- Page 1 DS-DISP-12 TECHNICAL REFERENCE MANUAL DS-DISP-12 V20-1 1 ...
-
Page 2: Table Of Contents
7.2. General Safety Instructions 10 7.2.1 Environmental Considerations 10 7.2.2. Product End-of-Life Handling 10 7.2.3. System and Components Recycling 10 7.2.4. General safety and hazard warnings for all Dewesoft systems 11 8. Documentation Version 14 DS-DISP-12 V20-1... -
Page 3: About This Document
It gives you important information about the subject. Please read carefully! Hint It gives you a hint or provides additional information about a subject. Example Gives you an example of a specific subject. DS-DISP-12 V20-1 3/14 ... -
Page 4: Specifications
IP rating IP40 Shock & Vibration Vibration sweep sinus (EN 60068-2-6:2008) Vibration random (EN 60721-3-2: 1997 - Class 2M2) Shock (EN 60068-2-27:2009) MIL-STD-810D Physical Dimensions 312 x 214 x 50 mm Weight 1.9 kg Rev: 1574416800 DS-DISP-12 V20-1 4/14 ... -
Page 5: Connectors
The USB connector is used to connect the Touch screen controller in the DS-DISP-12 to the PC. Mini USB B Connector 3.1.3. Video Inputs Two video connectors are available to connect DS-DISP-12 to video signal source either analog VGA or digital DVI signal can be connected. VGA Connector ... -
Page 6: Touch Controller
Open Control panel, then select System and check in Device Manager to confirm that new HW is recognised correctly. Image 1: Device Manager DS-DISP-12 V20-1 6/14 ... -
Page 7: On Screen Display (Osd) & Keypad
Decrease slider value Select next menu item In main menu or in submenu B Move picture to the right In H-Position submenu Move picture down In V-Position submenu Increase slider value DS-DISP-12 V20-1 7/14 ... -
Page 8: Warranty Information
6.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly. ... -
Page 9: Printing History
When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo. ... -
Page 10: Safety Instructions
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft GmbH assumes no liability for the customer’s failure to comply with these requirements. ... -
Page 11: General Safety And Hazard Warnings For All Dewesoft Systems
REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained. ... - Page 12 This product has left the factory in safety-related flawlessness and in proper condition. In order to ● maintain this condition and guarantee safety use, the user has to consider the security advice and warnings in this manual. DS-DISP-12 V20-1 12/14 ...
- Page 13 Devices and systems according to IEC 61508 or IEC 61511 which are considered as “operationally well-tried”, are excluded from the scope of IEC 61326-3-1. Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the scope of IEC 61326-3-1. DS-DISP-12 V20-1 13/14 ...
-
Page 14: Documentation Version
DS-DISP-12 TECHNICAL REFERENCE MANUAL 8. Documentation Version Doc-Version Date [dd.mm.yyyy] Notes 1.0 06.11.2014 Initial version (JK) 2.0 14.07.2015 Connectors update (JK) V20-1 08.09.2020 New template DS-DISP-12 V20-1 14/14 ...
