SERVICE
LED TV
UN58J5190BF
LED TV
Chassis : UNE50
Model
: UN58J5190BF
Manual
1. Precautions
2. Product specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UN58J5190BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung UN58J5190BF

Summary of Contents for Samsung UN58J5190BF

  • Page 1 LED TV Chassis : UNE50 Model : UN58J5190BF SERVICE Manual LED TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UN58J5190BF...

  • Page 2: Table Of Contents

    Contents 1. Precautions ........................1-1 1-1. Safety Precautions ......................1-1 1-1-1. Warnings ........................1-1 1-1-2. Servicing the LED TV ....................1-1 1-1-3. Fire and Shock Hazard .....................1-1 1-1-4. Product Safety Notices .....................1-2 1-2. Servicing Precautions ......................1-3 1-2-1. General Servicing Precautions .................1-3 1-3. Static Electricity Precautions ....................1-4 1-4.
  • Page 3 4-5. Software Upgrade ......................4-27 4-5-1. By USB ........................4-27 4-5-2. By Online ........................4-27 4-5-3. Alternative Software (Backup) ................4-27 4-6. The Dimension of J5190 Models ..................4-28 5. Wiring Diagram ......................5-1 5-1. Wiring Diagram ........................5-1 5-2. Connector ..........................5-2 5-3. Connector Functions ......................5-4 5-4. Cables ..........................5-5 5-5.
  • Page 4 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2016 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 5: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 6: Product Safety Notices

    1. Precautions 1-1-4. Product Safety Notices Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc.

  • Page 7: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions An electrolytic capacitor installed with the wrong polarity might explode. WARNING Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. CAUTION If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 8: Static Electricity Precautions

    1. Precautions 1-3. Static Electricity Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground.

  • Page 9: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 10: Product Specifications

    2. Product specifications 2. Product Specifications 2-1. Product information Model UN58J5190AF Front View * W : Width H : High D : Depth Detail View Color Front : Black, Stand : Black With Stand 1308 x 843.4 x 295.9 mm / 51.9 x 33.2 x 11.6 inches Dimensions 58"...

  • Page 11: Product Specification

    Virtual Surround DTS Studio Sound DTS Codec DTS Premium Sound 5.1 3D Sound Sound Customizer Sound Output (RMS) 10W x 2 Speaker Type Down Firing + Full Range Woofer HD Audio Wallmount Sound Mode Multiroom Link Smart TV Samsung SMART TV...
  • Page 12 Voice Control Face recognition Motion control Convergence TV to Mobile - Mirroring Mobile to TV - Mirroring, DLNA Samsung SMART View Wireless TV On - Samsung WOL Notification - BLE Briefing On TV WiDi WiFi Direct Differentiation Wireless Copy Sports Mode...
  • Page 13 Bezel Type Slim Type Normal Front Color Black Light Effect (Deco) Stand Type Square Swivel (Left/Right) Additional Feature Samsung 3D 3D Converter Instant On Camera Built-in Processor PX Ready 21:9 Immersive Picture Mode SCSA Support Accessibility Yes(Zoom) Digital Clean View...
  • Page 14 Eco Sensor Accessory 3D Active Glasses (Included) Remote Controller Model TM1240A Batteries (for Remote Control) Samsung Smart Control (Included) PX (Included) Ultra Slim Wall Mount Support Mini Wall Mount Support Vesa Wall Mount Support Floor Stand Support TV Camera (Included)
  • Page 15 2. Product specifications Item UN58J5190AFXZA Accessory User Manual E-Manual ANT-Cable Power Cable Slim Gender Cable...

  • Page 16: Specifications

    2. Product specifications 2-2-2. Specifications Specifications „ Model UN58J5190AF Item Description Screen Size (Diagonal) 58 inches Display Resolution 1,920 x 1,080 Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated Input Sync Signal H/V Separate, TTL, P. or N. AC Power Voltage &...

  • Page 17: Accessories

    • The part code for some accessories may differ depending on your region. Product Description Code. No Remark BN59-01199F Remote Control & Batteries (AAA x 2) 4301-000103 Power Cord 3903-000853 Samsung Electronics Service center User manual BN68-07181P Holder-Wire Stand BN61-08370A...
  • Page 18 2. Product specifications 2. Product Specifications 2-1. Product information Model UN58J5190BF Front View * W : Width H : High D : Depth Detail View Color Front : Black, Stand : Black With Stand 1308 x 843.4 x 295.9 mm / 51.9 x 33.2 x 11.6 inches Dimensions 58"...
  • Page 19 Virtual Surround DTS Studio Sound DTS Codec DTS Premium Sound 5.1 3D Sound Sound Customizer Sound Output (RMS) 10W x 2 Speaker Type Down Firing + Full Range Woofer HD Audio Wallmount Sound Mode Multiroom Link Smart Service Samsung SMART TV...
  • Page 20 Voice Control Face recognition Motion control Convergence TV to Mobile - Mirroring Mobile to TV - Mirroring, DLNA Samsung SMART View Wireless TV On - Samsung WOL Notification - BLE Briefing On TV WiDi WiFi Direct Localization Analog Clean View...
  • Page 21 Narrow Bezel Bezel Type Slim Type Normal Front Color Black Light Effect (Deco) Stand Type Square Swivel (Left/Right) Additional Feature Samsung 3D 3D Converter Instant On Camera Built-in Processor PX Ready 21:9 Immersive Picture Mode SCSA Support Accessibility Yes(Zoom) One Connect...
  • Page 22 2. Product specifications Item UN58J5190BFXZA Additional Feature Channel List USB-Clone Connect Share™ (HDD) ConnectShare™ (USB 2.0) Movie Connect Share™ Transfer AC/DC TV Embeded POP Extended PVR Game Mode IP Video Closed Caption OSD Language English, Spanish, French Picture-In-Picture BT HID Built-in USB HID Support Feature Upgrade (Evolution Kit Ready) ATSC 3.0 Ready...
  • Page 23 2. Product specifications 2-2-2. Specifications Specifications „ Model UN58J5190BF Item Description Screen Size (Diagonal) 58 inches Display Resolution 1,920 x 1,080 Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated Input Sync Signal H/V Separate, TTL, P. or N.
  • Page 24 • The part code for some accessories may differ depending on your region. Product Description Code. No Remark BN59-01199F Remote Control & Batteries (AAA x 2) 4301-000103 Power Cord 3903-000853 Samsung Electronics Service center User manual BN68-07181P Holder-Wire Stand BN61-08370A...

