Summary of Contents for third coast equipment RS35
- Page 1 Soil Roller RS35 Operator’s Manual thirdcoastequipment.com...
- Page 2 ©2024 by Third Coast Equipment, Inc. All rights reserved. All trademarks referenced in this manual are the property of their respective owners. No portion of this manual may be reproduced without written permission from Third Coast Equipment, Inc. To reduce the risk of injury, all operators and maintenance personnel must read and understand their machine’s instruction manual in full before operating, changing accessories, or performing...
-
Page 3: Table Of Contents
CONTENTS Introduction Applications Safety Labeling Hazards & Risks California Proposition 65 Warning General Hazards & Risks Transportation Hazards Mechanical Hazards Fire, Explosion & Thermal Hazards Chemical Hazards Noise Hazards Personal Protective Equipment & Human Health Hazards Additional Hazards Operation Familiarization with the Soil Roller & its Components Joystick Control Operation Daily Pre-Operation Inspection Starting the Roller... -
Page 5: Introduction
INTRODUCTION Thank you for your purchase of this Third Coast Equipment, Inc. (“Third Coast”) soil roller. Please read this operator’s manual in its entirety prior to using your new machine. This manual provides information pertaining to the safe use, proper operation, and routine maintenance of this machine. -
Page 6: Safety Labeling
Suggest every year or every 500 hours to change hydraulic oil and filter. Suggest using ISO12922 and ISO6743-4 Soil Roller RS35 definition of the hydraulic oil. For a temperate climate, it is recommended to use HV46 or HV68. When change the hydraulic oil, please change entirely. - Page 7 MACHINE LABELS LABEL INTERPRETATION Soil Roller RS35 NAMEPLATE: Lists important information lbs. 7250 3288 about the machine including model, serial Serial No. Manuf. Yr. 2024 3CECT48H225808 THIRD COAST EQUIPMENT, Inc. number, and other information. New Berlin, WI USA www.thirdcoastequipment.com TIE DOWN: This label identifies safe tie- down points for securing the machine for transport.
-
Page 8: Hazards & Risks
LABEL INTERPRETATION READ THE MANUAL: This label instructs the operator to read the manual prior to operating the machine. BATTERY DISCONNECT: This label indicates the location of the battery disconnect switch. HAZARDS & RISKS CALIFORNIA PROPOSITION 65 WARNING Use of this product may expose you to certain chemicals, including diesel engine exhaust, which are known to the State of California to cause cancer. -
Page 9: Mechanical Hazards
MECHANICAL HAZARDS Certain mechanical hazards are inherit in operating this machine due to the weight, operation, travel, and vibration of this machine. Disregarding these warnings can lead to serious injury. Do not operate this machine unless all protective guards are in place. Keep hands and feet clear of rotating and moving parts. -
Page 10: Noise Hazards
Do not refuel this machine in confined spaces. Diesel vapors may be hazardous to your health, and concentrated vapors may cause an explosive atmosphere. Any fluids spilled from the machine, whether flammable or not, must be cleaned up in a manner consistent with all local environmental regulations. -
Page 11: Operation
OPERA TION FAMILIARIZATION WITH THE SOIL ROLLER & ITS COMPONENTS Prior to operating this soil roller, it is important to be aware of the critical components, safety features, and safe operating procedure of this machine. BATTERY DISCONNECT SWITCH The battery disconnect switch manually disconnects power from the battery to the roller. -
Page 12: Joystick Control Operation
JOYSTICK CONTROL OPERATION The joystick controls fore/aft travel, engages and disengages the compaction exciters, and raises or lowers the dozer blade (if Exciters ON/OFF equipped). Unless actively moving the roller forward or backwards, Dozer the joystick should remain in the neutral position, indicated by an Raise/Lower “N”. -
Page 13: Dpf Regen
