- Page 1 ASSEMBLY INSTRUCTION ETIENNE CANOPY BED Item Number: Dimensions : 81.8'' X 87.3'' X 89.1'' inches Page 1 of 7...
- Page 2 Components & Hardware A. Headboard (1 pc) NOTE : TWO PEOPLE ARE RECOMMENDED FOR INSTALLATION PARTS INCLUDED IN CARTON 1 PART DESCRIPTION QTY (pc) PARTS INCLUDED IN CARTON 2 B. Footboard (1 pc) PART DESCRIPTION QTY (pcs) PARTS INCLUDED IN CARTON 3 PART QTY (pcs) DESCRIPTION...
- Page 3 Step 1. Screw Threaded Bolt (D) to Headboard (A) Step 2. Locate Sticker Signs found on Side Rail and Headboard and make sure they match. Align Female and Male Connectors and insert Side Rail (G) to Headboard (A). Step 3. Connect Round Washer (E) and Hex Nut (F) to Threaded Bolt (D) and tighten using Wrench provided (See Figure 1).
- Page 4 Step 5. Install Center Slat Support (I) to Headboard and Footboard. (See Figure 2) CENTER SLAT SUPPORT Figure 2. Step 6. Install slats (H). (See Figure 3) SLATS Figure 3. Page 4 of 7...
- Page 5 Step 7. Install Post (J) to Headboard and Footboard. (See Figure 4 & 5) POST Figure 4. POST Figure 5. Step 8. Install the Canopy (K) to Post (J). (See Figure 6) Figure 6. Page 5 of 7...
- Page 6 Step 9. Install Iron Corner (M) in the end of post and tighten the Canopy (K) and Post (J) with Allen Bolt (N),Flat Washer (O), and Lock Washer (P) using Allen Key (Q) (See Figure 7) Step 10. Install the Ornament (L) with turn clockwise the threaded axle until it fits perfectly (See Figure 8) Figure 7.
- Page 7 Clean dust on the furniture surface using a duster. Polish every six months. Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484 or email ps@frontgate.com. Specialists are available weekdays 8:00 AM to 8:00 PM EST or Saturdays 9:30 AM to 6:00 PM.
