Alldaq ADQ-LB-BB System Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XXXXX
ADQ-LB-BB System Rev. 1.0 EN
Manual
Ver. 1.0
EN
ADQ-LB-BB System
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADQ-LB-BB System and is the answer not in the manual?

Questions and answers

Related Manuals for Alldaq ADQ-LB-BB System

Summary of Contents for Alldaq ADQ-LB-BB System

  • Page 1 XXXXX ADQ-LB-BB System Rev. 1.0 EN Manual Ver. 1.0 ADQ-LB-BB System...
  • Page 2 ADQ-LB-BB System Rev. 1.0 EN Imprint Handbuch ADQ-LB-BB System Rev. 1.0 Manufacturer and support ALLNET® and ALLDAQ® are registered trademarks of ALLNET® GmbH Computersysteme. For questions, problems and product information, please contact the manufacturer directly: ALLNET® GmbH Computersysteme Division ALLDAQ...

  • Page 3: Table Of Contents

    Contents ADQ-LB-BB System Rev. 1.0 EN Contents 1. Introduction 1.1 Scope of delivery 1.2 Safety instructions 1.3 Installation and mounting location 1.4 Brief description 1.5 System requirements 2. Overview of the system 2.1 Block diagram 2.2 ADQ-LB-BB 2.3 Connector and pin assignment 2.4 ADQ-LB-BM 2.0...

  • Page 4: Introduction

    ALLDAQ ADQ-LB-BB (control unit with ADQ-Link) for ADQ-LB-BM 2.0 • ALLDAQ ADQ-LB-BM 2.0 carrier board for ADQ-LB-LM/VLM modules • ALLDAQ ADQ-LB-LM (load module)ALLDAQ ADQ-LB-VLM (variable load module) • ALLDAQ ADQ-LB-MB for mechanical mounting of the ADQ-LB-LM/VLM modules on the ADQ- LB-BM carrier board (optional). ADQ-LB-BM carrier board (optional)
  • Page 5 Introduction ADQ-LB-BB System Rev. 1.0 EN 1.2 Safety instructions Please observe the following instructions: • Never expose the device to direct sunlight during operation. • Never operate the device near heat sources. • Protect the device from moisture, dust, liquids and vapors.
  • Page 6 The relevant installation regulations and standards must be observed. The ADQ-LB-BB system may only be used in dry rooms. Ensure adequate heat dissipation. Make sure the connection cables are secure. The installation must be carried out in such a way that the cables are not under tension, otherwise they could come loose.
  • Page 7 Optional ALLDAQ driver Software On the ALLDAQ homepage you will find drivers for Windows 11/10/8.1/8/7 (32 and 64 bit) as well as a function library (API) with code examples for high-level language programming. Please note the information in the associated help file adqSDK.chm. You can also find details about programming in the help file adqDriver.chm, which you can access via the “ALLDAQ Manager”...

  • Page 8: Overview Of The System

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2. Overview of the system 2.1 Block diagram ± AI-Line-Out +K0_DUT -K0_DUT ± AI-Line-Out/U-Ref K0..7 ADQ-LB-BM 2.0 U-Ref +K0_SCU LM_1 LM_0 Load channels -K0_SCU max. ± 51,2Vrms ADQ-SCU-(LC-)BB max. 10A peak or analog data acquisition system ±...

  • Page 9: Adq-Lb-Bb

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2.2 ADQ-LB-BB If you do not use all ADQ-LB-BM 2.0, you can use the free openCollector switching outputs (default upon delivery). 6x ADQ-LB-BM 2.0 Carrier module for ADQ-LB-LM/VLM modules 80p. Connector for ADQ-LB-BM 2.0...

  • Page 10: Connector And Pin Assignment

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2.3 Connector and pin assignment Specifications (ST1) and (ST2) The ADQ-LB-BB can be controlled via the ADQ-LINK via this connector. ADQ-LINK-IN (point to point): ST1 • Overvoltage protection of the cables up to ± 60 V / ADQ devices can be deployed up to 100 m (twisted cable) •...
  • Page 11 Function groups ADQ-LB-BB System Rev. 1.0 EN U-Ref (ST3) and (ST5) The adjustment voltage for ADQ-SCU-(LC-)BB) can be connected via this connector. Description GND_PC PC ground U-Ref (P) +U-Ref U-Ref (N) -U-Ref Würth 3-pin (691305130003) Mating plug (691305130003) Description U-Ref (P)
  • Page 12 Function groups ADQ-LB-BB System Rev. 1.0 EN Connector plug (STB_BM 0..5) Note: Pin description of the connection plug (STB_BM0..5) between the ADQ-LB-BB and the ADQ- LB-BM 2.0 is only relevant when using a customer-specific add-on board instead of the ADQ-LB-BM All control signals are exchanged between the ADQ-LB-BB and the ADQ-LB-BM 2.0 via this connec-...
  • Page 13 Function groups ADQ-LB-BB System Rev. 1.0 EN Description Description Type Type Circuit diagram Circuit diagram POWER BMx_FREE3 Output (relay driver) POWER not occupied POWER BMx_FREE4 Output (relay driver) POWER not occupied Mx_Sense_1 LM/VLM Modul-ID-Spannung BMx_FREE5 Output (relay driver) Mx_Sense_0 LM/VLM Modul-ID-Spannung...

