QUICK START GUIDE
Spectra Geospatial
Ranger 5 Data Collector
C
Please read the full user guide
CAUTION –
including all safety warnings, before
operating this product.
In the box
Spectra® Geospatial Ranger® 5 data collector
►
AC power supply with regional plugs and USB-C port
►
USB-C to USB-C cable for charging and data transfer
►
Screen protector
►
Capacitive stylus with tether, 2 extra stylus tips
►
Philips #1 screwdriver
►
Handstrap
►
Protective pouch
►
Quick Start Guide
►
Model 121900
PDF
Advertisement
Related Manuals for Spectra Geospatial 121900
Summary of Contents for Spectra Geospatial 121900
- Page 1 QUICK START GUIDE Model 121900 Spectra Geospatial Ranger 5 Data Collector Please read the full user guide CAUTION – including all safety warnings, before operating this product. In the box Spectra® Geospatial Ranger® 5 data collector ► AC power supply with regional plugs and USB-C port ►...
- Page 2 PARTS OF THE RANGER 5 DATA COLLECTOR Function keys (F7-F12) Ambient light sensor Android keys Cursor lock LED Microphone (x2) Stylus tether points Function keys (F1-F3, F4-F6) Stylus holder OK key & directional keys Pole mount latches (x2) CAPS lock LED Handstrap connector points (x4) Battery charging LED Gore vent.
- Page 3 INSTALL MICROSIM CARD (OPTIONAL) Remove the cover to access the SIM card slot. TETHER THE STYLUS, STORE IN THE STYLUS HOLDER There is a stylus tether on the left and on the right of the device. INSTALL THE SCREEN PROTECTOR...
- Page 4 © 2021, Trimble Inc. All rights reserved. Trimble and the Globe & Triangle logo and Ranger are trademarks of Trimble, registered in the United States and in other countries. Spectra Geospatial is a Division of Trimble Inc. Spectra and the Spectra Geospatial logo are trademarks of Trimble Inc.
