User's Manual V 2.6, 7/8/2020
Overview:
The Eye-BERT Micro Family of products provide low cost, easy to use, electrical and optical test
solutions offering high performance bit error rate testing at a fraction of the cost while providing a rich
set of features not found in other bit error rate testers. Features include: variable bit rate, user
programmable patterns, optical power and temperature monitoring, and transceiver register read /
write capability. Some models offer one-click transceiver testing which automatically tests the
pluggable transceiver based on the information it reads from the module and generates a detailed test
report complete with manufacturer, part number, serial number, date code, fiber type, link length,
speed, and test results. The Units are supplied with anti-skid bumpers for bench use and are small
enough to be integrated into larger systems for dedicated link verification. A summary of the Eye-
BERT Micro models is listed below; for more details see the individual data sheets.
Model
Eye-BERT Micro LR
(100357A-XXX)
Eye-BERT Micro
(100286A)
Eye-BERT Micro 10G
(100292A)
Eye-BERT MicroX10
(100495A-X10)
Eye-BERT MicroX30
(100495A-X30)
Warnings and Precautions:
Do not exceed manufacturers recommended optical input power on any port
Use only compatible fiber optical connectors and modules
Use only the supplied 5VDC power supply as applicable
Observe ESD precautions when handling
Proper ventilation and/or heat sinking may be required depending on the environment and
transceiver power dissipation
Installing the Software and Starting the Application
Regardless of the model, all Eye-BERT Micro's use the same easy to operate software application
and USB driver.
1. Insert the CD or download the application from www.spectronixinc.com, run the "Eye-BERT
Micro Install.exe" installation program.
select "Run as administrator".
2. Connect power to the Eye-BERT Micro using the supplied 5VDC adapter (select models).
Page 1 of 7
Rates
6.312 Mbps – 125Mpbs
(continuous)
125Mbps – 4.25Gbps
(banded)
9.95Gbps – 11.3Gbps
(continuous)
1.224Gbps – 14.5Gbps
(banded)
1.224Gbps – 29Gbps
(banded)
Windows 7 Users and above: right click the file and
1
Eye-BERT Micro Family
Bit Error Rate Testers
Interfaces
Electrical SMA, 1310nm, 1550nm
Pluggable: any MSA compliant SFP or
SFP+
Pluggable: Any MSA compliant XFP
Pluggable: Any MSA compliant SFP,
SFP+, or SFP28
Pluggable: Any MSA compliant SFP,
SFP+, or SFP28
www.spectronixinc.com
Advertisement
Table of Contents
Related Manuals for Spectronix Eye-BERT Series
Summary of Contents for Spectronix Eye-BERT Series
- Page 1 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 Overview: The Eye-BERT Micro Family of products provide low cost, easy to use, electrical and optical test solutions offering high performance bit error rate testing at a fraction of the cost while providing a rich set of features not found in other bit error rate testers.
- Page 2 If the hardware installation wizard fails, go to “My Computer” > “Properties” > “Hardware” > “Device Manager”, and find the “Spectronix” or “SERIAL DEMO” entry under “Other Devices” and select “Update Driver”. At this point you will be able to browse to the location of the driver.
- Page 3 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 retransmits the input signal and is not supported by the pattern detector. All PRBS patterns, K28.5, and DCD patterns are supported by the pattern detector and can be used for bit error testing. The CJTPAT, CRPAT, and CSPAT patterns are intended only for jitter testing and are not supported by the pattern detector.
- Page 4 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 above the minimum transceiver threshold. The Sync LED turns green when the receiver CDR / pattern detector has locked to the incoming signal. The receiver measurement indicates either the received optical power (pluggable transceiver models) or the received bit rate.
- Page 5 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 Transceiver Utilities If the model supports pluggable transceivers, the “Utilities” button will be visible. Selecting this button will display the transceiver utilities window. From this window the user can read and write the registers and test the transceiver.
- Page 6 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 Data Logging Data can be logged to an Excel compatible CSV file in one second intervals by pressing the “Log” button from the main window. During logging, the log LED will flash green/yellow to indicate logging is in process.
- Page 7 Eye-BERT Micro Family Bit Error Rate Testers User’s Manual V 2.6, 7/8/2020 APPENDIX LETTER OF VOLOTILITY All products in the Eye-BERT Micro family contain both volatile and non volatile memory. Only the Eye-BERT Micro firmware application is stored in non volatile memory and program variables and settings are stored in volatile RAM which is cleared upon power down.