the low speed ( ) position to the high speed ( ) position, or anywhere between as desired. As a general rule of thumb, drive speed and compaction force will increase with increased RPM. DPF REGEN If required, the DPF Bypass Regen feature may be activated. See the “Diesel Particulate Filter Regen”... -
Page 14: Tips For Proper Compaction
TIPS FOR PROPER COMPACTION Soil rollers are fast, efficient tools for compacting a wide variety of substrates. The chief concern when operating a roller is safety, and several precautions should be followed during operation. First, walk the jobsite prior to starting your equipment to make sure it is free of people, foreign objects, obstructions, trip hazards, and other obstacles that may impede operation or cause a safety concern. -
Page 15: Extended Storage
EXTENDED STORAGE Following proper long-term storage procedures ensures the machine is ready to operate when you return to it. The following procedures should always be performed when the machine will not be in use for the next 30 days: Thoroughly clean the exterior of the machine with a damp rag, then dry it. Do not use solvents. Check and repair any leaks and tighten any loose hardware prior to storage. -
Page 16: Care & Preventative Maintenance
CARE & PREVENT A TIVE MAINTENANCE Third Coast soil rollers are designed to provide years of trouble-free service, but as with all power equipment, periodic maintenance is required to keep this machine running smoothly. Maintenance is a normal part of ownership of any machine, and must be carried out on time per the prescribed intervals or sooner, as needed. -
Page 17: Engine Inspection & Maintenance Tables
WEEKLY OPERATIONAL CHECKS After each week of operation, or each 40 hours, whichever occurs first: Grease the articulation joint (both top and bottom pins) with NLGI No. 2 synthetic multipurpose grease. Grease the steering cylinder (both ends) with NLGI No. 2 synthetic multipurpose grease. MONTHLY OPERATIONAL CHECKS After each month of operation, or each 200 hours, whichever occurs first: Inspect the scraper bars for wear and cracks. -
Page 18: Tightening Torque Tables
TIGHTENING TORQUE TABLES The threaded fasteners on this machine are all right handed, coarse-thread, metric, Class 8.8 or Class 12.9 fasteners. All fasteners on this machine are marked by strength class and must be torqued to the proper specification for that class. To identify whether a fastener is a Class 8.8 or Class 12.9 fastener, check the identifying marks stamped on the head. -
Page 19: Specifications
SPECIFICA TIONS MACHINE SPECIFICATIONS TABLE 5: SOIL ROLLER SPECIFICATIONS DIMENSIONS & WEIGHT Wheelbase (“A”) 71 in Drum Width (“B”) 47.2 in Overall Length (“C”) 131 in Drum Diameter (“D”) 47.2 in Overall Width (“E”) 53 in Height, ROPS Folded (“H1”) 74 in Height, ROPS Extended (“H2”) 108 in... -
Page 20: Engine Specifications
Danfoss hydraulic exciter motor Hydraulic dozer blade Comfort all-weather awning kit Folding ROPS with seat belt Working lights Strobe & reverse beacons Mirrors Contact your Third Coast Equipment dealer for more information on accessories. Drum scrapers TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE SOLUTION Engine does not start Battery disconnect is in OFF position. - Page 21 SYMPTOM POSSIBLE CAUSE SOLUTION Engine does not start; Low engine oil. Check oil level and refill as needed. it turns over but will Low fuel level or bad fuel. Check fuel level and age of fuel. not maintain operation. Inadequate glow plug cycle time. Cycle glow plugs for five seconds, and try starting engine again.
-
Page 22: Wiring & Hydraulic Diagrams
WIRING & HYDRAULIC DIAGRAMS WIRING DIAGRAM... -
Page 23: Warranty
HYDRAULIC DIAGRAM WARRANTY Third Coast Equipment stands behind all of its products with a best in class warranty, including: Five-year warranty on spare parts WARRANTY Four-year warranty on Vanguard engines Three-year warranty on Honda engines Two-year warranty on labor year This limited warranty contains certain exclusions and limitations and is restricted to repair or replacement of the machine or affected parts only. - Page 24 3CE Dealer Card Third Coast Equipment, inc. New Berlin, WI RS35-OM-01 thirdcoastequipment.com...
