N 2HT, UK. Argos(N.I.) Ltd and Sainsbury’s (NI) Ltd. Forestside Shopping Centre, Upper Galwally, Belfast, BT8 6FX, UK...
- Page 3 Fittings (Shown to scale) Bag 1 M6x25mm Bolt x 8 M6x50mm Bolt x 4 Spring Washer x 4 Flat Washer x 4 M6x50mm Screw x 8 Ø25mm Felt pad x 4 M4 Alley Key x 1...
- Page 4 Parts Bottom Leg Frame x 1 Up Leg Frame x 1 (753 x 562mm) (753 x 562mm) Support Rail x 2 ( 362 x 38mm) Seat x 1 Support Rail x 2 420 x 330mm) ( 285 x 38mm) Support Rail x 2 ( 195 x 50mm)
- Page 5 M6x50mm Bolt x 4 M6x25mm Bolt x 8 Spring Washer x 4 Flat Washer x 4 M6x50mm Screw x 8 Ø25mm Felt pad x 4 M4 Alley Key x 1 M6x50mm Screw x 8 M4 Alley Key x 1 Warning! Please do not fully tighten the bolts in this step.
- Page 6 Spring Washer x 4 Flat Washer x 4 M6x50mm Bolt x 4 M6x25mm Bolt x 8...
- Page 7 Ø25mm Felt Pad x 4 Peel off the back Warning! Please do fully tighten all the bolts and screws in this step. Turn Product Assembly is complete.
