Summary of Contents for ARCTIC HAYES AH113
- Page 1 ARCTIC HAYES COMPACT DIGITAL MULTIMETER WITH TEMPERATURE FUNCTION User Manual AH113 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Safety Instructions The instrument is designed according to the requirements of the international electrical safety standard IEC61010-1 for the safety requirements of the electronic testing instruments. The design and manufacture of instruments strictly comply with the requirements of IEC61010-1 CAT.III 600V over voltage safety standards.
- Page 3 Safety Instructions • Before using the instrument, please check whether there is any crack or plastic damage in the instrument case. If there is any damage, do not use. • Before using the instrument, please check whether the probe is cracked or damaged. If so, please replace the same type and the same electrical specifications.
- Page 4 Safety Instructions • Only use with the supplied probes. If the probe is damaged and need contact the manufacturer. Do not use probes with a different specification. High Voltage Product complies with all Warning relevant European laws AC (Alternating The additional product label current) shows that do not discard...
- Page 5 Physical Appearance NCV probe Flashlight Red / Green light LCD display Function keys Function knob 10A input socket COM input socket Other measurement input socket Height - 151mm Weight - 424g Width - 75mm (without batteries) Depth - 46mm...
- Page 6 Specification Environment condition of using CAT||| 600V Pollution level Altitude <2000M Working environment 0~40°C (<80% RH, <10°C non condensing). temperature & humidity Storage environment -10~60°C (<70% RH, remove the battery). temperature & humidity General technical specifications Temperature coefficient: 0.1 x accuracy/°C (<18°C or >28°C). MAX.
- Page 7 Specification Operation FUNC key Where there are multiple measuring functions on the selection switch, the function button will change between the measurement functions. Data hold Press” HOLD” key, enter data hold mode/ cancel data hold mode. Maximum measurement Press” Max” key, enter Maximum measurement/cancel Maximum measurement.
- Page 8 Measurement Operation Warning for all below measurements. 1. The voltage above 600V can’t be measured; otherwise the instrument may be damaged. 2. Pay special attention to safety when measuring high voltage to avoid electric shock or personal injury. 3. Test the known voltage with the meter before use, confirm the instrument function is intact.
- Page 9 Measurement Operation 3. Contact the probe to the measured circuit (connect to the measured power supply or circuit in parallel), measure the voltage. 4. Read the measurement result on the screen. Frequency / Duty Measurement 1. Turn the knob to “Hz%” and Switching Frequency or duty function by “FUNC.”...
- Page 10 Measurement Operation Warning for all below measurements. When measuring resistance on the line, disconnect the power supply and discharge all the high-voltage capacitors. Otherwise, the instrument may be damaged, and the user may suffer an electric shock. Resistance Measurement 1. Turn the knob to “ “...
-
Page 11: Continuity Measurement
Measurement Operation Continuity Measurement 1. Turn the knob to “ “ shift and Switch to Continuity measurement function according to “FUNC.” key. 2. Insert the red probe in “ “ socket, insert the black probe in “COM” socket. 3. Contact the probe to the measured circuit or resistance. - Page 12 Measurement Operation Warning for all below measurements. In order to avoid possible accidents such as electric shock or personal injury, please follow the safety regulations. NCV Test 1. Turn the knob to the “ “ shift, and Switch to NCV test function according to “FUNC.” key. Meter will display “NCV”.
-
Page 13: Temperature Measurement
Measurement Operation 3. When the meter senses weak AC signals, the green indicator lights up, while the beeps send out slow dips. 4. When the meter senses strong AC signals, the red indicator lights up, while the beeps send out fast dips. - Page 14 Accuracy Specification DC Voltage Range Resolution Accuracy 600mV 0.1mV ±(0.5% reading +3) 0.001V 0.01V 600V 0.1V AC Voltage Range Resolution Accuracy 600mV 0.1mV ±(1.0% reading +3) 0.001V 0.01V 600V 0.1V DC Current Range Resolution Accuracy 600�A 0.1�A ±(1.2% reading +3) 6000�A 1�A 600mA...
- Page 15 Accuracy Specification Resistance Range Resolution Accuracy 600Ω 0.1Ω ±(1.0% reading +3) 6kΩ 0.001kΩ 60kΩ 0.01kΩ 600kΩ 0.1kΩ 6MΩ 0.001MΩ ±(1.5% reading +3) 60MΩ 0.01MΩ Capacitance Range Resolution Accuracy 10nF 0.001nF ±(4.0% reading +3) 100nF 0.01nF 1000nF 0.1nF 10�F 0.001�F 100�F 0.01�F 1000�F 0.1�F...
- Page 16 Accuracy Specification Frequency / Duty Range Resolution Accuracy 10Hz 0.001Hz ±(1.0% reading +3) 100Hz 0.01Hz 1000Hz 0.1Hz 10kHz 0.001kHz 100kHz 0.01kHz 1000kHz 0.1kHz 10MHz 0.001MHz ±(3.0% reading +3) 1~99% 0.1% Continuity Test The resistance is Open circuit voltage is <30, the buzzer about 1V will sound and Overload...
-
Page 17: Battery Replacement
Battery & Fuse Replacement Battery Replacement 1. Turn off the power supply of the instrument, and remove the probe on the instrument. 2. Use screwdriver to unscrew screws fixing the battery cover, remove the battery cover. 3. Remove old batteries, replace with new batteries of the same specifications. - Page 18 Calibration Calibration To maintain the integrity of measurements, Arctic Hayes recommends that the multimeter is calibrated annually at an approved Calibration Laboratory. Arctic Hayes can offer this service, please contact sales@arctic-hayes.com or call +44(0)113 271 5245 to arrange.
-
Page 20: Limited Warranty
Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
