- Page 1 ARCTIC HAYES ATEX VOLTAGE DETECTOR NON-CONTACT User Manual AHATEX12 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Safety Instructions Warning. Read all instructions before using the appliance and retain for future reference. • Please follow all safety operation instructions. • Test using a known live source in the AC voltage range to confirm the detector is working properly before use.
- Page 3 Physical Appearance Screw on battery cover Flashlight Flashlight on/off button 12V mode button Detector on/off button LED indicators Detector tip Worklight Height - 156mm Weight - 47g (without Width - 42mm batteries) Length - 20mm...
- Page 4 Measurement Operation • Turning the Detector on: Momentarily press the detector On/Off button (5). The sounder will beep once and the green LED will illuminate to indicate that the detector is on and ready for use. • Turning the Detector off: Momentarily press the On/Off button.
- Page 5 Measurement Operation • Low Voltage Mode (12 to 1000V AC): Press and hold the 12V button (4). The green LED will change to yellow to indicate the detector is in the low voltage mode. While pressing the 12V button, place the tip of the detector near an AC voltage.
- Page 6 Measurement Operation • Auto Power Off: To conserve battery life, the detector will automatically turn off after approx 5 minutes of inactivity. When powering down, the alarm will beep twice and the green LED will turn off. • Flashlight: Momentarily press the Flashlight button (3) to turn the flashlight on or off.
- Page 7 Measurement Operation & Specification 4. Press the cover onto detector and rotate clockwise until engaged. Do not use excessive force. 5. The IP67 dust and water ingress protection level is determined by the correct fitting of this cap. NOTE: When batteries are loaded for the first time, please remove the white, rectangular security strip before installing the batteries.
- Page 8 Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
