- Page 1 FSDEL-218-161 INSTRUCTION MANUAL PLUG-IN TRANSDUCER FINE SERIES ALARM SETTER FSDEL...
-
Page 2: Safety Concerns
Aluminum electrolytic capacitors are used for products. Please energize the power supply within one year after purchase. Countermeasures against troubles. If this product breaks down within the warranty period, it will be repairs by DAIICHI ELECTRONICS. Disposal Please dispose of this product as industrial waste (noncombustible). -
Page 3: Table Of Contents
FSDEL-218-161 Contents Safety concerns ････････････････････････････････････････････････････････････ 1 1. Outline on the product ･･･････････････････････････････････････････････････ 3 1.1 Features ･･････････････････････････････････････････････････････････････ 3 2. Installation 2.1 Outline dimensions ････････････････････････････････････････････････････ 3 2.2 Cautions on mounting ･･････････････････････････････････････････････････ 4 2.3 Example of combination mounting ･･･････････････････････････････････････ 4 2.4 The mount to DIN rail, and the method of detachment ･･･････････････････ 5 2.5 Connection diagram ････････････････････････････････････････････････････... -
Page 4: Outline On The Product
1.1 Features Compact size. Miniaturized our company's alarm setter (SDLC-105A). FSDEL is the same size as our small plug-in transducer (Fine series). Two mounting methods. Socket installation or mounting base (FWBA) installation. Bright and easy to see display. -
Page 5: Cautions On Mounting
FSDEL-218-161 (2) Precision Resistance Unit, Type：UR-2 (option) AWG22 (60mm) 11.2 UR-2 combines an alarm setter of voltage input, and please use it. When open measures are necessary when they change an alarm setter with hot line condition in current input, they connect UR-2 to socket, and please use it by voltage signal. -
Page 6: The Mount To Din Rail, And The Method Of Detachment
FSDEL-218-161 2.4 The mount to DIN rail, and the method of detachment. <Cautions> If it insert and remove the body section from a socket, please carry out after shutting down a power supply and an input signal. (1) How to fix a socket. (2) How to fix a body to a socket. -
Page 7: Connection Diagram
FSDEL-218-161 2.5 Connection diagram OUTPUT 1, 2：Make contact (N.O.) OUTPUT 1, 2：Break contact (N.C.) Socket (FW11) Mounting base (FWBA) Socket (FW11) Mounting base (FWBA) INPUT INPUT INPUT INPUT － ＋ ＋ － － ＋ ＋ － OUTPUT2 OUTPUT2 AUX.SUPPLY AUX.SUPPLY OUTPUT1 OUTPUT1 OUTPUT1... -
Page 8: About Of Auxiliary Supply
FSDEL-218-161 2.6 About of auxiliary supply By applying auxiliary power to the power supply (AUX. SUPPLY) terminal of mounting base, power is supplied to each unit. When mounting base has unit individual power switch. Please insert this product into the mounting base and tighten the screw to fix the main body. An auxiliary power is supplied. -
Page 9: Method Of Operation
FSDEL-218-161 3. Method of operation 3.1 Name and function of each part For 1 output For 2 output POWER LED The LED lights when the auxiliary power is supplied, and goes out when it is shut off. POWER POWER OLED Displays the measured value (actual scale) and various setting values. -
Page 10: Measurement Mode
FSDEL-218-161 3.3 Measurement mode After turning on the auxiliary power supply, the measurement mode is entered and each measurement can be confirmed.〔Input value display, Maximum value display, Minimum value display, Alarm output 1 display（ON/OFF ⇔ Setting value）, Alarm output 2 display（ON/OFF ⇔ Setting value）〕 Press UP or DOWN to switch display. -
Page 11: Setting Mode
FSDEL-218-161 3.4 Setting mode (Each set value can be changed.) Pressing ENTER for 3 seconds or longer with input value display switches to setting mode. Input value display Common setting Setting change 3 seconds ENTER Common Unit Unit ENTER ENTER DOWN DOWN Scaling minimum value... - Page 12 FSDEL-218-161 Alarm output 1 setting ( ７ Setting change Alarm output 1 Output mode Output mode ENTER ENTER DOWN DOWN Operation value Operation value At the same time, At the same time, 1 time or more than 1 time or more than 1 second, or return 1 second.