  • Page 25: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. This LED TV contains electrostatically sensitive devices. Use caution when handling these components. WARNING 3-1. Disassembly and Reassembly Disconnect the LED TV from the power source before disassembly.
  • Page 26 3. Disassembly and Reassemble Description Picture Description Screws Remove screws of Main Board and Power Torque : Board. 7~ 8Kgf.cm 6001-002756 Remove the speakers and power cables. Remove the cables, function assy and Panel drive cable.
  • Page 27 3. Disassembly and Reassemble Description Picture Description Screws Completed disassembly. NOTE Reassembly procedures are in the reverse order of disassembly procedures.

  • Page 28: Disassembly(Ptc)

    3. Disassembly and Reassemble 3-2. Disassembly(PTC) How to disassembly „ Description Picture Description Refer Place TV face up on cushioned table. Remove the ASSY Function assy. Spread the both sides of PTC upper (marked "▼") by use the tool. CAUTION Do not scratch on both side by use tool.
  • Page 29 3. Disassembly and Reassemble Description Picture Description Refer Separate the left and right side of the PTC as shown. Separate the Bottom of the PTC as shown Raise up the PTC Bottom. Disassembly is complete.
  • Page 30 3. Disassembly and Reassemble How to reassembly „ Description Picture Description Refer Attach the PTC Bottom first to the Panel. Secure the plastic latch on the left and right side of the PTC as shown.
  • Page 31 3. Disassembly and Reassemble Description Picture Description Refer Visually inspect the spacing between the PTC and the Panel for equal clearance. CAUTION Combine to stick the PTC Rib into the middle mold.
  • Page 32 3. Disassembly and Reassemble Description Picture Description Refer Assembly is complete.

  • Page 33: Troubleshooting

    TV. The Picture Test displays a high definition picture you can examine for flaws or faults. If the test picture does not appear or there is noise or distortion, the TV may have a problem. Contact Samsung’s Call Center for assistance. If the test picture is displayed properly, there may be a problem with an external device.
  • Page 34 4. Troubleshooting The Problem Try this! Store displays are all tuned to digital, HD (high definition) channels. If you have an analog cable/set top box, upgrade to a digital set top box. Use HDMI or Component cables to deliver HD (high definition) picture quality. Many HD channels are upscaled from SD (Standard Definition) content.

  • Page 35: Testing The Sound

    If the TV does not play sound during the Sound Test, or the sound is distorted, there may be a problem with the TV. Contact Samsung’s Call Center for assistance. If the TV plays the Sound Test melody without distortion, there may be a problem with an external device.

  • Page 36: There Is A Problem With The Broadcast

    4. Troubleshooting 4-1-3. There is a problem with the broadcast The Problem Try this! If your TV is not connected to a cable box or satellite box: • Confirm that the coaxial cable is securely connected to the TV. The TV is not receiving all •...

  • Page 37: My File Won't Play

    Reset Settings > Reset settings, except for the network settings, default settings. Resets all Smart Hub settings to their factory defaults and deletes all information related to Samsung accounts, linked Resetting Smart MENU > Smart Hub >Smart Hub Reset service accounts, Smart Hub service agreements, and Smart...

  • Page 38: Other Issues

    4. Troubleshooting 4-1-9. Other Issues The Problem Try this! Watching TV for an extended period of time causes the panel to generate heat. The heat from the panel is dissipated through internal vents running along the top of The TV is hot. the TV.

  • Page 39: Connect

    4. Troubleshooting 4-2. Connect...
  • Page 40 4. Troubleshooting...

  • Page 41: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". UN58J5190AFXZA „ Inches 58" Vendor PANEL Code BN95-01724A Spec.

  • Page 42: Entering Factory Mode

    4. Troubleshooting 4-3-2. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you have Factory remote control INFO Factory If you don’t have Factory remote control, can’t control some menus. T-NT14MAKUC-xxxx Option T-NT14MAKUSS-xxxx Control...

