- Page 1 ARCTIC HAYES VOLTAGE DETECTOR NON-CONTACT User Manual AH12 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Safety Instructions Warning. To avoid possible electric shock or personal injury: Please read the instruction manual carefully before use and strictly observe the safety rules and warnings listed in the instruction manual. • If the Voltage Detector is not used according to the instructions the protection function provided by the NCVD (Non-Contact voltage detector) may be affected and invalidate any warranties.
- Page 3 Safety Instructions • When using the Voltage Detector, if the tip does not illuminate or no beeping sound,voltage could still be present. Voltage Detector indicates active voltage in the presence of electrostatic fields of sufficient strength generated from the source (Mains) voltage.
- Page 4 Specification Environment condition of using Operating Temperature 0~40°C Storage Temperature -10~50°C Humidity ≤ 80% Battery 2 x 1.5V AAA General technical specifications Operating Voltage AC Voltage: 12~1000V (50/60Hz) High Sensitivity 12 ~ 1000V Middle Sensitivity 48 ~ 1000V Low Sensitivity Distinguish the Live &...
- Page 5 Measurement Operation Turn NVCT Functionality On: 1. Press and release the power / sensitivity button. 2. Listen for single-beep sound and watch for the green LED to illuminate and remain lit indicating the unit is powered on. Turn NVCT Functionality Off: 1.
- Page 6 Measurement Operation How to use as live / neutral detector: When tester is used to test for live / neutral the tester will beep and proximity sensor will illuminate on detection of Live terminal / receptacles. Turn Flashlight On/Off: 1. Press and release “Flashlight” button to turn flashlight on or off.
- Page 7 Battery Replacement Low Battery Indication: 1. When the battery drops to approximately 2.4V, the green LED will turn red LED. 2. When the battery drops to approximately 2.1V, the detector will automatically power off. Battery Replacement 1. Rotate the battery cover anti-clockwise then remove the old batteries.
- Page 8 Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
