OPERATING AND ASSEMBLY INSTRUCTIONS
Free-standing stove
LUPO
LYNX
CANE
In accordance with the requirements of the Ecodesign Directive
on the territory of EU member states:
"This product cannot be used as a primary heating
source."
www.hitze.pl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUPO and is the answer not in the manual?

Questions and answers

Summary of Contents for HITZE LUPO

  • Page 1 OPERATING AND ASSEMBLY INSTRUCTIONS Free-standing stove LUPO LYNX CANE In accordance with the requirements of the Ecodesign Directive on the territory of EU member states: "This product cannot be used as a primary heating source." www.hitze.pl...
  • Page 2 Dear Customer, Thank you for purchasing a Hitze freestanding stove! BEFORE FIRST USE, IT IS ESSENTIAL TO READ THE OPERATING AND INSTALLATION INSTRUCTIONS IN FULL AND CHECK THE COMPLETENESS OF THE PRODUCT...
  • Page 3: Table Of Contents

    1.2. In order to maintain the necessary safety rules, it is necessary to.........2 1.3. Never ..............................3 1.4. Hitze is exempt from civil and criminal liability in the event of ..........3 1.5. Purpose of the stove......................3 1.6. Construction and operation of the furnace.................6 2.
  • Page 4 NEWS INTRODUCTORY Warmth from Nature - these words perfectly illustrate the Hitze brand philosophy. In accordance with it, we produce fireplaces and stoves that are heated with wood or wood pellets, that is, raw materials that are the least harmful to the environment. Thanks to new technology, we have created innovative solutions that are characterized by modern design and high heating efficiency.
  • Page 5 ▪ avoid installing the stove in rooms with type B gas appliances, hoods (with and without exhaust), heat pumps, collective ventilation ducts, numerous operating smoke ducts, as well as...
  • Page 6: Never

    1.5m from the stove; ▪ Light fires with flammable materials and burn waste. 1.4. Hitze is exempt from civil and criminal liability in the event of: ▪ use of the stove contrary to the Operating and Installation Instructions;...
  • Page 7 Overall depth Body depth Width of the hearth Depth of the hearth Air intake diameter Flue diameter Glass width Glass height Tab 1 LUPO furnace dimensions Fig. 2 LYNX stove dimensions Dimensions [mm]. LYNX S LYNX B Width Height Overall depth...
  • Page 8 Fig. 3 CANE furnace dimensions Dimensions [mm]. CANE S CANE SF Width Height 1020 1020 Overall depth Body depth Width of the hearth Depth of the hearth Air intake diameter Flue diameter Glass width Glass height Tab 3 CANE furnace dimensions...
  • Page 9: Construction And Operation Of The Furnace

    Technical data: LUPO S, CANE S, CANE SF parameter unit LUPO M LUPO L LYNX S, LYNX B Nominal power Heating load range 3-8,5 4,5-11,5 5,5-14 Maximum fuel loading weight kg/h Average fuel consumption Thermal efficiency 83,5 g/m3 CO emissions (at 13% O2)
  • Page 10 ashtray 14. flank flue deflector doors made of a special profile 15. decor glass flue cap 10. backplate 16. handle flue gas afterburning system 11. baseplate 17. air curtain combustion chamber with 12. adjustment lever 18. leveling screws insert secondary air damper 19.
  • Page 11: Transport And Handling

    It is required that the installation of the stove be carried out by a qualified person or company and technical acceptance by a master chimney sweep and fire prevention specialist. The order of execution of the work on the installation of the stove: ▪...
  • Page 12 The operation of transferring the flue from the top plate to the back wall is shown in the figure. 1. A view of the furnace in its 2. Remove the top cover, cut a 3. Using an allen wrench, hole in the back plate with a factory configuration, unscrew the back plate, hacksaw, or cut a hole with...
  • Page 13 Fig. 7 Tightening the feet 2.3. Recommendations for substrates: ▪ Before installing the stove, check the load-bearing capacity of the floor (whether it meets the load-bearing conditions for the type of device depending on its weight); ▪ The floor must be made of non-flammable material with a minimum thickness of 30 cm, with a strip of space in front of the oven door with a width of at least 60 cm and extending beyond the edges of the door a minimum of 30 cm.
  • Page 14: Flue Pipe

