- Page 6 1. Prepare 8 bolt assemblies by first inserting a spring washer (#F) onto the bolts (#A) then a washer (#E) onto that same bolt (#A). 2. Align the end of the upper side rails (#5,6) to the holes along the top side panels (#1). Insert 2 bolt assemblies into each end.
- Page 7 2. Prepare 10 bolts by applying a spring washer 1. Align the guardrail reinforce (#F) onto the bolts (#B), then insert into the bars (#13) to the holes along holes and secure using the Allen wrench (#H). the designated guardrail bars. Front Guardrail Bar Front Guardrail Bar Back Guardrail Bars...
- Page 8 2. Prepare 5 bolts by applying a spring washer 1. Align the guardrail (#F) onto the bolts (#B), then insert into the bars to the side rails. holes and secure using the Allen wrench (#H). Insert the ladder steps (#14) into the slots along the ladders (#11,12), then insert a bolt (#C) into each end.
- Page 9 1. Insert a dowel (#D) into the holes along the top of the bottom bed, then with the help of another person carefully place the upper bed onto those dowels (#D). 2. Insert 2 wood screws (#L) into each leg. Secure using a screwdriver.
- Page 10 Place the slats (#12) onto the side rails, then insert a wood screw (#I) into each end. Secure using a screwdriver.
