DXZC-E and DXZC-EM Zero Clients
Quick Start Guide
The DXZC-E is a PC-over-IP® (PCoIP®) zero client that can be used to connect to
physical and virtual workstations, virtual desktops such as VMware Horizon and
cloud managed desktops such as Amazon Workspaces.
The DXZC-E is based on the Tera2 chipset and supports two heads of video at the
desktop. The DXZC-E has eight USB 2.0 ports, two on the front panel and six at the
rear. Two of the rear USB ports are capable of charging high charge-current
devices.
The DXZC-E is available in two versions. The standard DXZC-E has an RJ45 network
port. The DXZC-EM has a network port that accepts a copper or fiber SFP module
(available separately). Each version is supplied with a PSU and power cable.
Before you start
You must first configure a remote computer and PCoIP host, ready for connection
to the DXZC-E. The remote computer must be powered and connected to the
appropriate network. You will need the IP address of the PCoIP host.
STEP 1: Connect the Keyboard, Mouse and optional Headset
1. Connect a keyboard and mouse either to the front panel USB ports or to the
USB ports at the rear. Note that two of the rear ports are capable of charging
high charge-current devices (up to 1.5A).
2. Connect audio devices, if used.
STEP 2: Connect the Monitor, Network cable, Peripherals and Power
1. Connect at least one compatible monitor to the DXZC-E, starting at the
Video 1 port.
2. Connect the network cable.
3. Connect the DXZC-E PSU. Use only the PSU supplied with this DXZC-E!
www.amulethotkey.com
DXZC-E Zero Client
Note: This guide uses 'DXZC-E' as a generic term when referring
to both the standard DXZC-E product and the DXZC-EM product.
STEP 3: Power on the unit
1. Press the POWER/MENU button. A short button press turns on the unit.
2. When the unit is on:
A long button press turns off the unit.
■
A short button press displays the On Screen Display (OSD) configuration
■
menu.
3. Turn on the monitor and make sure the remote workstation is on.
AMULET
HOTKEY
solutions you can bank on
DXZC-E Quick Start Guide v1.0 November 2016
QS-DXZC-E001
®
®
