Installation

1.
Determine location for desired
placement of unit close enough
to a power outlet to allow the
included 120/240 VAC to 24 VDC
power adapter to be plugged
in. Typically, the angled grille
should be pointed upward and
mounted as high on the wall as
practical, within 18 inches of the
ceiling if possible.
2.
Plug the power adapter's elbow
style DC connector into the
unit's rear power outlet.
3.
Attach the DXB Mini to the
wall location with included
screws utilizing the mounting
bracket flanges.
4.
Make proper electrical
connection of 24VDC power
adapter to outlet.
STEP 1
STEP 2
STEP 3
