  • Page 1 IN230900344V01_GL IN230900344V01_GL_845-953V00...
  • Page 11 PARTS LIST PART. Qty. PART. Qty. PART. Qty. CW4-3 CW4-1 SG10 SG7-2 CW3L SG101 SG7-1 SG102 CR1-2 CW2-2 SG103 CF1-2 CR1-1 CR1-3 CW1-2 SG12 CF1-1 Drill CW1-1 CW2-1 SG13 CW3-1 SG14 CW1-3 SG15 CW1-4 Z410 CA1R CD1-4 Z420 CD1-1 CA1L Z425 CD1-6 ZW413...
  • Page 12 EN_Use spatula (part"SG8") for easier insertion of panel into profile FR_Utiliser la spatule (pièce "SG8") pour faciliter l'insertion du panneau dans le profilé. ES_Utilice una espátula (pieza "SG8") para facilitar la inserción del panel en el perfil. PT_Utilizar uma espátula (peça "SG8") para facilitar a inserção do painel no perfil DE_Spachtel (Teil "SG8") zum leichteren Einsetzen der Platte in das Profil verwenden...
  • Page 13 Step 1 CF1-1 2 PC CF1-1 CF1-1...
  • Page 14 Step 2 1 PC 1 PC 1 PC CF1-1 CF1-1 Step 3 CF1-2 1 PC CF1-1 CF1-2...
  • Page 15 Step 4 1 PC 1 PC CF1-2 Step 5 CF1-1 CF1-1 CF1-2...
  • Page 16 Step 6 2 PC 2 PC SG7-2 1 PC SG7-2 SG7-1 1 PC SG7-1 1 PC Step 7...
  • Page 17 Step 8 Z410 4 PC Step 9...
  • Page 18 Step 10 Z420 21 PC Step 11...
  • Page 19 Step 12 1 PC...
  • Page 20 Step 13 CW1-1 1 PC CW1-2 CW2-1 CW1-1 1 PC CW1-3 1 PC CW2-1 2 PC CW2-2 CW2-2 CW1-3 1 PC CW2-1 CW1-2 CW2-1 CW1-1...
  • Page 21 Step 14 Step 15 Z420 8 PC...
  • Page 22 Step 16 CPA2 1 PC CPA2 Step 17 CW2-1 2 PC CW2-2 1 PC CW2-2 CW2-1 CW2-1...
  • Page 23 Step 18 1 PC Step 19 CW1-4 1 PC CW1-1 2 PC CW1-4 CW1-1 CW1-1...
  • Page 24 Step 20 Step 21 Z420 8 PC...
  • Page 25 Step 22 CPA1 1 PC CPA1 Step 23 1 PC CW4-1 CW4-1 1 PC Z410 2 PC...
  • Page 26 Step 24 AB=CD...
  • Page 27 Step 25 Z410 16 PC Step 26 2 PC...
  • Page 28 Step 27 CW3-1 CW3-1 CW3-1 4 PC CW3-1 CW3-1 Step 28 CW3L 1 PC CW3R CW3L CW3R 1 PC CW3-1 CW3-1...
  • Page 29 Step 29 CA1L 1 PC CA1R 1 PC Z410 CA1L CA1R 2 PC Step 30 1 PC...
  • Page 30 Step 31 CW4-3 1 PC 1 PC Z410 CW4-3 2 PC Z410 Step 32 CW4-3+BY...
  • Page 31 Step 33 ZW413 6 PC SG12 2 PC SG12 CA1R SG12 CA1L ZW413 ZW413 Step 34...
  • Page 32 Step 35 Z420 32 PC...
  • Page 33 Step 36 SG10 1 PC SG10 Step 37 Remove the film before fixing SG101 SG10 SG101 SG101 SG101 Need two persons to fix SG101, 1 PC one person presses it, and the other person assembles it.
  • Page 34 Step 38 SG102 The press plate boss section shall be pressed against SG101 Press tightly to avoid falling down 2 PC Please note the side with bending edge be pressed to SG101 SG103 It's better to fix just one screw on each SG102&SG103 before each one adjust into right location.
  • Page 35 Step 40 CR1-1 1 PC CR1-3 CR1-3 1 PC CR1-1...
  • Page 36 Step 41 1 PC 1 PC CR1-3 CR1-1 1 PC Step 42 CR1-2 CR1-1 1 PC CR1-2 CR1-1 CR1-3...
  • Page 37 Step 43 CR1-2 1 PC 1 PC 1 PC Step 44 2 PC 2 PC...
  • Page 38 Step 45 Z410 8 PC Step 46...
  • Page 39 Step 47 Z420 26 PC The distance from the profile edge to the first screw is about 40mm. Z420 Step 48...
  • Page 40 Step 49 Step 50 Z420 18 PC...
  • Page 41 Step 51 Z425 4 PC 2 PC DOOR SECTION Door mount this is above outside...
  • Page 42 CD1-1 CD1-2 Step 52 1 PC 1 PC CD1-4 CD1-5 1 PC 1 PC CD1-3 CD1-4 CD1-5 1 PC CD1-6 CD1-6 CD1-1 CD1-2 1 PC CD1-3 5 PC CD1-4 CD1-5 CD1-6 CD1-1 CD1-2 CD1-3...
  • Page 43 Step 53 CA2R 1 PC CD1-4 CA2R 1 PC CD1-5 CA2L CD1-6 CD1-1 CD1-2 1 PC CD1-3 CA2L 1 PC Step 54 1 PC 1 PC CD1-1 CD1-2 CD1-3...
  • Page 44 Step 55 1 PC CD1-4 1 PC CD1-5 CD1-6 Step 56...
  • Page 45 Step 57 Step 58 ZW413 20PC...
  • Page 46 Step 59 2 PC Z410 CD1-1 8 PC CD1-2 CD1-3 Z410 Z410 Step 60...
  • Page 47 Step 61 M03-6L M03-6L M03-6L 1 PC M03-7 M03-7 M03-7 1 PC M03-7 M03-6L Step 62 Z410 12 PC Z410 Z410 CD1-4 4 PC CD1-5 CD1-6 CD1-1 CD1-2 1 PC CD1-3 Z410...
  • Page 48 Step 63 Z410 20 PC CD1-1 CD1-4 CD1-2 CD1-5 CD1-3 CD1-6 Step 64 ZW413 2 PC 1 PC ZW413...
  • Page 49 Step 65 SG14 2 PC SG13 SG13 Z410 SG14 2 PC SG15 Z410 SG15 2 PC Z410 Z410 8 PC Step 66 LOCK 1 PC LOCK...
  • Page 50 PARTS SCHEMATIC CR1-2 CR1-1 CR1-3 CR1-1 CW4-1 SG14 CPA1 CW1-4 CW2-2 SG15 SG13 SG15 CW2-2 CW2-1 CW1-1 CPA2 CW2-1 CW2-1 CW1-1 CW2-1 CW4-3 SG13 CW3R SG12 SG12 CW3-1 CW3L CA1R SG14 CW3-1 CW3-1 CA1L CW1-3 SG10 SG102 SG101 SG103 CW3-1 SG103 CW1-2 SG102...
