Summary of Contents for Thor Kitchen TMD3002
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Safety Warnings Precautions To Avoid Possible Exposure To Excessive Microwave Energy Specifications Important Safety Instructions Grounding Instructions Radio Interference Utensils 2 Product Overview Setting Up Your Oven Clearances And Dimensions Microwave Drawer Measurements Normal Installation Steps Anti-tip Block Installation Instructions 3.4 Drawer Installation Model And Serial Number Location 3.6 Care,cleaning And Maintenance... -
Page 4: Safety Warnings
1 SAFETY WARNINGS 1.1 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY • Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. - Page 5 1 SAFETY WARNINGS • Install or locate this appliance only in accordance with the provided installation instructions. • Some products such as whole eggs and sealed containers - for example, closed glass jars - are able to explode and should not be heated in this oven. •...
-
Page 6: Grounding Instructions
1 SAFETY WARNINGS - Do not overheat the liquid. - Stir the liquid both before and halfway through heating it. - Do not use straight-sided containers with narrow necks. - After heating, allow the container to stand in the microwave oven for a short time before removing the container. -
Page 7: Radio Interference
1 SAFETY WARNINGS • A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. • Longer cord sets or extension cords are available and may be used if care is exercised in their use. - Page 8 1 SAFETY WARNINGS Utensil Test: • Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question. • Cook on maximum power for 1 minute. • Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
-
Page 9: Product Overview
1 SAFETY WARNINGS Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing. Metal twist ties May cause arcing and could cause a fire in the oven. -
Page 10: Clearances And Dimensions
3 PRODUCT INSTALLATION 3.1 CLEARANCES AND DIMENSIONS • Dimensions that are shown in Figure 1 must be used. Given dimensions provide minimum clearance. Locate electrical outlet in the shaded area in the upper left-hand corner of the cutout. See Figure 3 •... - Page 11 3 PRODUCT INSTALLATION Microwave Door Handle Assembly Instructions Bolt Bolt door handle Scheme of installation 1. Carefully remove the door handle from the packaging. Orientate it according to the provided diagram. Ensure that both screw holes on the handle are positioned close to the edge.
- Page 12 3 PRODUCT INSTALLATION Figure 2 Figures 1 and 2 contain many Microwave Drawer measurements for reference when planning the drawer's location .This Microwave Drawer can be installed below any electric or gas wall oven. *Can also be installed using an electrical outlet in an adjacent cabinet within the area where tire provided electrical cord can reach.
-
Page 13: Drawer Installation
3 PRODUCT INSTALLATION 3.3 NORMAL INSTALLATION STEPS ANTI-TIP BLOCK INSTALLATION To reduce the risk of tipping of the drawer, the Anti-Tip block must be properly 13/16- installed located 14 inches above the floor on which the Microwave Drawer will sit. The 6-inch Anti-Tip block must be provided by the installer. See Figures 1 and 3. -
Page 14: Operation Instructions
4 OPERATION INSTRUCTIONS 4.1 Control Panel and Features (1) (2) (10) (11) (12) 1 ) Open 7 ) Defrost Time 8 ) Number Keys 3 ) Auto Menu 9 ) Time Cook 4 ) Defrost Weight 10 ) Start/+30sec. 11 ) Power Level 5 ) Close 6 ) Timer/Clock 12 ) Stop/Cancel... -
Page 15: Time Cook
4 OPERATION INSTRUCTIONS 4.4 Time Cook 10 power levels are available. Level Power Display 100% TIME COOK 2. Press number keys to set the cook time,it should be within 00:01-99:99. POWER LEVEL POWER LEVEL number key to set the power level. START+30SEC. -
Page 16: Popcorn
4 OPERATION INSTRUCTIONS 4.8 Popcorn POPCORN 4.9 Sensor Reheat Sensor Reheat Sensor Reheat START+30SEC. PASTA Sr-1 PIZZA Sr-2 PLATE Sr-3 SOUP Sr-4 4.10 Sensor Cook Sensor Cook Sensor Cook START+30SEC. Potato Sc-1 Chicken Sc-2 Fish Sc-3 Ground Meat Sc-4 Fresh Veggies Sc-5 Frozen Veggies Sc-6... -
Page 17: Soften
4 OPERATION INSTRUCTIONS 4.13 SOFTEN SOFTEN SOFTEN START+30SEC. Menu Display Weight 1 buTT 1 (STICK) Butter 2 buTT 2(STICHS) 3 buTT 3(STICHS) 8 oz ICE 8 oz Ice cream/ Frozen juice 16 oz ICE 16 oz 32 oz ICE 32 oz 3 oz CHEE 3 oz Cream Cheese... -
Page 18: Troubleshooting
5 TROUBLESHOOTING 5.1 Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY • Electrical cord for oven is not •... -
Page 19: Warranty
Warranty&Service This product has been manufactured by Thor , 4651 E Airport Dr, Ontario, CA 91761 For Customer Service, please call (877) 288 - 8099 For the most up to date warranty and service policy, please refer to our website WWW.THORKITCHEN.COM/WARRANTY-REGISTRATION For in-warranty service requests, please visit our website at WWW.THORKITCHEN.COM/SERVICE... - Page 20 WELCOME TO THE CLUB You chose THOR Kitchen to enhance your culinary journey and we’re stoked to have you in the club. Think of it as a secret society of really savvy people, such as yourself, choosing professional power and performance at an affordable price.
