QUICK START GUIDE
Make sure you follow these instructions for a
quick start with the TC1000A72V for SurRon Ultra
Bee.
Connect the wires as shown below! Use only bolts and tools
included in the box. The product must be used in combination
with the
stock fuse
you will lose the Warranty and cause serious damage to the
product!
TC1000 Controller is not an original SurRon/Segway part so you
are using it at your own risk.
For additional help contact us at support@torp.hr
at all times! In case of incorrect installation,
Power Wires
Make sure to connect:
The
The black battery wire to the negative (-) electrode
Phase Wires
Make sure to connect:
The
The
The
IMPORTANT
red battery wire
to the positive (+) electrode
Blue motor
wire to the the letter B
Green motor
wire to the the letter G
Yellow motor
wire to the letter Y
M6 bolts
with Washers
Max Torque 4.5 Nm
Use only tools included with
the controller! Any damage
caused by torque higher than
4.5 Nm and tools that are not
part of the original package is
not covered by warranty!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TORP TC1000A72V
Summary of Contents for TORP TC1000A72V
- Page 1 QUICK START GUIDE Make sure you follow these instructions for a quick start with the TC1000A72V for SurRon Ultra Bee. Connect the wires as shown below! Use only bolts and tools included in the box. The product must be used in combination...
- Page 2 INSTALLING TC1000 ON SURRON ULTRA BEE. The TC1000 for SurRon Ultra Bee comes with an aluminum Heat Sink. Place the TC1000 inside the heatsink and align the 6 holes on its back to the 6 holes on the heatsink. Use the 6 bolts and the hex-key (included in the package) to secure the controller to the heatsink.
- Page 3 IMPORTANT: After the installation make sure to go to the 5th screen of the Torp App, click on the CALIBRATION button, select the ULTRA BEE as your motor type and follow the INSTALLATION WIZARD. For additional help contact us at support@torp.hr...
