- Page 1 NICOLA RECTANGULAR DINING TABLE Assembly Guide (2 - Leaf Extension) HARDWARE LIST QTY (Pcs) PART PART DESCRIPTION HEXAGONAL BOLT M8 X 75 MM LOCK WASHER M8 PLAIN WASHER M8 SHOCK Y WRENCH 12 PAGE : 1 OF 4...
- Page 2 # Step 1 Place table top sub assy above the base sub assy as illustration below. TOP SUB ASSY BASE SUB ASSY # Step 2 Open the locks underneath and pull the HEXAGONAL BOLT ends apart, fully extended. LOCK WASHER Then tighten the hexagonal bolt, lock PLAIN WASHER washer, and plain washer with shock Y...
- Page 3 #Step 3 Place the extension leaf sub assy in the opening. LEAF SUB ASSY TOP SUB ASSY BASE SUB ASSY # Step 4 Slide the leaf sub assy to one end so that mating edges are tightly. Then, turn the lever of the table locks underneath to close position.
- Page 4 Do not strike the furniture with hard or pointed items. Frontgate: Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484 or email ps@frontgate.com. PAGE : 4 OF 4...