  • Page 43: Factory Data

    4. Troubleshooting 4-3-3. Factory Data Option „ Factory Menu Name Data Range Factory Reset Type 58D6AF0S Local Set Model UJ5190 SVC Model 5190 TUNER S_TC Ch Table NONE MRT Option Front Color U-S-C-53 Lvds Format JEIDA Language_Arabic Region PnP Language Local WIFI REGION OTN Support...
  • Page 44 4. Troubleshooting Factory Menu Name Data Range BD Wise Support OFF(H6203 ON) Data Service Support PVR Support CI Support LEDMotionPlus Support Natual Mode Support Relax Mode Support HDMI/DVI SEL Select LED/PDP Wall Mount HV Flip HV Filp FRC HV Flip Light Effect e-Pop Default CAMERA Support...
  • Page 45 4. Troubleshooting Factory Menu Name Data Range PH RATE PD EN PEQ Inx WF Scale WF Type Num of Network Stream DP V Size Backend Device BT_AUDIO_ON_OFF Config_AV_PATH USING_PSI_UPDATE ECO Stanby Fast Logo Delay Num of PANEL KEY Panel Detail Panel Init Time Tcon Init Time WRITE MAC Address...
  • Page 46 4. Troubleshooting Factory Menu Name Data Range FRC Monitoring Checksum 0x0000 Fast Boot in Production UART ENABLE ECO IC TYPE MC8121 Info Link Server Type development Info Link Country None TTX Group … Visual Test … MediaPlay DB … OPTION_SWU OPTION_NUM RF Remocon Support CCD mode...
  • Page 47 4. Troubleshooting Factory Menu Name Data Range Panel Temperature LOGIC Waveform Day Logic Check Sum SAPC Timer APC Speed Hotel Option Hospitality Mode Power On Menu OSD Operation Music Mode External Source Eco Solution Cloning Shop Option Shop Mode Exhibition Mode 3D Cube Asia Option Unbalance...
  • Page 48 4. Troubleshooting Factory Menu Name Data Range A2Ident Low Thid Pilot Level High Thld 0x0Fh Pilot Level Low Thld 0x08h Carrier2 Amp High Thld Carrier2 Amp Low Thld Carrier2 SNR High THR Carrier2 SNR Low THR Sig Error On Sig Error Off Amp Model TAS5745 Amp Volume...
  • Page 49 4. Troubleshooting Factory Menu Name Data Range LVDS Spread DDR Spread Period Amplitude HD SSC ON/Off HD SSC Value LVDS SSC ON/OFF LVDS Value DDR SSC ON/OFF DDR SSC Value FRC Vx1 SSC ON/OFF FRC LVDS SSC ON/OFF FRC LVDS SSC MRR FRC LVDS SSC MFR FRC Vx1 SSC Period FRC Vx1 SSC Modulation...
  • Page 50 4. Troubleshooting Factory Menu Name Data Range 0x3447 DCC VERSION DCC CHK SEL DCC CHECK LOCAL DCC CHECK TOTAL MultiACC Checksum IIC Bus Stop Tuner Status SHOW Cert Option RM_BIST_DTV RM_BIST_ATV Voice Debug „ Factory Menu Name Data Range Self Test(for HW) Loop Back FLASH EEPROM...
  • Page 51 4. Troubleshooting Factory Menu Name Data Range DTV CH Inspection Satellite CH Inspection Woofer Sound Inspection DP Test DP CRC Result Voltage Result Chip Test Module Test ATV CH Inspection DTV CH Inspection Satellite CH Inspection UHD OSD TEST Aging Line Test Tweeter Sound Inspection Info SVC Info...
  • Page 52 4. Troubleshooting Factory Menu Name Data Range IR Blaster Upgrade IR Blaster delay time CPLD Download LDC PROFILE UPGRADE Pic Data USB Update Audio Data USB Update Eco Data USB Upate SC ADK Upgrade SC MBR Upgrade Reset App Reset EEPROM Rst SPI Flash Reset Failure...
  • Page 53 4. Troubleshooting Factory Menu Name Data Range TS Clock delay S CI Control Buf ON TS Clock delay CPU Test Pattern Pattern Sel Logic Pattern Sel Logic Level Sel FRC Pre Test Pattern FRC Post Test Pattern SOC TCON Test Pattern SOC TCON Pattern Level SOC TCON FRC Pattern HDMI WB Pattern...
  • Page 54 4. Troubleshooting Factory Menu Name Data Range 1st_Y_GH 1st_Y_GL 1st_Cb_BH 1st_Cb_BL 1st_Cr_RH 1st_Cr_RL 2nd_R_L 2nd_G_L 2nd_B_L 2nd_R_H 2nd_G_H 2nd_B_H White Balance R-Offset G-Offset B-Offset R-Gain G-Gain B-Gain WB-W2_R_Offset WB_W2_B_Offset WB_W2_R_Gain WB_W2_B_Gain WB-N_R_Offset WB_W2_N_Offset WB_W2_N_Gain WB_W2_N_Gain MGA On/Off R1_Gain G1_Gain B1_Gain R2_Gain G2_Gain B2_Gain...
  • Page 55 4. Troubleshooting Factory Menu Name Data Range R4_Gain G4_Gain B4_Gain R5_Gain G5_Gain B5_Gain R6_Gain G6_Gain B6_Gain R7_Gain G7_Gain B7_Gain R8_Gain G8_Gain B8_Gain R9_Gain G9_Gain B9_Gain R10_Gain G10_Gain B10_Gain Advanced „ 4-23...

  • Page 56: White Balance

    4. Troubleshooting 4-4. White Balance 4-4-1. Calibration Into the Factory Mode. Select Menu. ADC/WB Select menu. Select menu. Option Control Debug AV Calibration ADC/WB Comp Calibration Advanced HDMI Calibration 4-4-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „...
  • Page 57 4. Troubleshooting Method of Color Calibration (AV) „ Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port. Press the Source key to switch to “AV1” mode. Enter Service mode. Select the “ADC” menu. Select the “AV Calibration” menu. In “AV Calibration Off”...

