List of E-Bike Component Names
31
22
19
20
17
21
18
Fig. 1 Electric Bicycle
1. Tires & Tubes
2. Rims
3. Spokes
4. Front Hub with QR
5. Front Fork
6.
Front Mechanical Disk Brake
7. Front Mudguard (Fender)
8.
Shift Lever & Brake Lever
9. Handlebar & Stem
10. Bell
11. Frame
12. Pedal
13. Chainwheel/Crankset
14. Chain Cover
15. Seat Clamp
16. Seat Post
1
29
27
25
09
26
08
16
28
10
15
30
23
14
32
13
12
11
07
17. Chain
18. Rear Derailleur
19. Rear Motor Hub
20. Freewheel
21. Kickstand
22. Rear Mudguard (Fender)
23. Rear Carrier
24. Battery
25. Grip
26. Shift Lever & Brake Lever 27
27. Throttle
28. Brake, Shift & Display Cables
29. Display
30. Front Light
31. Rear Light
32. Mudguard (Fender) Stay
Before your first ride
We strongly recommend taking your bike to a local bike shop after assembling
so a professional, reputable bike mechanic can check your work and perform all
necessary safety checks prior to the first ride. To find a Retrospec dealer near
you, please visit https:/ /retrospec.com/pages/store-locator.
Please keep these instructions for future use & reference. Do not discard.
Congratulations on your purchase of this Retrospec electric bike! We make sure
all of our e-bikes have been carefully designed and manufactured to the latest
international quality standards.Please read this instruction manual carefully
and thoroughly before riding. It contains important information on safety, and
maintenance and it's the owner's responsibility to read this manual before riding
and keep it for future reference.
05
06
This user's instruction manual includes two sections:
04
SECTION I - Mechanical Operation, and SECTION II - Electric Operation.
03
These instructions apply to electric bike models with following equipment:
02
01
Section I:
Mechanical Components Operation • Derailleur with Disc Brakes
For mechanical equipment, an electric bicycle differs only slightly from a
non-electric bike.
Section II:
Electrical Components Operation
• The battery-pack mounted on the down tube
•
The motor in the rear wheel hub
• The controller box is inside the frame
• Handlebar-mounted Display Panel operations.