  • Page 14: Adq-Lb-Bm

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2.4 ADQ-LB-BM 2.0 Carrier module for the ADQ-LB-LM/VLM modules. Carrier module for the ADQ-LB-LM/VLM modules. ADQ-LB-MH Module holder for ADQ-LB-LM (item no. 189126) Module holder for ADQ-LB-LM (item no. 189126)

  • Page 15: Connector And Pin Assignment

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2.4.1 Connector and pin assignment Fan connection (FAN0) and (FAN1) FANO/FAN1 Description +12V_PC Power supply Switching ou Type: Open Collector Würth 2-pin (691305130002) (GND_PC) Negative pole from a 12VDC fan (Imax. 0.5A)g Mating plug (691305130002) ±...
  • Page 16 Function groups ADQ-LB-BB System Rev. 1.0 EN Load channel connections (ST1) and (ST2) Typ: Phoenix Contact (1792795) Mating plug (1792575)

  • Page 17: Adq-Lb-Lm

    Function groups ADQ-LB-BB System Rev. 1.0 EN 2.5 ADQ-LB-LM Load modules with the corresponding load resistors (see table). Load modules with the corresponding load resistors (see table). Item no. CH_0 (4) CH_1 (5) CH_2 (6) CH_3 (7) ID Label ID Voltage(U)
  • Page 18 Function groups ADQ-LB-BB System Rev. 1.0 EN 2.5.1 ADQ-LB-VLM Variable load module with the corresponding load resistors (see table). Status LOAD-LEDs Status LOAD-LEDs Art.-Nr. CH_0 CH_1 ID Label ID Voltage(U) ID0325 0,325 219051 1R to 8R 1R to 8R ID11 For customized modules Slot (ADQ-LB-BM 2.0)
  • Page 19 Function groups ADQ-LB-BB System Rev. 1.0 EN Technical specifications VLM module (1R to 8R). Ω V peak max I peak max Pmax 1Ω 100W 2Ω 200W 3Ω 21,21V 7,07A 150W 4Ω 28,28V 7,07A 200W 5Ω 125W 6Ω 150W 7Ω 175W 8Ω...
  • Page 20 ADQ-LB-BB System Rev. 1.0 EN Fan for ADQ-LB-LM modules Fan for ADQ-LB-LM/VLM modules (item no. 189213) 3. ALLDAQ I2C Board Control Center To get to know the operation of the ADQ-LB-BB, there is the I2C Board Control Center in the ALLDAQ Launcher under Tools.
  • Page 21 Control via the ALLDAQ driver system ADQ-LB-BB System Rev. 1.0 EN...
  • Page 22 Specifications ADQ-LB-BB System Rev. 1.0 EN 4. Specifications Conditions: TA = 25°C unless otherwise specified; warm-up time: 30 minutes. Element Condition Specification Supply +5 V / +12 V supply via Würth connector from PC power ADQ-LINK-IN supply unit Frequency 100kHz...
  • Page 23 Specifications ADQ-LB-BB System Rev. 1.0 EN Humidity Operation 20%..55% (non-condensing) Dimensions ADQ-LB-BB 465 x 170 x 20 mm (W x D x H) ADQ-LB-BM 2.0 115 x 76 x 49 mm Total height 180 mm (VLM module plugged in) Total height 145 mm (LM module plugged in) Manufacturer‘s warran-...

  • Page 24: Adq-Lb-Lm

    Specifications ADQ-LB-BB System Rev. 1.0 EN ADQ-LB-LM module Element Condition Specification Quantity/Type 4 changeover relays (DPDT), type: Finder Series 40.62 Contact material AgNi Operating time Response time max. 12 ms Fallback time max. 4 ms Switch cycles mechanical min. 10.000.000 Electrical service life min.
  • Page 25 Specifications ADQ-LB-BB System Rev. 1.0 EN ADQ-LB-VLM module Element Condition Specification Quantity/Type 2 changeover relays (DPDT), type: Finder Series 40.62 Contact material AgNi Operating time Response time max. 12 ms Fallback time max. 4 ms Switch cycles mechanical min. 10.000.000 Electrical service life min.

  • Page 26: Accessories

    ADQ-63 (item no. 188372), ADQ-LINK bus control box • ADQ-153 (Art. No. 185076), control box USB to ADQ-LINK bus • ALLDAQ ADQ-LB-MH (item no. 189126), for mechanically attaching the ADQ-LB-LM/VLM mo- dules to the ADQ-LB-BM 2.0 carrier board • Fan for ADQ-LB-LM/VLM modules (item no. 189126) 5.2 Manufacturer and support...

  • Page 27: Recycling Notice And Rohs Conformity

    If you have any questions or problems with the application, you can reach us during our normal opening hours on the following telephone number +49 (0)89 894 222 - 474 or by e-mail to: support@alldaq.com.
  • Page 28 ALLNET® GmbH Computersysteme Division ALLDAQ Maistrasse 2, D-82110 Germering E-Mail: support@alldaq.com Phone: +49 (0)89 894 222 – 474 Fax: +49 (0)89 894 222 – 33 Internet: www.alldaq.com...