  • Page 58: Adjustment

    4. Troubleshooting 4-4-3. Adjustment Into the Factory Mode. Select Menu. ADC/WB Select menu. Select menu. Option Control Debug (Low light) (High light) Sub Bright Sub Contrast White Balance ADC/WB R offset R gain Advanced G offset G gain B offset B gain 4-26...

  • Page 59: Software Upgrade

    4-5. Software Upgrade Samsung may offer upgrades for the TV’s firmware in the future. These upgrades can be performed via the TV when it is connected to the Internet, or by downloading the new firmware from samsung.com to a USB memory device.

  • Page 60: The Dimension Of J5190 Models

    4. Troubleshooting 4-6. The Dimension of J5190 Models 454.0 400.0 182.5 400.0 136.9 44.9 133.7 40.9 263.4 263.8 181.6 263.0 341.9 312.1 4-28...
  • Page 61 TV. The Picture Test displays a high definition picture you can examine for flaws or faults. If the test picture does not appear or there is noise or distortion, the TV may have a problem. Contact Samsung’s Call Center for assistance. If the test picture is displayed properly, there may be a problem with an external device.
  • Page 62 4. Troubleshooting The Problem Try this! Store displays are all tuned to digital, HD (high definition) channels. If you have an analog cable/set top box, upgrade to a digital set top box. Use HDMI or Component cables to deliver HD (high definition) picture quality. Many HD channels are upscaled from SD (Standard Definition) content.
  • Page 63 If the TV does not play sound during the Sound Test, or the sound is distorted, there may be a problem with the TV. Contact Samsung’s Call Center for assistance. If the TV plays the Sound Test melody without distortion, there may be a problem with an external device.
  • Page 64 4. Troubleshooting 4-1-3. There is a problem with the broadcast The Problem Try this! If your TV is not connected to a cable box or satellite box: • Confirm that the coaxial cable is securely connected to the TV. The TV is not receiving all •...
  • Page 65 Reset Settings > Reset settings, except for the network settings, default settings. Resets all Smart Hub settings to their factory defaults and deletes all information related to Samsung accounts, linked Resetting Smart MENU > Smart Hub >Smart Hub Reset service accounts, Smart Hub service agreements, and Smart...
  • Page 66 4. Troubleshooting 4-1-9. Other Issues The Problem Try this! Watching TV for an extended period of time causes the panel to generate heat. The heat from the panel is dissipated through internal vents running along the top of The TV is hot. the TV.
  • Page 67 4. Troubleshooting 4-2. Connect...
  • Page 68 4. Troubleshooting...
  • Page 69 4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". UN58J5190BFXZA „ 58" Inches DA01 Vendor PANEL Code BN95-01724A...
  • Page 70 4. Troubleshooting 4-3-2. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you have Factory remote control INFO Factory If you don’t have Factory remote control, can’t control some menus. T-NT14MAKUC-xxxx Option T-NT14MAKUSS-xxxx Control...
  • Page 71 4. Troubleshooting 4-3-3. Factory Data Option „ Factory Menu Name Data Range Factory Reset Type 58D6AF0S Local Set Model UJ5190 SVC Model 5190 TUNER ATSC / Clear QAM) S_TC ( Ch Table NONE MRT Option Front Color U-S-C-53 Lvds Format JEIDA Language_Arabic Region...
  • Page 72 4. Troubleshooting Factory Menu Name Data Range BD Wise Support OFF(H6203 ON) Data Service Support PVR Support CI Support LEDMotionPlus Support Natual Mode Support Relax Mode Support HDMI/DVI SEL Select LED/PDP Wall Mount HV Flip HV Filp FRC HV Flip Light Effect e-Pop Default CAMERA Support...
  • Page 73 4. Troubleshooting Factory Menu Name Data Range PH RATE PD EN PEQ Inx WF Scale WF Type Num of Network Stream DP V Size Backend Device BT_AUDIO_ON_OFF Config_AV_PATH USING_PSI_UPDATE ECO Stanby Fast Logo Delay Num of PANEL KEY Panel Detail Panel Init Time Tcon Init Time WRITE MAC Address...
  • Page 74 4. Troubleshooting Factory Menu Name Data Range FRC Monitoring Checksum 0x0000 Fast Boot in Production UART ENABLE ECO IC TYPE MC8121 Info Link Server Type development Info Link Country None TTX Group … Visual Test … MediaPlay DB … OPTION_SWU OPTION_NUM RF Remocon Support CCD mode...
  • Page 75 4. Troubleshooting Factory Menu Name Data Range Panel Temperature LOGIC Waveform Day Logic Check Sum SAPC Timer APC Speed Hotel Option Hospitality Mode Power On Menu OSD Operation Music Mode External Source Eco Solution Cloning Shop Option Shop Mode Exhibition Mode 3D Cube Asia Option Unbalance...
  • Page 76 4. Troubleshooting Factory Menu Name Data Range A2Ident Low Thid Pilot Level High Thld 0x0Fh Pilot Level Low Thld 0x08h Carrier2 Amp High Thld Carrier2 Amp Low Thld Carrier2 SNR High THR Carrier2 SNR Low THR Sig Error On Sig Error Off Amp Model TAS5745 Amp Volume...
  • Page 77 4. Troubleshooting Factory Menu Name Data Range LVDS Spread DDR Spread Period Amplitude HD SSC ON/Off HD SSC Value LVDS SSC ON/OFF LVDS Value DDR SSC ON/OFF DDR SSC Value FRC Vx1 SSC ON/OFF FRC LVDS SSC ON/OFF FRC LVDS SSC MRR FRC LVDS SSC MFR FRC Vx1 SSC Period FRC Vx1 SSC Modulation...
  • Page 78 4. Troubleshooting Factory Menu Name Data Range 0x3447 DCC VERSION DCC CHK SEL DCC CHECK LOCAL DCC CHECK TOTAL MultiACC Checksum IIC Bus Stop Tuner Status SHOW Cert Option RM_BIST_DTV RM_BIST_ATV Voice Debug „ Factory Menu Name Data Range Self Test(for HW) Loop Back FLASH EEPROM...
  • Page 79 4. Troubleshooting Factory Menu Name Data Range DTV CH Inspection Satellite CH Inspection Woofer Sound Inspection DP Test DP CRC Result Voltage Result Chip Test Module Test ATV CH Inspection DTV CH Inspection Satellite CH Inspection UHD OSD TEST Aging Line Test Tweeter Sound Inspection Info SVC Info...
  • Page 80 4. Troubleshooting Factory Menu Name Data Range IR Blaster Upgrade IR Blaster delay time CPLD Download LDC PROFILE UPGRADE Pic Data USB Update Audio Data USB Update Eco Data USB Upate SC ADK Upgrade SC MBR Upgrade Reset App Reset EEPROM Rst SPI Flash Reset Failure...
  • Page 81 4. Troubleshooting Factory Menu Name Data Range TS Clock delay S CI Control Buf ON TS Clock delay CPU Test Pattern Pattern Sel Logic Pattern Sel Logic Level Sel FRC Pre Test Pattern FRC Post Test Pattern SOC TCON Test Pattern SOC TCON Pattern Level SOC TCON FRC Pattern HDMI WB Pattern...
  • Page 82 4. Troubleshooting Factory Menu Name Data Range 1st_Y_GH 1st_Y_GL 1st_Cb_BH 1st_Cb_BL 1st_Cr_RH 1st_Cr_RL 2nd_R_L 2nd_G_L 2nd_B_L 2nd_R_H 2nd_G_H 2nd_B_H White Balance R-Offset G-Offset B-Offset R-Gain G-Gain B-Gain WB-W2_R_Offset WB_W2_B_Offset WB_W2_R_Gain WB_W2_B_Gain WB-N_R_Offset WB_W2_N_Offset WB_W2_N_Gain WB_W2_N_Gain MGA On/Off R1_Gain G1_Gain B1_Gain R2_Gain G2_Gain B2_Gain...
  • Page 83 4. Troubleshooting Factory Menu Name Data Range R4_Gain G4_Gain B4_Gain R5_Gain G5_Gain B5_Gain R6_Gain G6_Gain B6_Gain R7_Gain G7_Gain B7_Gain R8_Gain G8_Gain B8_Gain R9_Gain G9_Gain B9_Gain R10_Gain G10_Gain B10_Gain Advanced „ 4-23...
  • Page 84 4. Troubleshooting 4-4. White Balance 4-4-1. Calibration Into the Factory Mode. Select Menu. ADC/WB Select menu. Select menu. Option Control Debug AV Calibration ADC/WB Comp Calibration Advanced HDMI Calibration 4-4-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „...
  • Page 85 4. Troubleshooting Method of Color Calibration (AV) „ Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port. Press the Source key to switch to “AV1” mode. Enter Service mode. Select the “ADC” menu. Select the “AV Calibration” menu. In “AV Calibration Off”...
  • Page 86 4. Troubleshooting 4-4-3. Adjustment Into the Factory Mode. Select Menu. ADC/WB Select menu. Select menu. Option Control Debug (Low light) (High light) Sub Bright Sub Contrast White Balance ADC/WB R offset R gain Advanced G offset G gain B offset B gain 4-26...
  • Page 87 4-5. Software Upgrade Samsung may offer upgrades for the TV’s firmware in the future. These upgrades can be performed via the TV when it is connected to the Internet, or by downloading the new firmware from samsung.com to a USB memory device.
  • Page 88 4. Troubleshooting 4-6. The Dimension of J5190 Models 454.0 400.0 182.5 400.0 136.9 44.9 133.7 40.9 263.4 263.8 181.6 263.0 341.9 312.1 4-28...

