- Page 1 Operating Manual Z-PA.SDL.1 WLAN adapter EN-US Programming device for HMG10P/PMG10P series...
-
Page 2: Table Of Contents
List of contents Baumer List of contents 1 About this document ..........................Purpose............................... Warnings in this manual........................Labels in this manual .......................... Disclaimer ............................Scope of delivery..........................Name plate............................Maintenance and service life....................... Approvals and warranty ........................Temperature range for operation and storage .................. - Page 3 Baumer List of contents Firmware update ..........................23 Encoder parameters..........................24 Parameter Download .......................... 25 Encoder monitoring ..........................26 8 Technical data ............................. 27 Dimensions ............................27 9 Licenses ............................... 28 V2 | Z-PA.SDL.1 WLAN adapter Operating Manual...
-
Page 4: About This Document
In addition, the local occupational health and safety regulations and general safety regulations apply. The illustrations in this manual are examples only. Deviations are at the discretion of Baumer at all times. Warnings in this manual Warnings draw attention to potential personal injury or material damage. -
Page 5: Scope Of Delivery
About this document Scope of delivery Delivery includes: 1x Z-PA.SDL.1 WLAN adapter 1x power connector with adapter plug for different countries In addition, the following documentation is accessible in digital form at www.baumer.com: Operating manual Declaration of Conformity Connection cables Name plate... -
Page 6: Approvals And Warranty
About this document Baumer Approvals and warranty Declaration of conformity according to the prevailing country-specific directives. We grant a 2-year warranty in line with the conditions of the German Electrical and Electronic Manufacturers' Association (ZVEI). INFO warranty seal Any breaking of the seal provided at the device will result in loss of warranty. -
Page 7: General Information
Used electrical and electronic devices may not be disposed of in household waste. The product contains valuable raw materials that can be recycled. There- fore dispose of this product at the appropriate collection point. For additional in- formation visit www.baumer.com. V2 | Z-PA.SDL.1 WLAN adapter Operating Manual... -
Page 8: Transport And Storage
Transport and storage Baumer Transport and storage Transport NOTICE Material damage due to improper transport. a) Ensure maximum diligence when unloading the delivered packages as well as when trans- porting them inside the company. b) Note the information and symbols on the packaging. -
Page 9: Description
Baumer Description Description Functionality The Z-PA.SDL.1 WLAN adapter is for programming and monitoring the HMG10P/PMG10P en- coder series. The encoder parameters below enable parameterization (depending on encoder version). Doing so requires registration as "ADMIN": Resolution Singleturn (SSI) Resolution Multiturn (SSI) -
Page 10: Required Connection Accessories (Not Included In The Delivery)
Description Baumer Required connection accessories (not included in the delivery) 4.2.1 For HMG10P/PMG10P with mating flange connector(s) INFO The M23 T-piece does not provide encoder power supply via the programmer (pins 7 + 10 not assigned). Order number Version 11210827... -
Page 11: For Hmg10P/Pmg10P With Ssi Terminal Box
Baumer Description 4.2.2 For HMG10P/PMG10P with SSI terminal box INFO For ONLINE mode the connection terminal can be detached and the cable ends SA (green) and SB (yellow) can be directly connected to the encoder terminals or to any existing cables of the machine/control cabinet (customer installation). -
Page 12: For Hmg10P/Pmg10P With Bus Terminal Box
Description Baumer 4.2.3 For HMG10P/PMG10P with bus terminal box INFO For ONLINE mode the connection terminal can be detached and the cable ends SA (green) and SB (yellow) can be directly connected to the encoder terminals or to any existing cables of the machine/control cabinet (customer installation). -
Page 13: Connecting The Wlan Adapter To Encoder
Baumer Connecting the WLAN adapter to encoder Connecting the WLAN adapter to encoder DANGER Risk of injury by rotating shafts a) When connecting programmer to encoder, make sure that each machine connected to the encoder is down and protected against any inadvertent switchon. -
Page 14: Electrical Installation
Electrical installation Baumer Electrical installation DANGER Injury by secondary damage Failure or signal errors by connected sensors may entail system control errors. a) Eliminate secondary damage by relevant safety precautions in the downstream electronics. NOTICE Damage to the WLAN adapter due to incorrect supply voltage. -
Page 15: Reset Button
Baumer Electrical installation RESET button The RESET button can be used for programmer shut down, restart or restore default. Press RESET button with a pointed object (e.g. paper clip) and hold for ... for >0.3 seconds Programmer is shut down. -
Page 16: Online Mode
Electrical installation Baumer 6.3.2 ONLINE mode Use cases for ONLINE mode are monitoring, diagnostics and parameterization of an encoder in installed condition. In this case, the encoder is installed in a machine or facility. Encoder operating voltage supply is by the machine/ controller. Programmer power supply requires a separate source. -
Page 17: Establishing P2P Connection With Network Cable
Baumer Electrical installation 6.4.1 Establishing P2P connection with network cable Using a network cable, you can establish a direct network connection to the programmer. Instruction: a) Set the Network Mode switch to "P2P". b) Connect PC and programmer with the network cable. -
Page 18: Establish Connection To Programmer Via Web Browser
Establish connection to programmer via web browser Network connection to the programmer having been established enables direct access via web browser. Instruction: a) Open the web browser. b) Go to website http://baumer.sensor(alternatively, call IP address 10.0.0.1) ü Window Connection opens for connection to the connected encoder. - Page 19 Baumer Electrical installation d) In the event the connection to the connected encoder is not automatically established, per- form the settings yourself at Advanced. ü The programmer has been connected. INFO In the event of extended drops in the mains voltage, the programmer performs restart and the web browser may lose the programmer connection.
