Titan Pro 11 Ton Electric Log Splitter –

Operation Guide

This guide will show you how to operate your Titan Pro TPLS11TV electric log splitter. For

further information, please email

Please ensure that the oil cap is loosened before use as this works as a bleed valve.



Connect your plug to the power supply. Turn on the log splitter using the green button

above the motor.



To operate the ram head downwards, first pull the dead man's handle (on the right of

the machine when operating) fully down.

customerservices@titan-pro.co.uk

or call 01258 489161.

Table of Contents

Need help?

Do you have a question about the TPLS11TV and is the answer not in the manual?

Page 1 Titan Pro 11 Ton Electric Log Splitter – Operation Guide This guide will show you how to operate your Titan Pro TPLS11TV electric log splitter. For further information, please email customerservices@titan-pro.co.uk or call 01258 489161. Please ensure that the oil cap is loosened before use as this works as a bleed valve.
Page 2  Whilst operating the dead man’s handle, move the operating handle (on the left of the machine when operating) out, to approximately 45° from the machine, then pull down slowly to find the first (splitting) speed. Pulling this lever to its fullest extent will activate the faster (transition) speed.
Page 3  For storage purposes, you may want to retract the ram into its housing. In order to do so, the ram head must first be in the down most position. In order to retain it in this position, you must first remove the cotter pin and the clevis pin to allow the ram to retract downwards.
Page 4  When the ram head is down, you can then replace the cotter pin and the clevis pin in order to lock this into position. Please also see the following YouTube video, which gives information on raising the ram, first use of the machine and transportation mode: https://youtu.be/eTARv0eaqpU...
