Summary of Contents for Bush DLED49287FHD
- Page 1 Instruction Manual DLED49287FHD...
-
Page 2: Table Of Contents
Contents Support ..............6 Environmental Information........7 Features ..............7 Accessories Included..........7 Standby Notifications ..........7 TV Control Switch & Operation.......8 Inserting the Batteries into the Remote ....8 Connect Power ............8 Antenna Connection ..........8 Notification ..............8 Disposal information ..........9 Specification ............9 Remote Control ............10 Connections............ - Page 3 Important safety precautions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to CAUTION alert the user to the presence of uninsulated “dangerous voltage” within the product’s RISK OF ELECTRIC SHOCK enclosure that may be of sufficient magnitude DO NOT OPEN to constitute a risk of electric shock of persons.
- Page 4 equipment. High temperatures can melt plastic and holding its neck, as this could result in damage to the lead to fires. plug. Do not unplug the appliance by pulling from the power cord and never touch the power cord with wet DON’T use makeshift stands and NEVER fix legs with hands as this could cause a short circuit or electric wood screws - to ensure complete safety always fit...
- Page 5 Wall Mounting (optional) NOTE: The TV set should be stored in a dry and • To prevent injury, this TV must be securely attached to dust-free room. the wall in accordance with the installation instructions Connection to a Television Distribution (if the option is available).
- Page 6 Symbols in this Instruction Book The following symbols are used in the Instruction Book as a marker for restrictions and precautions and safety instructions. Note such information for security reasons. WARNING If you do not pay attention to such a marked warning, it can cause serious injury or death.
-
Page 7: Support
Support Technical experts are available 7 days a week • Simple help and advice on setting up your digital equipment (image). • Guidance on connecting other devices to your television such as a DVD player, Sky, home cinema system or a games console. •... -
Page 8: Environmental Information
• AVL (Automatic Volume Limiting) Environmental Information • PLL (Frequency Search) This television is designed to be environment friendly. To reduce energy consumption, you can follow these • PC input steps: • Game Mode (Optional) If you set the Energy Saving to Minimum, Medium, •... -
Page 9: Tv Control Switch & Operation
Changing Channels and Volume TV Control Switch & Operation You can change the channel and adjust the volume by using the Volume +/- and Programme +/- buttons on the remote. Inserting the Batteries into the Remote Lift the cover on the back of the remote gently. Insert two AAA batteries. -
Page 10: Disposal Information
For DTS patents, see http://patents.dts.com. Specification Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol PAL BG/DK/II’ TV Broadcasting together are registered trademarks, and DTS SECAM BG/DK 2.0+Digital Out is a trademark of DTS, Inc. DTS, Inc. -
Page 11: Remote Control
Remote Control Standby: Switches On / Off the TV TV: Displays channel list / Switches to TV Source Volume +/- Menu: Displays TV menu OK: Confirms user selections, holds the page (in TXT mode), views channel list (DTV mode) Back/Return: Returns to previous screen, opens index page (in TXT mode) No function My button 1 (*) -
Page 12: Connections
Connections Connector Type Cables Device NOTE: When connecting a device via the YPbPr or Side Scart AV input, you must use the Connection connection cables to enable (back) connection. See the illustrations on the left side. | You can use YPbPr to VGA cable (not supplied) to enable YPbPr signal via VGA Connection... -
Page 13: Switching On/Off
Press OK button on the remote control to continue. Switching On/Off After the initial settings are completed TV will start To Switch the TV On to search for available broadcasts of the selected Connect the power cord to a power source such as a broadcast types. -
Page 14: Cec And Cec Rc Passthrough
Note: The audio device should support System Audio Control Loop/Shuffle Mode Operation feature and CEC option should be set as Enabled. All files in the list will be Start playback with the Play E-Manual continuously played in original button and activate You can find instructions for your TV’s features in order the E-Manual. -
Page 15: Tv Menu Contents
TV Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode Mode can be set to one of these options: Cinema, Game, Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen. - Page 16 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
- Page 17 System - Settings Menu Contents Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options.
- Page 18 Installation Menu Contents Automatic Displays automatic tuning options. Digital Aerial: Searches and stores aerial DVB stations. channel scan Analogue: Searches and stores analogue stations. (Retune) Manual This feature can be used for direct broadcast entry. channel scan Network Searches for the linked channels in the broadcast system. Digital Aerial: Searches for aerial channel scan network channels.
-
Page 19: General Tv Operation
Note: Default PIN can be set to 0000 or 1234. If you have General TV Operation defined the PIN(is requested depending on the country selection) during the First Time Installation use the PIN that Using the Channel List you have defined. The TV sorts all stored stations in the Channel List. -
Page 20: Teletext Services
Event Options Note: Do not unplug the power cord while led is blinking during the reboot process. If the TV fails to come on after the Use the directional buttons to highlight an event and upgrade, unplug, wait for two minutes then plug it back in. press OK button to display Event Options menu. -
Page 21: To Program Your Sky Remote For Your Tv
To Program Your SKY Remote For Your TV PC Input Typical Display Modes 1. Make sure your SKY box is connected to your TV The following table is an illustration of some of the typical video display modes. Your TV may not support 2. -
Page 22: Av And Hdmi Signal Compatibility
AV and HDMI Signal Compatibility Source Supported Signals Available SECAM NTSC4.43 (SCART) NTSC3.58 RGB 50/60 SECAM Side AV NTSC4.43 NTSC3.58 480i, 480p 60Hz 576i, 576p 50Hz YPbPr 720p 50Hz,60Hz 1080i 50Hz,60Hz 480i, 480p 60Hz 576i, 576p 50Hz 720p 50Hz,60Hz HDMI1 1080i 50Hz,60Hz HDMI2... -
Page 23: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Extension Video Codec SPEC (Resolution) & Bit Rate .dat, vob MPEG1/2 1080P@30fps - 40 Mbps MPEG1/2, .mpg, .mpeg MPEG4 MPEG1/2, H.264, H.264: 1080Px2@30fps - 62.5 Mbps, 1080P@60fps - 62.5 Mbps MVC: .ts, .trp, .tp 1080P@30fps - 62.5 Mbps Other: 1080P@30fps - 40Mbps AVS, MVC .mp4, .mov,... -
Page 24: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps .mp3, MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3... -
Page 25: Supported Subtitle File Formats For Usb Mode
Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps .wav LPCM 64Kbps ~ 1.5Mbps 8KHz ~ 48KHz IMA-ADPCM, 384Kbps 8KHz ~ 48KHz MS-ADPCM G711 A/mu-law 64Kbps ~ 128Kbps 8KHz MPEG1/2 Layer3... -
Page 26: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 þ 640x480 þ þ þ... -
Page 27: Guarantee
Guarantee Product Guarantee This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit. - Page 28 Product fiche Commercial Brand: BUSH Product No. 10100630 Model No. DLED49287FHD Energy efficiency class Visible screen size 49 inches / 124 cm (diagonal,approx.) (inch/cm) On mode average power 71 W consumption (Watt) Annual energy consumption 103 kWh (kWh/annum) Standby power consumption...
- Page 29 BUSH DLED49287FHD 50331673 Standby Power Consumption (approx.) 0,5 W Screen Resolution 1920 x 1080 English - 28 - For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105...
-
Page 30: Important Instructions
Important Instructions For your own safety read the following instructions carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN &... - Page 31 Home Retail Group 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes MK9 2NW...