  • Page 89: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram IP Board CNM803 CNL802 CN201 CN1401_FHD CN120 CN302 Function Speaker Speaker Speaker Speaker T-CON Wifi...

  • Page 90: Connector

    5. Wiring Diagram 5-2. Connector Main Board „ 4 CN1501 8 CN201 12 CN304 13 CN2402_IRB 5 CN1502 9 CN601 1 CN1401_FHD 3 CN401 10 CN602 6 CN1402 11 CN502 7 CN1201 2 CN302 CN1401_FHD CN1401_FHD ODD_TX3+ ODD_TX0- EVEN_TX3+ ODD_TX3- EVEN_TX3- FRC_SDA ODD_TXCLK+...
  • Page 91 5. Wiring Diagram CN302 (to Speaker) CN601 (to HDMI1) HDMI1_RX2+ HDMI1_RXCLK- HDMI1_RX2- CN401_OPT (to Optical Jack) HDMI1_RX1+ SPDIF_OUT HDMI1_SCL_DDC B5V_DC_PW HDMI1_RX1- HDMI1_SDA_DDC CN1501 (USB1) HDMI1_RX0+ B5V_USB1_PW USB1_DP HDMI1_5V USB1_DM HDMI1_RX0- HDMI1_HOT_PLUG HDMI1_RXCLK+ CN1502 (USB2) B5V_USB2_PW USB2_DP CN602 (to HDMI2) USB2_DM HDMI2_RX2+ HDMI2_RXCLK- CN1402 (to LAN)

  • Page 92: Connector Functions

    5. Wiring Diagram 5-3. Connector Functions Connector Function Supply main power and dimming signal from IP Board to Main Board. CN201  CNM803 The LVDS signal transfered from Main Board to Panel. CN1401  CON3...

