Rapsodo PITCHING 2.0 Quick Start Manual page 2

5. CALIBRATION
Connect the RCE by tapping the
'Refresh'. To Calibrate, tap the
right of the app then tap 'Recalibrate'.
The red line in the azimuth view should go directly
middle of home plate.
!
Angles should be as close to
6. DISPLAYS
Red
Not ready
Green
Data ready, monitor ready
Blue
Processing data
(wait for green light to pitch again)
Power Battery Monitor
Connection to App
7.
MAINTENANCE
The monitor and the RCE must be charged separately. The monitor
is charged using the provided right angle Micro USB Cable and
the RCE is charged with the provided USB-C cable.
For additional resources visit the
Rapsodo Learning Centers
'Play' tab and then tapping
'Monitor' icon on the bottom
0 degrees and 14 degrees as
RCE and monitor connected.
RCE and monitor connected to application, needs calibrated or on 'Pause Mode'.
Ready to record data.
Data processing.
RCE switched off and charging.
Warning for low battery, please recharge monitor.
RCE turned on, not connected to app and monitor.
RCE turned on, connected to app but not the monitor.
BASEBALL
down the
possible.
Green
Succesfully Connected to RCE though USB
Red
Not connected to RCE, Waiting for USB Sync
Amber
Charging (switched off)
Gray
Off
SOFTBALL
USB Cables Charger
support@rapsodo.com
844.772.7763