-
Page 13: Calibration
FSDEL-218-161 Test mode Pressing UP and DOWN for more than 3 seconds in the measurement mode switches to the test mode. Normal detection operation is not performed during the test mode. Measurement mode Test mode 3 seconds DOWN DOWN ENTER Press ENTER to switch ON / OFF... -
Page 14: Model Name And Specification Code
FSDEL-218-161 4. Model name and specification code TYPE Specification code ＦＳＤＥＬ－ ① ② ③ ④ ② Alarm output ① Input（Input resistance） Output 1 Output 2 Change-over break before make DC1 to 5V (About 1MΩ) ― contact (N.O./N.C.) DC4 to 20mA (About 100Ω) Make contact (N.O.) Make contact (N.O.) Other... -
Page 15: Alarm Output
FSDEL-218-161 5.2 Alarm output Item Function Setting in five kinds of modes as follows is possible for operation of detection. ① High limit detection (H), Alarm output, relay excitation ② High limit detection (H), Alarm output, Relay non-excitation Output mode Output mode setting ③... -
Page 16: Relay Operation
FSDEL-218-161 5.3 Relay operation ■ Contact delay function ８ Relay operation in over-input detection. (Output mode：Excitation, H ( Operation value Setting value setting Dead band Input Relay action Contact delay Contact delay Contact delay setting time setting time setting time ８... -
Page 17: Pre-Alarm Function
FSDEL-218-161 5.4 Pre-alarm function A monitor lamp is blinked among contact delay time until excitation of a relay after operation value detection. Blinking of a monitor lamp will be gradually fast, and when the point of contact delay time passes, a monitor lamp is lights up. -
Page 18: Setting Value
FSDEL-218-161 5.5 Setting value Initial value № Contents Mark Setting range 1 output 2 outputs Select one point from 129 points Unit display UNIT ％ (Please refer to the "5.6 Unit" for more information) Minimum value S.MIN -9999 to 9998 Scaling Maximum value S.MAX... -
Page 19: Unit
FSDEL-218-161 5.6 Unit № Item Setting unit 1 Length μm ×10mm ×10cm 2 Mass ×10kg 3 Time 4 Current μA ×10A 5 Temperature ℃ ×10℃ 6 Angle ° Volume ×10L ×100L 8 Speed mm/min m/min mm/h 9 Acceleration 10 Frequency 11 Rotational speed ×10rpm 12 Density... -
Page 20: Performance・Class
FSDEL-218-161 5.7 Performance・Class Item Specification Input range Accuracy DC60mV to Less than 1V ±0.2％（％ of input span） DC±60mV to Less than ±1V Setting accuracy DC1 to 60V DC±1 to ±60V ±0.1％（％ of input span） DC1 to 50mA DC±1 to ±50mA Input range Accuracy When the measurement display span is less than 10000... -
Page 21: Electrical Strength And Mechanical Strength
FSDEL-218-161 5.8 Electrical strength and mechanical strength Item Specification Between electric circuit and case. 1 alarm Between input, output and auxiliary supply. output Between input and output. Insulation resistance Between electric circuit and case. Above 50MΩ at DC500V. JIS C 1111 Between input, output and auxiliary supply. -
Page 22: Emc Directive (Ce Marking)
FSDEL-218-161 5.10 EMC Directive (CE Marking) Item Specification Contact discharge Electrostatic ±4kV (Charge voltage) Performance After test EN61000-6-2:2005 discharge immunity Air discharge standard：B ：Normal operation EN61000-4-2:2009 test ±8kV (Charge voltage) Frequency：① 80 to 1000MHz ② 1.4 to 2.0GHz Radiated, During test ③... -
Page 23: Structure, Use / Storage Environmental Conditions, Others
FSDEL-218-161 5.11 Structure, Use / Storage environmental conditions, Others Item Specification Material ABS resin Appearance color Munsell N1.5 (Black) 29.5 mm × 76 mm × 125 mm (Width × height × depth) Including socket External dimensions Mass FSDEL：Approx. 105g , Socket：Approx. 50g Socket：FW11（OMRON Corporation）×1 , Accessories When socket is unnecessary, please specify at arrangement. - Page 24 FSDEL-218-161 Tokyo Office : 11-13, Hitotsuya 1-chome, Adachi-ku, Tokyo, 121-8639, JAPAN. TEL：+81-3-3885-2411 , Fax：+81-3-3858-3966 Kyoto Office : 1-19, Ichinobe-Nishikawahara, Jyoyou-shi, Kyoto, 610-0114, JAPAN. TEL：+81-774-55-1391 , Fax：+81-774-54-1353 Revision A, DATE：November 29, 2019...