  • Page 93: Cables

    5. Wiring Diagram 5-4. Cables Model Main-SMPS (18P-10P) Main-Tcon Code UN58J5190 BN39-01889K BN96-33236H Image Model Main-Function/WiFi Module Code UN58J5190 BN39-01903N Image...

  • Page 94: The Types Of Module

    5. Wiring Diagram 5-5. The Types of Module Function module Wifi module Code No. BN59-01174A BN96-30902X Standard IEEE802.11abgn Image...
  • Page 95 ANNEX. Exploded View & Part List ANNEX. Exploded View & Part List [UN58J5190AFXZA IS01] 1-1. Exploded View 1-1-1. Parts List Code No. Description & Specification Q’ty SA/SNA Remark BN95-01724A PRODUCT LCD-INX; v580HJ1,CY-HH058BGNV1H/V BN96-33358A ASSY CHASSIS TOP P; Y14 F-LED 58,PC+ABS+G BN96-30902X ASSY BOARD P-FUNCTION;...
  • Page 96 ANNEX. Exploded View & Part List 2-1. Electrical Parts List Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE) Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark UN58J5190AFXZA (IS01) BN90-05304X ASSY W/I;UN40F6400AFXZA BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC BN81-09500R PART SET-MECH W/I;UH5H,U58HF* S001A BN90-06123A...
  • Page 97 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 BN63-12638A SHEET-COMPLEX;MEGA 58inch G230-54,PET,0..4 BN63-12640A SHEET-REFLECTOR;MEGA 58inch UXJP175,PET, ...4 BN96-32771A ASSY LED BAR P;58inch Left,Direct LED PK ...4 BN96-32772A ASSY LED BAR P;58inch Right,Direct LED P ...4 BN96-33354A ASSY CHASSIS BOTTOM P;Y14 F-LED 58,MEGA,...
  • Page 98 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark EC13 BN39-01889K LEAD CONNECTOR;UE50H6300,Flat Connector, BN39-01903N LEAD CONNECTOR-FUNCTION;58H5203,Lead Con P001A BN44-00787A DC VSS-LED TV PD BD;L58GFB_ESM,L58GFB_ES WIFI BN59-01174A NETWORK-WIFI MODULE;WIDT-30Q,Internal Wi HOLDER- BN61-09175B SCREW-MACHINE;BH,+,M3,L10,ZPC(WHT),SWRCH LED SCREW BN62-00670A...
  • Page 99 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 1203-008118 IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9 ...4 1204-003558 IC-VIDEO PROCESS;SENK15,HS-TFBGA,626P,26 ...4 1205-004447 IC-SWITCH;TPS2051CDBVR,SOT23-5,5P,3x1.65 ...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4..4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5mm,TP,100V, ...4 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 ...4 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 ...4 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005...
  • Page 100 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 ...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4Points,TP,10 ...4 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 ...4 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, ...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP ...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 ...4 AD480 2203-000330...
  • Page 101 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,5050,0.072Ohm,245 ...4 2703-004145 INDUCTOR-SMD;2.2uH,20%,6.5 x 6.9mm,0.20o ...4 2703-004462 INDUCTOR-SMD;3.3uH,20%,10x10x8mm,0.0082O ...4 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh ...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz ...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, ...4 3301-002039 BEAD-SMD;26ohm,1608,TP ...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL...
  • Page 102 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark HOLDER- BN61-08370A HOLDER-WIRE STAND;26UE4000 GUIDE STAND,P WIRE BN68-04972A MANUAL FLYER-12,REGULATORY GUI;ALL,SAMSU BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,0.2,20,7 BN68-07181P MANUAL USERS-01;J5202,United States,W/P* BN92-19443X ASSY BOX;LED TV BH68-00697A LABEL BOX-00;ALL MODEL,ART PAPER 90G,60, BN69-11019N BOX UNIT;58J5190-SS,CB,A-01,DW3,W1555,D1...

  • Page 103: Annex. Exploded View & Part List [Un58J5190Bfxza Da01]

