- Page 1 OPERATOR'S MANUAL TAMPING RAMMER PR40 / PR60 / PR70 R e v i s i o n 2 . 2 3 . 2 4 w w w . t h i r d c o a s t e q u i p m e n t . c o m...
- Page 2 To reduce the risk of injury, all operators and maintenance personnel must read and understand these instructions before operating, changing accessories, or performing maintenance on Third Coast Equipment machines. All possible situations cannot be covered in these instructions. Care must be exercised by everyone using, maintaining, or working near this equipment.
-
Page 3: Table Of Contents
Table of Contents 1. SAFETY INFORMATION. …………………………………………………………………. 3 1.1 Safety Precautions …………………..……………………………………………………3 1.2 Operating Safety…………………………………………………………………………...4 1.3 Operator Safety while using Internal Combustion Engines…………………..………..5 1.4 Service Safety ……………………………………………………………………..……….6 1.5 Label Locations………………………………………………………………..……………7 1.6 Safety Labels………......……………………….…………………………..8-9 1.7 Operating Labels………....……………………….…………………………...10 2. OPERATION ………………………………………………………...….…………………..11 2.1 Application…………………………………………………………….…...…………………….11 2.2 Before Starting……………………………………………………...………….……...………..11 2.3 To Start …………………………………………………………….………….………..….……12... -
Page 4: Safety Information
SAFETY INFORMATON 1.1 Safety Precautions This operator's manual provides information pertaining to the safe and proper operation of this machine. All operators must read this manual in full prior to operation or transportation of this machine. This manual contains DANGER, WARNING, CAUTION callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. -
Page 5: Operating Safety
SAFETY INFORMATON 1.2 Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions and familiarize yourself with the location and proper use of all instruments and controls. -
Page 6: Operator Safety While Using Internal Combustion Engines
SAFETY INFORMATON 1.3 Operator Safety while using Internal Combustion Engines DO NOT smoke when refueling the engine or during any other fuel handling operation. DO NOT refuel a hot or running engine. DO NOT refuel the engine near an open flame. ... -
Page 7: Service Safety
ALWAYS keep area around muffler free of debris. ALWAYS conduct Periodic Maintenance as recommended in Operation Manual. ALWAYS clean debris from engine cooling fins. ALWAYS replace worn or damaged components with Third Coast Equipment recommended spare parts. -
Page 8: Label Locations
SAFETY INFORMATION 1.5 Label Locations... -
Page 9: Safety Labels
SAFETY INFORMATION 1.6 Safety Labels This machine uses international pictorial labels where required. These labels are described below: Label Meaning This model-in label contains important safety and operating information. If it becomes illegible, the cover must be replaced. Reger to the Parts Manual for ordering information. - Page 10 SAFETY INFORMATION Meaning Label CAUTION! For optimal control, performance, and minimal hand/arm vibration, grasp handle as shown. WARNING! Serious injury if struck by compressed spring or cover. If the spring system cover is removed improperly, the springs can eject. Guaranteed sound power level in dB(A). A nameplate listing the model number and serial number is attached to each unit.
-
Page 11: Operating Labels
SAFETY INFORMATION 1.7 Operating Labels This machine uses international pictorial labels where needed. These labels are described below: Start the engine: Turn the engine switch to the ON position Close the choke. Pull the rewind starter. Open the choke. Stop the engine: Turn the engine switch to OFF position. -
Page 12: Operation
OPERATION Operation 2.1 Application Rammers are designed to compact various types of soil and clay to prevent settling and provide a solid base for the placement of footings, concrete slabs, foundations, gas lines, utility piping, etc. Do not use in the following applications or scenarios as the rammer is likely to become unbalanced and may cause operator injury or machine damage. -
Page 13: To Start
OPERATION 2.3 To Start 1. Slide the throttle lever from stop to the idle position. 2. Open the fuel shut-off valve by moving the fuel cock lever to the open position. 3. If starting the engine from cold, set the choke to the "CLOSED" position (If restarting a warm engine, the choke is usually not required.) 4. -
Page 14: Operation
OPERATION 2.4 Operation 1. Allow engine to run for 5 minutes at low speed to warm the engine. 2. Move the throttle lever quickly to the “FULL OPEN” position. DO NOT move the throttle level slowly as this may cause damage to the clutch or spring. Make sure that the throttle lever is moved to the FULL OPEN position. -
Page 15: Maintenance
MAINTENANCE 3 MAINTENANCE 3.1 Periodic Maintenance Schedule The chart below lists basic maintenance. Refer to engine manufacturer’s Operator’s Manual for additional information on engine maintenance. A copy of the engine Operator’s Manual was supplied with the machine when it was shipped. Daily After Every... -
Page 16: Transporting
MAINTENANCE 3.2 Transporting 1. Shutdown engine prior to transportation or lifting. 2. Tighten fuel tank cap securely and close fuel cock to prevent fuel leaks. 3. For long distance transportation it is recommended to drain the fuel tank. 4. Ensure lifting equipment is adequately rated for rammer weight (see identification plate on machine for weight). -
Page 17: Air Cleaner
MAINTENANCE 3.4 Air Cleaner Maintaining a clean engine will extend engine life. Keep air filter clean at all times. Clean air filter using the recommended solvent daily. See engine manual for proper cleaning procedure. Let the filter dry before reinstalling. NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner. - Page 18 MAINTENANCE 3.6.2 Engine Troubleshooting SYMPTOM POSSIBLE CAUSE SOLUTION Difficult to start Ignition plug being bridging? Check ignition system. Clean or replace Fuel is available but Carbon deposit at ignition? ignition. spark plug will not ignite.(Power Short circuit due to deficient available at high Replace insulators.
- Page 19 MAINTENANCE SYMPTOM POSSIBLE CAUSE SOLUTION Operation not satisfactory Air cleaner clogged? Clean or replace air cleaner. Not enough power Bleed (remove air) from fuel Air in fuel line? available line. (compression Fuel level in carburetor float normal, no Adjust carburetor float. chamber improper? missfiring) Carbon deposit in cylinder?
-
Page 20: Technical Data
TECHNICAL DATA 4. TECHNICAL DATA Sound Specification (According to 2000/14/EC) Measured sound Power level 105 dB(A) Guaranteed sound power level 108 dB(A) Hand-Arm vibration Specification (According to ISO 5394, EN 1033 and EN500-4): 8.0m/s... -
Page 21: Warranty
Preventative maintenance and routine service are essential to the long life of your tamping rammer. Please refer to your local Third Coast Equipment dealer for all OEM spare parts and service needs. For your convenience we have provided this space to record relevant data about your tamping rammer.
