ENGLISH
Congratulations to the purchase of this product. Please read this manual thoroughly prior to using the product in order to
benefit fully from all features.
BUTTONS
ON/OFF: Hold for ON/OFF, press to switch modes.
PREV/UP: Press to go to previous song. Press in selfie-
mode to take a photo with your mobile phone.
NEXT/DOWN: Press to go to next song. Press in selfie-
mode to take a photo with your mobile phone.
PLAY/PAUSE: Press to change between play and pause.
Hold to turn the microphone function off.
REC: Press and hold shortly to change voice style.
The voice transformer allows to change between 4
different voice styles.
+: Increase volume.
-: Decrease volume.
SCAN : Turn on the 2 microphones to bluetooth mode..
Double short press scan button of one microphone, then these 2 microphones will be TWS
OPERATION
1.
Supply power: hold the "ON/OFF" button to power up the device.
2.
BT connection: enable BT on your smartphone and connect with the microphone. The microphone emits a specific
tone to indicate that the connection has been successful.
3.
Adjust volume: adjust the microphone volume to a suitable level.
4.
Start your Karaoke session!
RECORDING WITH SMARTPHONE
1.
Connect the "recording" cable (micro-USB to 3.5mm jack not supplied). Insert the micro-USB end of the cable in the
micro-USB slot on the bottom interface of the microphone. Plug the 3.5mm jack end of the cable in the 3.5mm jack on
your smartphone.
2.
Open your favourite Karaoke or other recording app and record your Karaoke adventures.
3.
Save the song: operate according to the instructions of your favourite Karaoke or recording software.
TWS FUNCTION
1.
Turn on the 2 microphones
2.
Make these 2 microphones under bluetooth mode
3.
Double short press ''SCAN'' button of one microphone. Then TWS is connected. Connect any of these 2 microphones
by bluetooth to the mobile phone. Then when play music, it will play on both microphones together.
TECHNICAL SPECIFICATIONS
Output power
: 5W
Frequency response
: 100 Hz-10kHz
SPL max
: >115dB
Power supply
: Built-in 18650 Li-battery
Battery capacity
: 800 mAh DC5V charging
Bluetooth freq and power : 2402-2480MHz / 2.18dBm
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.
The undersigned, MSC Distribution, declares that radio equipment of the STAR-SING DUO type
and Boomtone DJ brand complies with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.boomtonedj.com/boomtonedj-star-sing-duo-p90300.html
Imported by : MSC DISTRIBUTION 9 rue Camille Flammarion, 91630 Avrainville FRANCE
STAR-SING DUO
.