    ANNEX. Exploded View & Part List ANNEX. Exploded View & Part List [UN58J5190BFXZA DA01] 1-1. Exploded View 1-1-1. Parts List Code No. Description & Specification Q’ty SA/SNA Remark BN95-01724A PRODUCT LCD-INX; v580HJ1,CY-HH058BGNV1H/V BN96-33358A ASSY CHASSIS FRONT P; Y14 F-LED 58,PC+ABS BN96-30902X ASSY BOARD P-FUNCTION JOG;...
  • Page 104 ANNEX. Exploded View & Part List 2-1. Electrical Parts List Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE) Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark UN58J5190BFXZA (DA01) BN90-05304X ASSY W/I;UN40F6400AFXZA BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C BN81-09500R A/S PART SET-MECH W/I;UH5H,U58HF* S001A...
  • Page 105 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 BN63-12640A OPTICAL SHEET-REFLECTOR;14Y_H5K 58inch_U ...4 BN96-32771A ASSY LED BAR P;58inch Left,CEM3,White LE ...4 BN96-32772A ASSY LED BAR P;58inch Right,CEM3,White L ...4 BN96-33354A ASSY CHASSIS REAR P;Y14 F-LED 58,EGI-SEC ..5 AK63-00675A...
  • Page 106 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark BN39-01903N LEAD CONNECTOR-SUB ASSY;58H5203,UL21016, P001A BN44-00787A DC VSS-PD BOARD;L58GFB_ESM,AC/DC,166W,10 WIFI BN59-01174A NETWORK-WLAN CLIENT;WIDT30Q,58x31.45x8.5 HOLDER- BN61-09175B SCREW-MACHINE;BH,+,M3,L10,ZPC(WHT),SWRCH LED SCREW BN62-00670A INSULATOR-TAPE;H5203,PET,BLACK,L54,W54,T M0131 BN63-00520A GASKET-EMI;APPOLO_PAL,Conductive Fabric, M0131 BN63-00985A GASKET-EMI;DS15AS,Conductive Fabric,T1.5...
  • Page 107 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 1204-003558 IC-VIDEO PROCESS;SENK15,HS-TFBGA,626P,26 ...4 1205-004447 IC-SWITCH;TPS2051CDBVR,SOT23-5,5P,3x1.65 ...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4..4 1405-001271 VARISTOR;35V,20VDC,5A,1005,TP,100V,10pF ...4 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 ...4 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 ...4 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 ...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 ...4...
  • Page 108 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1.0x1.0 ...4 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 ...4 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, ...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP,4P,TP,1 ...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 ...4 AD480 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1005 ...4 AD480...
  • Page 109 TAPE-SINGLE FACE;OPP,T0.05,W75,L800M,CLE BN68-02422B LABEL WARNING;ALL,ART PAPER,T0.05,W240,L BN69-09624A CUSHION-SET FRONT;UH6300-60,EPS,16.7g/l, BN69-10618A CUSHION-SET;UH5200 58",EPS,16.7g/l,WHT,O BN69-12806A PACKING ANGLE;ALL,PAPER ACCE1 BN92-17477P ASSY ACCESSORY;LED_J6K BN96-38848Z ASSY ACCESSORY-MANUAL CABLE;UN58J5190AFX T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.2x4 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP BN59-01199F REMOCON-TV;2014 TV,Samsung,44KEY,3V,AMER HOLDER- BN61-08370A HOLDER-STAND CABLE;26UE4000,PA66,MOLD WIRE ANNEX-7...
  • Page 110 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark BN68-04972A LEAFLET-REGULATORY GUIDE;ALL,SAMSUNG,ENG BN68-05723A LABEL ETC;ALL,YUPO,T0.2,W20,L70 BN68-07181P MANUAL USERS;J5202,United States,W/P* BN92-19443X ASSY BOX;LED TV BH68-00697A LABEL BOX;ALL,ART PAPER,W60,L100,WHT,NO BN69-14791B BOX UNIT;58J5190,CB,SW2,F1,L1555,W160,H8 ANNEX-8...

  • Page 111: Exploded View

    Exploded Views and Parts List 1. Exploded View & Part List Exploded View Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 112: Parts List

    BN94-10553A ASSY PCB MAIN; UN58J5190AFXZA BN61-11153A HOLDER-SIDE AV; UH5203,HIPS,UO R001A BN96-39100A ASSY COVER P-REAR; 58J5202,USA BN61-07962B BRACKET-STNAD LINK; UE6030 55",SECC,T1.6, SG01A BN96-33524A ASSY GUIDE P-STAND; UH5200 58,PC+G/F20%,B SB04A BN96-33225B ASSY STAND P-BASE; UH5200 58",ABS,HB,BLK Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 113: Electrical Parts List

