Summary of Contents for DEWESOFT DS-DISP-12
- Page 1 Displays TECHNICAL REFERENCE AND USER MANUAL DS-DISP-12, DS-DISP-13, DS-DISP-15...
-
Page 2: Table Of Contents
6. Safety instructions 6.1. Safety symbols in the manual 6.2. General Safety Instructions 6.2.1. Environmental Considerations 6.2.2. Product End-of-Life Handling 6.2.3. System and Components Recycling 6.2.4. General safety and hazard warnings for all Dewesoft systems 7. Documentation version history V24-1 2/22... -
Page 3: About This Document
The DEWESoft® User Manual document provides basics and additional information and examples for working with DEWESoft® and certain parts of the program. The latest version of the DEWESoft® tutorials can be found here: https://download.dewesoft.com/list/manuals-brochures/software-manuals In the Software Manuals section click the download link of the DEWESoft X User Manual entry. V24-1 3/22... -
Page 4: Ds-Disp-12
TECHNICAL REFERENCE MANUAL 3. DS-DISP-12 DS-DISP-12 is a 12'' LED mobile display built into a rugged aluminum chassis for field tests and measurements. It is designed specifically to work with our data acquisition systems such as SBOX, MINITAURs , SIRIUS R2/R4, SIRIUS R8, and KRYPTON CPU. -
Page 5: Specifications
Displays TECHNICAL REFERENCE MANUAL 3.1. Specifications DS-DISP-12 Interfaces and options Touch Screen PCAP, Multi-touch Touch Screen Interface 1x USB 2.0, USB Mini B Video 1x VGA, 1x DVI, 1x HDMI 3x 1/4-20 UNC thread insert on bottom side, Mounting VESA mounting compatible on back side... -
Page 6: Connectors
The USB connector is used to connect the Touch screen controller in the DS-DISP-12 to the PC. Mini USB B Connector 3.1.1.3. Video Inputs Two video connectors are available to connect DS-DISP-12 to the video signal source; either analog VGA or digital DVI signal can be connected. VGA Connector... -
Page 7: Touch Controller
Displays TECHNICAL REFERENCE MANUAL 3.2. Touch controller 3.2.1. Controller as a HID-compliant mouse Touch screen hardware should be recognised by the OS as a HID-compliant mouse. Open Control panel, then select System and check in Device Manager to confirm that new HW is recognised correctly. -
Page 8: On Screen Display (Osd) & Keypad
Displays TECHNICAL REFERENCE MANUAL 3.3. On Screen Display (OSD) & Keypad 3.3.1. Functionality while OSD is closed Function Remark POWER Switch Power On/Off MENU Open OSD Main Menu/ENTER SELECT Auto-colour Opens brightness adjustment Input select 3.3.2. Functionality while OSD is open Function Remark POWER... -
Page 9: Ds-Disp-15 & Ds-Disp-13
TECHNICAL REFERENCE MANUAL 4. DS-DISP-15 & DS-DISP-13 DS-DISP presents Dewesoft affordable displays that offer the perfect combination of price and performance. Built for various project needs – DS-DISP-13 and DS-DISP-15 touchscreen monitors are slim, compact, and suitable to be mounted or embedded inside the vehicle or aircraft, or simply used on the field as a portable screen on the go. -
Page 10: Led Power Indicator
Displays TECHNICAL REFERENCE MANUAL Image 2: DS-DISP buttons layout 4.1.3. LED Power indicator Display shows green light when the display is "On" and shows red light when the display is in stand by. There is no light when the device is "Off". V24-1 10/22... -
Page 11: Technical Specifications
Displays TECHNICAL REFERENCE MANUAL 4.2. Technical specifications PARAMETER DS-DISP-15 DS-DISP-13 Resolution 1920x1080 (widescreen 16:9) 1920x1080 (widescreen 16:9) Color depth 16.7 M Colors 16.7 M Colors Brightness (typical): 250 (cd/m2) 350 (cd/m2) Contrast (typical) 700:1 1000:1 View angle 170°(H)/170°(V)(CR>10) 170°(H)/170°(V)(CR>10) 15ms 15ms Response time HDMI-A(HDMI v1.4) x1 ,... -
Page 12: Ds-Disp-13 Dimensions
Displays TECHNICAL REFERENCE MANUAL 4.2.2. DS-DISP-13 Dimensions Image 4: DS-DISP-13 technical drawing V24-1 12/22... -
Page 13: Installation Guidelines
1. Support DisplayPort Alternate Mode (USB Type-C (DP Alt)). 2. Be able to stably output 5V 1.6A current to the monitor (if the computer cannot supply sufficient current, please connect a 12V adapter or Dewesoft 2pin power cable to the monitor.) Important The USB-C port on the monitor cannot supply power to the computer. -
Page 14: Usb Type A And Hdmi Connection (Sbox, Minitaur, Sirius Rack)
Displays TECHNICAL REFERENCE MANUAL 5.2. USB Type A and HDMI connection (Sbox, Minitaur, Sirius Rack) Image 6: 2x USB-A to USB-C connection Important OBSIDIAN Cannot power the display over USB C output! As shown in the image, connect dual USB-A to the computer and USB C cable to the display for power and touch screen and HDMI for video connection. -
Page 15: Usb Type A, Hdmi And Separate Power Connection (Sbox, Minitaur, Sirius Rack, Krypton Cpu)
Displays TECHNICAL REFERENCE MANUAL 4.3.3. USB Type A, HDMI and separate power connection (Sbox, Minitaur, Sirius Rack, Krypton CPU) Image 7: Separate power cable connection As shown in the image , connect dual USB-A to the computer and USB C cable to the display for touch screen, HDMI for video connection and a 12V power adapter or 2 Pin Lemo power supply cable. -
Page 16: Warranty Information
5.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly. -
Page 17: Printing History
When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo. -
Page 18: Safety Instructions
Dewesoft d.o.o. assumes no liability for the customer’s failure to comply with these requirements. All accessories shown in this document are available as an option and will not be shipped as standard parts. -
Page 19: General Safety And Hazard Warnings For All Dewesoft Systems
REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained. - Page 20 Displays TECHNICAL REFERENCE MANUAL noises. The system does not work anymore. The system has been exposed to long storage in adverse environments. The system has been exposed to heavy shipment strain. Warranty void if damages caused by disregarding this manual. For consequential damages, NO ●...
- Page 21 Displays TECHNICAL REFERENCE MANUAL EN 61326-3-1:2008 IEC 61326-1 applies to this part of IEC 61326 but is limited to systems and equipment for industrial applications intended to perform safety functions as defined in IEC 61508 with SIL 1-3. The electromagnetic environments encompassed by this product family standard are industrial, both indoor and outdoor, as described for industrial locations in IEC 61000-6-2 or defined in 3.7 of IEC 61326-1.
-
Page 22: Documentation Version History
Displays TECHNICAL REFERENCE MANUAL 7. Documentation version history Version Date Notes V24-1 8.1.2024 Initial version DS-DISP-12 Release of DS-DISP-13, DS-DISP-15 V24-1 22/22...
