INSTALLATION MANUAL
JWS/M/W510RM (E)
SAFETY INFORMATION
• Please read and follow this product guide.
• Servicing and installation of this product must only be done
by qualified electrical personnel.
• Do not expose components inside this product to dripping or
splashing. Liquids may cause failure and/or fire hazard.
• Replace with Maxspid-approved battery only. Incorrectly
replaced battery may cause failure and/or fire.
• Match the polarities of the mains supply with the terminal
block and ensure it is firmly secured. Mismatch may cause
electric shock.
CLASSIC
LED EMERGENCY EXIT LIGHT
Ver. 1709SEP06
JWS/M/W5100
1
Advertisement
Table of Contents
Related Manuals for MAXSPID CLASSIC JWS/M/W510RM
Summary of Contents for MAXSPID CLASSIC JWS/M/W510RM
- Page 1 • Do not expose components inside this product to dripping or splashing. Liquids may cause failure and/or fire hazard. • Replace with Maxspid-approved battery only. Incorrectly replaced battery may cause failure and/or fire. • Match the polarities of the mains supply with the terminal block and ensure it is firmly secured.
- Page 2 INSTALLATION GUIDE Unit Description Mounting Base Charging Indicator & Test Switch Inner Plate Diffuser & Legend...
- Page 3 Mounting Guide *Seal all cable entry/mounting screws with cable gland/rubber gaskets for weather-proof application *Wedges for wall mounting are included in package Mains Supply Connection...
- Page 4 Note: • LED charge indicator will be lit if installation is done properly. • For first usage, ensure mains supply to the unit is turned on for 24 hours to fully charge the battery. *Interrupting the mains supply will discharge the battery. •...
