User Manual
193
1 POWER FUNCTION:
TYPE
CAPACITY
DC IN
TYPE-C
PV IN
www.ACOPower.com
Wh
52000mA
Portable Power Station
52000mAh/192.4Wh
DC 11-30V 5A MAX
PD60W
DC 12-30V 5A MAX
DC OUT
TYPE-C
USB1
USB2
USB1&USB2
BATTERY OUT
Add: 4120 Valley Blvd, Walnut, CA 91789, USA
Tel:+1-626-575 7722 Fax: +1-626-737 1140
Email: sales@acopower.com
Power Your Green Life!
DC 12-16-20-24V 5A MAX
PD60W
QC3.0 18W MAX
QC3.0 18W MAX
DC 5V 3. 5A MAX
DC 12-16.8V 10A MAX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACOPOWER X230
Summary of Contents for ACOPOWER X230
- Page 1 TYPE-C PD60W USB2 QC3.0 18W MAX PV IN DC 12-30V 5A MAX USB1&USB2 DC 5V 3. 5A MAX BATTERY OUT DC 12-16.8V 10A MAX Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com...
- Page 2 OUTPUT/DC5521:Hold Press 3 Sec+Short Press,DC OUT DC 12V/16V/20V/24V Meet the Voltage Requirements of Different Equipment OUTPUT2:DC 12V~16.8V Dedicated to ACOPOWER Refrigerator USB/QC3.0:Support Devices Mobile Phones，Tablet PC, Digital Camera and other USB/QC3.0 Digital Devices,Plug a USB Cable into one of the USB Ports，Device auto Charging...
-
Page 3: Power Application
Battery Charges Battery Life / Battery Life / Battery Life / (60W) for 2.5 h 6 Full Charges 18 Full Charges 2.7 Full Charges Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com... - Page 4 Power Your Green Life! 2.2 APPLICATION(2): For ACOPOWER /LIONCooleR PX /VX Series 2.3 APPLICATION(3):LED LIGHT Double Press:LED Light on Double Press+Short Press，LED Emergency Fishing Light on Double Press:LED Light off Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140...
-
Page 5: Power Charging
Solar Charge :MAX Current :5A ,MAX Solar Panel Open Circuit Voltage 30V(DC5521 Connector) Car /Truck Charge （12V/24VCar /Truck）(DC5521 Connector) Wall Charge ：INDC 11~30V MAX 5A ,(DC5521 Connector) Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com... - Page 6 Power Your Green Life! TYPE-C Fast Charger PD60W(USB -C) Built In Refrigerator For Charging:Through PV Plug or DC12V/24V DC Plug Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com...
- Page 7 Car Charging Solar Charging :MAX Current :4A ,MAX Solar Panel Open Circuit Voltage 30V，Through the PV Plug of the Refrigerator By MC4-5521 Cable： Solar Charging Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com...
-
Page 8: Power Output
If the machine malfunctions, you can refer to the table below to troubleshoot. If you still have questions,please contact the official after-sales customer service for help. Do not disassem- ble or repair the machine by yourself Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com... - Page 9 Electrical connection Check the internal electrical Refrigerator disconnected or input voltage connections of the too high exceeding 30V refrigerator,/Reduce input voltage Unable to power on Battery drain Battery drain Replace PD charger PD charging power too low The power of PD charger itself is very low, please check Replace PD charger Not active Disconnect it and then reconnect it Not working when placed OUT2 output not turned on OUT2 output not turned on in the refrigerator Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com...
- Page 10 Using your Power pack in temperatures below O℃/32°F or above 40℃/104°F is highly inadvisabie and will likely cause irreparable damage to the internal battery. Add: 4120 Valley Blvd, Walnut, CA 91789, USA www.ACOPower.com Tel:+1-626-575 7722 Fax: +1-626-737 1140 Email: sales@acopower.com...
