ARCTIC HAYES AH118 User Manual

Professional digital multimeter with temperature function

Advertisement

Quick Links

ARCTIC
HAYES
PROFESSIONAL
DIGITAL MULTIMETER
WITH TEMPERATURE FUNCTION
User Manual
AH118
Before using the instrument, please read this
manual carefully, and save for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AH118 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARCTIC HAYES AH118

  • Page 1 ARCTIC HAYES PROFESSIONAL DIGITAL MULTIMETER WITH TEMPERATURE FUNCTION User Manual AH118 Before using the instrument, please read this manual carefully, and save for future reference.
  • Page 2 Safety Instructions The instrument is designed according to the requirements of the international electrical safety standard IEC61010-1 for the safety requirements of the electronic testing instruments. The design and manufacture of instruments strictly comply with the requirements of IEC61010-1 CAT.III 600V over voltage safety standards.
  • Page 3 Safety Instructions • By measuring the known voltage to check whether the meter work is normal, if it is not normal or damaged, do not use. • Before using the instrument, please check whether there is any crack or plastic damage in the instrument case.
  • Page 4 Do not use probes with a different specification. Calibration To maintain the integrity of measurements, Arctic Hayes recommends that the multimeter is calibrated annually at an approved Calibration Laboratory. Arctic Hayes can offer this service, please contact sales@arctic-hayes.com or call +44(0)113 271 5245 to arrange.
  • Page 5 Safety Instructions Safety symbols   High Voltage Warning AC (Alternating current) DC (Direct current) AC or DC Warning, important safety signs Ground Fuse Equipment with double insulation/reinforced insulation protection Battery under voltage Product complies with all relevant European laws The additional product label shows that do not discard this electrical/electronic product into household garbage.
  • Page 6 Physical Appearance NCV probe Flashlight Red / Green light LCD display (dual colour backlight) Function keys Function knob 10A input socket Other measurement input socket mA, uA input socket COM input socket Height - 188mm Weight - 656g Width - 88mm (without batteries) Depth - 57.5mm...
  • Page 7 Specification Environment condition of using CAT IV 600V CAT III 1000V Pollution level Altitude <2000m Working environment 0~40°C (<80% RH, <10°C non condensing). temperature & humidity Storage environment -10~60°C (<70% RH, remove the battery). temperature & humidity General technical specifications Temperature coefficient: 0.1 x accuracy/°C (<18°C or >28°C).
  • Page 8 Specification Operation FUNC key Where there are multiple measuring functions on the selection switch, the function button will change between the measurement functions. Data hold Press” HOLD” key, enter data hold mode/ cancel data hold mode. Maximum measurement Press” Max” key, enter Maximum measurement/cancel Maximum measurement.
  • Page 9 Measurement Operation Warning for all below measurements. 1. The voltage above DC1000V or AC750V can’t be measured; otherwise the instrument may be damaged. 2. Pay special attention to safety when measuring high voltage to avoid electric shock or personal injury. 3.
  • Page 10 Measurement Operation DC/AC Voltage mV Measurement 1. Turn the knob to “ “ and Switching AC or DC voltage function by “FUNC.” key. 2. Insert the red probe in “ “ socket, insert the black probe in “COM” socket. 3. Contact the probe to the measured circuit (connect to the measured power supply or circuit in parallel), measure the voltage.
  • Page 11 Measurement Operation Warning. The voltage above 10V can’t be measured; otherwise the instrument may be damaged. Pay special attention to safety when measuring high voltage to avoid electric shock or personal injury. Test the known voltage with the meter before use, confirm the instrument function is intact.
  • Page 12 Measurement Operation Warning. The voltage above 1000V can’t be measured; otherwise the instrument may be damaged. Pay special attention to safety when measuring high voltage to avoid electric shock or personal injury. Test the known voltage with the meter before use, confirm the instrument function is intact.
  • Page 13: Continuity Measurement

    Measurement Operation 4. Read the measurement result. Continuity Measurement 1. Turn the knob to “ “ and Switch to continuity function by “FUNC.” key. 2. Insert the red probe in “ “ socket, insert the black probe in “COM” socket. 3.
  • Page 14: Capacitance Measurement

    Measurement Operation Capacitance Measurement 1. Turn the knob to “ “. 2. Insert the red probe in “ “ socket, insert the black probe in “COM” socket. 3. Contact the probe to the measured circuit or Capacitance, measure the resistance. 4.
  • Page 15: Temperature Measurement

    Accuracy Specification Live Test 1. Turn the knob to the “ “ shift, and Switch to live test function according to “FUNC.” key. Meter will display “LIVE”. 2. Insert the red probe in “ “ socket, Then the probe contact to the test point. 3.
  • Page 16 Accuracy Specification DC Voltage Range Resolution Accuracy 600mV 0.1mV ±(0.5% reading +3) 0.001V 0.01V 600V 0.1V 1000V AC Voltage Range Resolution Accuracy 600mV 0.1mV ±(1.0% reading +3) 0.001V 0.01V 600V 0.1V 750V DC Current Range Resolution Accuracy 600�A 0.1�A ±(1.2% reading +3) 6000�A 1�A 600mA...
  • Page 17 Accuracy Specification Resistance Range Resolution Accuracy 600Ω 0.1Ω ±(1.0% reading +3) 6kΩ 0.001kΩ 60kΩ 0.01kΩ 600kΩ 0.1kΩ 6MΩ 0.001MΩ ±(1.5% reading +3) 60MΩ 0.01MΩ Capacitance Range Resolution Accuracy 10nF 0.001nF ±(4.0% reading +3) 100nF 0.01nF 1000nF 0.1nF 10�F 0.001�F 100�F 0.01�F 1000�F 0.1�F...
  • Page 18 Accuracy Specification Frequency / Duty Range Resolution Accuracy 10Hz 0.001Hz ±(1.0% reading +3) 100Hz 0.01Hz 1000Hz 0.1Hz 10kHz 0.001kHz 100kHz 0.01kHz 1000kHz 0.1kHz 10MHz 0.001MHz ±(3.0% reading +3) 1~99% 0.1% Continuity Test The resistance is Open circuit voltage is <30, the buzzer about 1V will sound and Overload...
  • Page 19: Battery Replacement

    Battery Replacement Battery Replacement 1. Turn off the power supply of the instrument, and remove the probe on the instrument. 2. Use screwdriver to unscrew screws fixing the battery cover, remove the battery cover. 3. Remove old batteries, replace with new batteries of the same specifications.
  • Page 20: Limited Warranty

    Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
