Hourglass eco-start basin mixer range

Advertisement

Quick Links

Dynamic Water Pressure
Max: 5.0 bar
Min: 0.2 bar
2.0
3.0
1.0
4.0
0
5.0
Pressure
BAR
Maximum Static Pressure: 10.0 bar
Pack Contents
Flexible Tails
x2
x1
Clicker Waste inc. Upper
Washer, Lower Washer
and Backnut
All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and
receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance.
Before installing this product the water supply must be thoroughly flushed in order to remove any swarf, solder etc.
Full access must be made available for future maintenance/servicing purposes.
This product must not be modified in any way as this will invalidate the guarantee.
Hourglass Eco-Start Basin Mixer Range | HOU ES BAS (D1)
Specifications
Inlet Water Temperature
Maximum Hot 60°C
Features
Eco Start
Tap Body
x1
x1
Base Seal
Tools Required for Installation/ Maintenance
x1
Fixing Kit
Adjustable Spanner
Prior to Installation
Installation Instructions
Please leave these instructions
Inlet Connections
60°C
1/2" BSP
Flexible Tails
Operation
2.5mm
Hexagonal Keys
& User Guide
with the end user
M24 Coin Slot
Temperature Control
For cold water, position the handle
On
straight forward so it is parallel with
the spout (the handle will stop here
when pushing it to the right)
To increase temperature, turn the
handle to the left
The temperature will gradually
rise the further the rotation of the
handle
The handle will cease to turn once
it is at a 90° angle, supplying the
maximum temperature
9mm
1.0mm
Cross Head
Box Spanner
Screwdriver
(fixing rod nut)
Spare Parts
To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your
Outlet
Aerator
27mm
Box Spanner
(cartridge)
product.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOU ES BAS (D1) and is the answer not in the manual?

Questions and answers

Summary of Contents for Bristan HOU ES BAS (D1)

  • Page 1 Prior to Installation Spare Parts All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
  • Page 2 Important The images shown are for Look underneath the illustrative purposes only. tap body to observe fixing kit rod(s) and The product you have purchased tail inlet positions may look different to those pictured in this booklet but will follow the same installation steps.
  • Page 3: General Cleaning

    General Cleaning Bristan products are made from premium Push the centre down to close the waste. materials, with hand polished, electroplated, PVD or EPD finishes. Your taps or shower should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth.
  • Page 4 Love Your Chrome Bristan offers an effective chrome-friendly cleaning kit for use with your taps and showers. Scan the QR Code or search for ‘CLEAN KIT01’ on Reverse the steps to www.bristan.com.
  • Page 5: Troubleshooting

    BristanTV Our Guarantee At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind. Your guarantee starts from the purchase of your product, but you can still benefit from registering it for easier identification in the unlikely event of a manufacturing fault, please visit www.bristan.com/register...