-
Page 20: Web Interface Description
HMG10P & PMG10P encoders. In case of any questions, please contact your local Baumer Sales team or distributor. Other user names are intended for manufacturers only (e.g. repair or maintenance). -
Page 21: System
Baumer Web interface description System Window System is for system settings of network, WLAN and system status. Ill. 7: System window 7.3.1 Network settings (LAN) Window Network settings is for adjustments in wired network connection. Possible connection options: Network cable for direct PC connection (P2P). Here, the programmer acts as a DHCP server. -
Page 22: Wlan Settings
Web interface description Baumer Switch network Infrastructure Infrastructure mode Manually Manual Ill. 9: Switch network mode 7.3.2 WLAN settings Window WLAN settings is for adjustments in the WLAN connection (mode, SSID, password and security level). Possible connection options: Programmer acts as access point. -
Page 23: System Control Panel
Baumer Web interface description 7.3.3 System control panel Window System Control Panel is for programmer restart or shutdown. Furthermore, it is used to restore default in the programmer. INFO Restoring default results in all saved data being lost. Ill. 11: Window System Control Panel... -
Page 24: Encoder Parameters
Web interface description Baumer Encoder parameters Window Parameterization is for editing encoder parameters. Parameter options: Incremental parameters: Additional output 1 and 2 (number of pulses per revolution) SSI Absolute Parameter: Resolution Singleturn (SSI), Resolution Multiturn (SSI), Binary or Gray Code (SSI Speed) -
Page 25: Parameter Download
Baumer Web interface description Parameter Download Window Diagnosis is for encoder parameter download for further processing and documenta- tion. Ill. 14: Window Diagnosis V2 | Z-PA.SDL.1 WLAN adapter Operating Manual... -
Page 26: Encoder Monitoring
Web interface description Baumer Encoder monitoring Window Monitoring provides encoder position, speed and temperature. Monitoring does not interact the encoder - controller communication. This means, the encoder signals will be always fully available for controller monitoring. Therefore, monitoring signals are not time-synchronous and can only be used for quality assessments. -
Page 27: Technical Data
Baumer Technical data Technical data Z-PA.SDL.1 Electrical Data Operating voltage Ub 24 V DC Encoder supply 5 V DC and 12 V DC via mating 15-contact D-SUB port Inputs SSI CLOCK+, SSI CLOCK-, SSI DATA+, SSI DATA-, Analog, RS485-A (SA), RS485-B (SB),... -
Page 28: Licenses
Baumer Licenses Baumer uses open source software licensed by copyright holders of free licenses like GNU General Public Licence (GLP Version2, GPL Version3) and GNU Lesser General Public Li- cence (LGPL), MIT License, zLib License, and licenses derived from the BSD License. - Page 29 Baumer List of illustrations List of illustrations Ill. 1 Programmer connection in OFFLINE mode..................15 Ill. 2 Programmer connection in ONLINE mode..................16 Ill. 3 Switch network mode .......................... 17 Ill. 4 Establishing WLAN connection in the Windows operating system ............. 17 Ill.
- Page 32 Baumer Germany GmbH & Co. KG Bodenseeallee 7 DE-78333 Stockach www.baumer.com...
