HiSpec HSEM/LEDEB Quick Start Manual

ARROW UP: HSEM/LEDEB
ARROW DOWN: HSEM/LEDEBD
RHINE UNIVERSAL EXIT BOX

MAIN FEATURES:

• 3 hour emergency time
• Maintained/Non-Maintained switchable
• Can be non-maintained by removing the wire link
• Metal casing
• Manual test button
• Screen printed legend included (different directions sold separately).
• 2x20mm conduit entry
• 3 year guarantee
This instruction leaflet contains important information on the correct
installation and operation of your fitting. Read this leaflet fully before
attempting installation and retain for future reference.
The exit box complies to IEC60598-2-22 and IEC62034.

SPECIFICATION

Wattage: 2.5w
Wattage (emergency mode): 1.5w
Lumen: 35lm
Lumen (emergency mode): 17lm
Input Power: AC 220V-240V 50Hz / 60Hz
Light source: 6 pcs SMD 5730 LED
Battery (LiFePo4): 3.2V 1.6Ah
Battery Life: Up to 4 years
Battery protection: Overcharging and over discharge
protection
Charging time 24 Hours
Minimum emergency duration: 3 Hours
IP Rating: IP20
Warranty 3 years
HISPEC ELECTRICAL PRODUCTS LTD UNIT 21 CHORLEY NORTH BUSINESS PARK, CHORLEY, LANCASHIRE PR6 7BX | WWW.HISPEC.CO.UK | VERSION 17112022

MAINTAINED/NON- MAINTAINED

User can turn the S2 to the "ON" side when they want the lamp to stay
on maintained-mode. Switch the S2 to"1" side will make the lamp run in
Non-maintained-mode.

INDICATOR

• When AC power is on, red indicator on,the battery is charging.
• When the battery is fully charged,the indicator will turn to green.
• When AC power off, the indicator will turn off.

MANUAL TEST

Press the "test button"for 1 second,the system will begin"manual test"for
5s,during this time,the green indicator will show a "1HZ blink".
AC POWER ON (CHARGING)
Orange indicator shows a 1HZ Battery Fault:
blink
• Check if the battery is not
connected properly.
• Check if the battery wire is
broken.
• Check if the battery voltage is
lower than normal
BATTERY MUST BE CHARGED FOR 24 HOURS PRIOR TO
DURATION TEST.
MANUAL TEST & SIMULATE AUTO TEST
Press the TEST switch for 1 The system will begin"manual
second test"for 5s,during this time,the
green indicator will shows a "1HZ
blink".
Press the TEST switch for 3 The system will begin"functional
seconds test"for 2 mins,during this time,the
green indicator will shows a "3HZ
blink".
Press the TEST switch for 5 The system will begin"duration
seconds test"during this time,the green
indicator will shows a "5HZ blink".
AC POWER OFF (DURATION OR TEST-MODE)
Orange indicator remains on "lack of battery capacity", user
needs to make sure the battery
has charged for 24hrs.
Orange indicator shows a 3HZ "LED fault", user needs to make
blink sure the LED lamp is connected
well,or has not been broken by
other reasons.

WARNING

1. Disconnect the AC power during installation.
2. This product should not be installed in places such as outdoors, humid
environments and chemically polluted air.
3. This product should have a permanent "live" supply that cannot be
switched off accidentally.
4. To ensure the product is operating normally,it should be checked
regularly.
5. The products have been discharged before leaving the factory. So it
needs to be charged 24 hours when used .
6. If the product is in storage or not used for a long time, it should be
charged and discharged once every three months, in order to protect
the battery performance.
7. Please keep this manual for future reference.
8. See reverse for maintenance record.
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your
used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmental safe recycling.
