- Page 1 ARCTIC HAYES DIGITAL VOLTAGE INDICATOR User Manual AHVOLT1 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Safety Instructions The instrument manual contains warning and safety rules which have to be observed by the user to ensure safe operation of the instrument and to maintain it in safe condition. Therefore read through these operating instructions before use. Warning.
- Page 3 Safety Instructions • Never attempt to use the instrument if its surface or your hands are wet. • Keep your hands and fingers behind the barriers during the measurements. • Never unlock and open the battery case during measurements. • Verify proper operation on known source before using or taking action as a result of indication after use.
- Page 4 Physical Appearance High voltage indication Voltage reading L/R LEDs for phase rotation test Power LED Polarity indication Continuity test LEDs for voltage LCD display L2 Probe + L1 Probe - Penlight Barrier Protection Probe 600V CATII clip Penlight switch Protection 600V CATIV Battery compartment...
- Page 5 Measurement Auto-power test Short circuiting the probes as follows powers on the instrument automatically and goes into self diagnostic test. Instrument may power on when replacing tips or due to the effect of static charge. Self diagnostic test Battery voltage is normal when Power LED is lighting up when battery voltage is below 2.4 +/- 0.1V Power LED flashes or goes off, replace batteries.
- Page 6 Measurement Handy construction Diameter of pitch between tips are changeable by the user. Voltage test (double pole test) • Connect both probes to the object under test. • The voltage is indicated by LED and LCD display.
- Page 7 Measurement Voltage polarity is indicated in the following manner: NOTE: when the L2 probe + is the positive (negative) potential, polarity indication LED indicated +DC (-DC). High voltage indication Grasp the instrument firmly and connect both probes to the object under test. Live circuit LED lights up when a voltage of approx.
- Page 8 Measurement Phase rotation test L LED and R LED for phase test rotation may operate on various wiring systems, but effective testing result can be obtained only on three phase 4 wire system. Grasp the instrument firmly and connect both probes to the object under test.
- Page 9 Measurement NOTE: In continuity mode the instrument works in the same way as the self diagnostic test. Penlight function This voltage tester is equipped with a built in LED light to illuminate the measurement point in dimly conditions. Pressing the penlight switch turns on the light.
- Page 10 Measurement Warning. Confirm that the battery case is properly locked prior to any measurement. • When batteries have leaked, the device must not be used any longer. Before you can use it again, it must be checked by our customer service. •...
- Page 11 Specification Capacitance LED voltage range 12-690V LED resolution 12 / 24 / 50 / 120 / 230 / 400 / 690V Tolerance 7 ± 5V (12V) 18 ± 5V (24V) 37.5 ± 5V (50V) 75% ±5% (120 / 230 / 400 / 690V) Response time <0.5s LED LCD voltage range...
- Page 12 Maintenance Maintenance When using tester in compliance with the instruction manual, no particular maintenance is required. If functional errors occur during normal operation, stop using it and contact your nearest authorized service centre. If the device is not used for an extended period of time, the batteries must be removed to prevent the risk of leaking batteries and damage to the device.
- Page 13 IP rating - first number - protection against solid objects, second number - protection against liquids AHVOLT1 is protected against dust and against water spray. 1. EN 61010-1 2. EN 61243-3 3. EN 61010-2-033 4.
-
Page 14: Limited Warranty
Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
