- Page 1 U S E R M A N U A L I N S T R U C T I O N A L M A N U A L Product name Electric to go here Configura Advance Product description to go here Configura Advance Chair Electric Configura Advance enablelifecare.com.au...
-
Page 2: Table Of Contents
This manual is important for understanding how to use your new Configura Advance chair; please read it before use. If you need further information, or require the information in a different format, please contact Highgate Healthcare. See Contact Details in Section 20. Electric Configura Advance... -
Page 3: General Warnings
12. Do not move the chair when it is in the forward tilt position. 13. This chair is not recommended for users outside the weight specifications detailed in Section 4. Electric Configura Advance... -
Page 4: Means Of Delivery
The Configura Advance chair is intended to be used as a portable chair with built in size, pressure and posture options in the acute, long-term care and homecare environments. The chairs are intended for patients who do not exceed the safe working load and height recommendations for the device. Electric Configura Advance... -
Page 5: Technical Specification
(-4°F to +122°F) Environmental information: Always store out of direct sunlight. If the chair is stored in conditions outside the normal NOTE: operating range, it should be allowed time to stabilise, in normal operating conditions, before use. Electric Configura Advance... - Page 6 Configura Advance Chair position setting ranges: STANDARD POSITION RANGE SETTINGS FORWARD TILT POSITION SETTING Key parts of the chair: BACKREST RIGHT SIDEPIECE LEFT SIDEPIECE SEAT LEG REST FOOT PLATE Electric Configura Advance...
-
Page 7: Accessories
First recharge of the battery must be no later than 12 months - Recharging during storage after production date stated on the label. Thereafter the battery must be recharged at least every 12 months. Electric Configura Advance... -
Page 8: Assembly
1. following components should present: A. Chair frame assembly B. Right Sidepiece C. Left Sidepiece D. 3 x Backrest cushions FIGURE 1 – Chair as delivered (side pieces are loose) Footplate F. Instruction manual Electric Configura Advance... - Page 9 Insert the clevis pin (Fig 4, Item 1) through the clevis at the back of the main frame, the gas strut and the backrest lockout slide. Secure the pin with the R-clip (Fig 4, Item 2). FIGURE 4 Electric Configura Advance...
- Page 10 – Top. The middle and bottom cushions are identical. FIGURE 6 11. Ensure the female poppers on the overlay are engaged on the male poppers on the frame, 3 EA on left- and right-hand side. (Fig 7, Item 1) FIGURE 7 Electric Configura Advance...
-
Page 11: Chair Adjustment
A clinical assessment and risk assessment MUST be carried out by suitably trained and qualified personnel before adjustments are made to the chair. Do not adjust the width, depth or height of the chair when a patient or user is in the chair. Electric Configura Advance... - Page 12 (Fig 13, Item 1) Turn the lever clockwise to release the backrest slide mechanism and move the backrest to the desired measurement with the other hand. The depth setting can be read off the scale on the FIGURE 13 Electric Configura Advance...
- Page 13 Refit the tilt gas strut clevis pin and R clip in the required CHAIR AT LOW CHAIR AT HIGH POSITION POSITION hole of the base frame. (Fig 19). 10. Place the chair back on its wheels and refit the footplate FIGURE 17 – Chair support fixings (See section 8). Electric Configura Advance...
- Page 14 POSITION FIGURE 18 – Actuator and chair mounting HIGH SEAT HEIGHT POSITION LOW SEAT HEIGHT POSITION FIGURE 19 – Actuator mounting After any of these adjustments a functionality check must be carried out (See section 11). NOTE: Electric Configura Advance...
-
Page 15: Footplate Operation & Adjustment
(Fig 20, Items 1&2). Turn the levers on the two plungers towards the front of the chair until they latch. The lever arm plungers are now locked in the open position. (Fig 21). Pull the footplate out. FIGURE 23 Electric Configura Advance... -
Page 16: Electric Controls
3, 4 and 5 on Figure 28. 4. Electric Leg rest – The leg rest can be adjusted between 75 degrees and 160 degrees. The buttons marked 1 and 2 on Figure 28 are used to adjust this angle. Electric Configura Advance... - Page 17 If locking out the backrest is not required, there is a Velcro strap that can be used to hold the lever in the unlocked position – see Figure 30. FIGURE 29 FIGURE 30 Electric Configura Advance...
-
Page 18: Using The Castor Brakes
To lock the castor brake, press on the outer edge of the red lever. The lever will flip up. To unlock the castor brake, press on the top of the red lever to bring it back horizontal. Electric Configura Advance... - Page 19 Figure 30 shows the brake locked. To unlock the brake, press the front green part of the foot lever down until the brake disengages. Figure 31 shows the brake unlocked. FIGURE 30 – Brake locked FIGURE 31 – Brake unlocked Electric Configura Advance...
-
Page 20: Functionality Check
Check that all actions are completed smoothly and without any cables being crushed. Check the correct function of the castors. 10. Ensure the handset cable is routed without any snags or kinked cable. 11. Ensure footrest is fitted securely. 12. Ensure sidepieces are fitted correctly. Electric Configura Advance... -
Page 21: Cleaning & Disinfection
Ensure the backrest lockout slide is released – see section 10 of Backrest will not recline (manual version). this manual. If the Configura Advance chair still does not function correctly, please contact Highgate Healthcare for further advice. Electric Configura Advance... -
Page 22: Storage
Do not carry out maintenance with service user or patient on the chair. Repairs to the Configura Advance chair must be carried by suitably trained and qualified personnel. After any maintenance has taken place a functionality check must be carried out (see section 11). Electric Configura Advance... -
Page 23: Guarantee
CISPR 11 establishments and those directly Harmonic emissions Class A connected to the public low-voltage power supply network that supplies buildings used IEC 61000-3-2 for domestic purposes. Voltage fluctuations Compliance /flicker emissions IEC 61000-3-3 Electric Configura Advance... - Page 24 IEC levels characteristic of 61000-4-8 a typical location in a typical commercial or hospital environment. NOTE: UT is the a.c. mains voltage prior to application of the test level. Electric Configura Advance...
- Page 25 If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the chair. Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m. Electric Configura Advance...
- Page 26 NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. Electric Configura Advance...
-
Page 27: Table Of Symbols
UK and Rest of World Accora Ltd. Accora Inc. Charter House, Barrington Road 9210 Corporate Blvd. Suite 120 Address Orwell, Cambridge Rockville, MD 20850 SG8 5QP, UK Telephone +44 (0)1223 206100 +1 301-560-2400 Email info@accora.care information@accora.care Website www.accora.care www.accora.care Electric Configura Advance... - Page 28 But we do more than just provide products. We give the knowledge and support to help our customers grow their business and deliver better life care. ENABLE LIFECARE PTY LTD T 1300 370 370 enablelifecare.com.au Electric Configura Advance...