    2.4. Duct chimney The stove requires the proper selection of the cross-section of the flue (flue duct) and the proper height of the flue pipe. The cross-sectional area of the flue and smoke duct is determined according to the formula: Where: F - cross-sectional area of the flue and flue pipe [m2];...
  • Page 15 2.6. The flue pipe system should meet the following characteristics: ▪ the cross-section of the flue pipe must not be smaller than the cross-section of the flue pipe and must not narrow towards the chimney (transitions can be used to increase the diameter from the flue pipe to the chimney);...
  • Page 16 2.7. Recommendations for connecting the air intake and how to ventilate the cartridge: ▪ It is necessary to bring in fresh air from outside by unsealing the windows so that there is a constant supply of air. Too little fresh air from the outside can cause poor combustion (production of carbon monoxide), and in the worst case, with tightly closed windows.
  • Page 17 NOTE! ▪ the best way to ensure the right amount of air to the stove is to supply it through a special supply duct directly from outside the building located under the floor ▪ It is also possible to connect the stove to the intake located in the wall of the building located in the fireplace housing using fireproof pipes;...
  • Page 18 Free-standing stoves allow the DGP system to be connected to the stove in two ways: from above (LUPO, CANE, LYNX) or from below (LUPO, CANE). When installing from the top, it is necessary to cut out parts of the rear cover in the places marked on the drawing. Unobstructed air flow is gained. When installing the pipes from below, it is required to use a blower in the system to extract the heated air.
  • Page 19 Fig. 13 Arrows indicate cutting locations before fitting connectors when connected from above Fig. 14 Properly installed connectors when connected from the top of the stove Fig. 15 Properly installed connectors when connected from the bottom of the stove...
  • Page 20: Starting Up

    On the properly installed connectors are placed pipes that carry the heated air to other rooms. For proper operation of the system, it is necessary to ensure the return of cool air to the room in which the stove is located.
  • Page 21: Use

    If flue gas is escaping from the stove chamber, adjust the flue gas damper setting and increase the chimney draft. Before the next kindling, the hearth should be cleaned of ash residue. Fig. 16 Operation of the throttle - pressed in - air supply closed, pulled out - air supply open The surface of the stove is covered with a special heat-resistant paint, which, when the stove is fired up, first gets soft (be careful not to scratch it then) and then hardens.
  • Page 22: Preventing Fumes From Escaping

    ▪ Wood billets in the combustion chamber should be laid parallel to the plane of the door. ▪ Before loading a fresh batch of fuel into the furnace, the grate should be ashed when necessary to empty the ash container. 4.3.
  • Page 23 Method 2 plate removal METHOD 2 (for LUPO M and L only). Spread the deflectors to the sides. This gives us a gap in the middle so that we can maneuver the plate to break out. Preferably using a flathead screwdriver Fig.
  • Page 24: Ash Removal

    4.7. Ash removal Depending on the amount and grade of fuel to be burned: ▪ Using a poker, scrape the ashes through the grate into the ash pan; ▪ After scraping the ashes, remove the ash pan and empty it; ▪...
  • Page 25: Conservation

    ▪ leave near the stove glass, any, flammable and heat-sensitive items; ▪ Operate the device with a broken glass; ▪ extinguish furnaces with water;w ▪ Allow children or pets into the device; ▪ make any structural changes, changes in installation and use rules without written permission from the manufacturer;...
  • Page 26 5.1. Recommended periodic cleaning furnace For efficient combustion in the furnace hearth, periodically clean the combustion chamber, grate, chimney and flue pipes. Element Frequency Tools and resources Convection surfaces of the stove As needed, but at least once a Spring material brush, ash and pipes connecting to the flue year or after a prolonged break in vacuum cleaner, fireplace...
  • Page 27: Recommended Periodic Cleaning Of The Furnace

    After unscrewing the cover, we will gain access to the cleanout. They are fastened with M8 nuts. For reassembly after cleaning the interior of the stove, it is recommended to use new sealing tape. Thorough cleaning should be done once a year after the heating season, or as needed. Fig.
  • Page 29 ▪ Unscrew the allen bolt M5x10, and then remove the concretes numbered 1 and 2 M5x10 Fig. 25 Location of bolt and concretes ▪ We now have the option of removing the upper deflector. remove Fig. 26 Location of deflector ▪...
  • Page 30: Faults And Irregularities During Operation

    FAULTS AND IRREGULARITIES DURING OPERATION During day-to-day operation of the stove, the malfunctions described below may become apparent, indicating that the stove was improperly installed without observing the appropriate guidelines contained in this Operating and Installation Manual and the applicable laws and regulations. 6.1.
  • Page 31 the device can be unsuitable atmospheric conditions, use a chimney cowl, but if this does caused by external e.g., wind or lack thereof, low not help you should perform an expert factors atmospheric pressure, high humidity, chimney sweep to determine the fog, etc.
  • Page 32: Nameplate

    NAMEPLATE The nameplate is located on the back of the device. Fig. 29 Model of nameplate and its location...
  • Page 33 CARD REVIEWS FURNACE INSPECTION LOG Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp...
  • Page 34 FLUE INSPECTION REGISTER Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp Overview Date, signature and stamp...
  • Page 35 HitzeManufacturerFireplac hitze_producer_firesplaces HITZE Fireplace Manufacturer STALKO Office: +48 48 380 18 98 NIP 9482603545 limited liability company limited Gdyśka 32 +48 800 88 00 30 REGON 361379132 partnership 26-600 Radom KRS 0000836475 info@hitze.pl POLAND 24/253 Solec St. 00-403 Warsaw, POLAND...