    BN91-12976A ASSY LCM-AMLCD;BN95-01724A,CY-HH058BGNV1 PANEL BN95-01724A PRODUCT LCD-INX;v580HJ1,CY-HH058BGNV1H/V SCREW 6001-002756 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 CB20 BN61-07953A BRACKET-WALL;UE5000 46",EGI-SECC PL,T1.2 BN61-07962B BRACKET-STNAD LINK;UE6030 55",SECC,T1.6, M0131 BN63-00520A GASKET;APPOLO_PAL,Conductive Fabric,0.13 BN68-05595A LABEL-STICKER;Art Paper 100G,T0.2,80mmX2 BN90-05987A ASSY MISC-BLU;MEGA MODEL,CY-HH058BGNV1V Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 114 ...4 BN81-10744A A/S-A/S-IC DRIVER GATE;INX 58 FHD 60Hz,6 ...4 BN81-10745A A/S-A/S-ASSY PCB-SOURCE (XR);INX 58 FHD ...4 BN81-10746A A/S-A/S-ASSY PCB-SOURCE (XL);INX 58 FHD ...4 BN81-10747A A/S-A/S-POLARIZER-C/F;INX 58 FHD 60Hz,41 ...4 BN81-10748A A/S-A/S-POLARIZER-TFT;INX 58 FHD 60Hz,41 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 115 ASSY DRM-KEY;HU7*,NT14U,US ...4 BN46-00109H KEY CODE-CERTIFI;MAC,TV/AV,General ...4 BN46-00110P KEY CODE-CERTIFI;MIRACAST(HDCP2.2), TV BN97-10423A ASSY SMD;LED TV ...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn ...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO ...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, ...4 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 ...4 0406-001628 DIODE-TVS;AOZ8804ADI,6/-/-V,150W,SLP2510 ...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 116 R-CHIP;10Kohm,5%,1/16W,TP,1005 ...4 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 ...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 ...4 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 ...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 ...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 ...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 ...4 2007-000256 R-CHIP;1.6Kohm,1%,1/10W,TP,1608 ...4 2007-000265 R-CHIP;1.8Kohm,1%,1/10W,TP,1608 ...4 2007-000583 R-CHIP;22Kohm,1%,1/10W,TP,1608 ...4 2007-000691 R-CHIP;3.3Mohm,5%,1/10W,TP,1608 ...4 2007-000726 R-CHIP;300ohm,1%,1/10W,TP,1608 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 117 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 ...4 AD480 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 ...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 ...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 118 2703-000213 INDUCTOR-SMD;470nH,10%,1608,1.35Ohm,35mA ...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 ...4 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366,0.015ohm,700 ...4 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080,0.025ohm,450 ...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,5050,0.072Ohm,245 ...4 2703-004145 INDUCTOR-SMD;2.2uH,20%,6.5 x 6.9mm,0.20o ...4 2703-004462 INDUCTOR-SMD;3.3uH,20%,10x10x8mm,0.0082O ...4 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh ...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz ...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, ...4 3301-002039 BEAD-SMD;26ohm,1608,TP Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 119 LEAFLET-QSG;J5202,United States,ART*,62. BN68-07705H LABEL-ENERGY;UN58J5190AFXZA,PET,T0.1,38, BN74-00053G TAPE-PAPER;PAPER,3M2307,0.14T,W10,60M,WH T0527 BP68-00052B LABEL-00,RATING;FPTV,PET,T0.05,93,73 ACCE1 BN92-17477P ASSY ACCESSORY;LED_J6K BN96-38848Z ASSY ACCESSORY MANUAL/CABLE;LED TV T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.2x4 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP BN59-01199F REMOCON-REMOCON;TM1240A,44,3.0V,TM1240A_ HOLDER-WIRE BN61-08370A HOLDER-WIRE STAND;26UE4000 GUIDE STAND,P Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 120 Exploded Views and Parts List Level Loc. Part Code Description & Specification Qty. SA/SNA BN68-04972A MANUAL FLYER-12,REGULATORY GUI;ALL,SAMSU BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,0.2,20,7 BN68-07181P MANUAL USERS-01;J5202,United States,W/P* BN92-19443X ASSY BOX;LED TV BH68-00697A LABEL BOX-00;ALL MODEL,ART PAPER 90G,60, BN69-11019N BOX UNIT;58J5190-SS,CB,A-01,DW3,W1555,D1 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 121 Exploded Views and Parts List 1. Exploded View & Part List Exploded View Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 122 ASSY PCB MAIN; LED TV BN61-11153A COVER-TERMINAL SIDE; HIPS,HIPS,MOLD,BLACK R001A BN96-39100A ASSY COVER P-REAR; USA CB18 BN61-07962B BRACKET-STAND LINK; SECC,T1.6,NATURAL,60H SG01A BN96-33524A ASSY GUIDE P-STAND; UH5200 58,PC+GF20%,BK SB04A BN96-33225B ASSY STAND P-BOTTOM; UH5200 58",ABS,BLACK Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 123 PRODUCT LCD-INX;v580HJ1,CY-HH058BGNV1H/V SCREW 6001-002756 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 CB20 BN61-07953A BRACKET-WALL;EGI-SECC PL,T1.2,NATURAL CB18 BN61-07962B BRACKET-STAND LINK;SECC,T1.6,NATURAL,60H M0131 BN63-00520A GASKET-EMI;APPOLO_PAL,Conductive Fabric, BN68-05595A LABEL ETC;UF6P,ART PAPER,T0.08,W80,L23,W BN90-05987A ASSY MISC-BLU;MEGA MODEL,CY-HH058BGNV1V ...4 BN02-00043C TAPE SINGLE FACE;F-LED 32/40/47",PET,T0. Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 124 A/S-IC DRIVER SOURCE;V580HJ1-PE6,6101B00 ...4 BN81-10744A A/S-IC DRIVER GATE;V580HJ1-PE6,6101B000C ...4 BN81-10745A A/S-ASSY PCB SOURCE RIGHT;V580HJ1-PE6,6B ...4 BN81-10746A A/S-ASSY PCB SOURCE LEFT;V580HJ1-PE6,6B0 ...4 BN81-10747A A/S-POLARIZER CF;V580HJ1-PE6,4101B002MS0 ...4 BN81-10748A A/S-POLARIZER TFT;V580HJ1-PE6,4101B002M9 TCON BN96-32745A ASSY T CON P;V580HJ1-PE6,V580HJ1-PE6,10, Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 125 ...4 BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,General ...4 BN46-00110P KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) BN97-10423A ASSY SMD;LED TV ...4 0202-001976 SOLDER-CREAM;LST-309M-K21,D20~38um,96.5S ...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300mW,SO ...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, ...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP ...4 0406-001628 DIODE-TVS;AOZ8804ADI,6V,1MAV,5A,TP ...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 ...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 126 R-CHIP;22Kohm,5%,1/16W,TP,1005 ...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 ...4 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 ...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 ...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 ...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 ...4 2007-000256 R-CHIP;1.6Kohm,1%,1/10W,TP,1608 ...4 2007-000265 R-CHIP;1.8Kohm,1%,1/10W,TP,1608 ...4 2007-000583 R-CHIP;22Kohm,1%,1/10W,TP,1608 ...4 2007-000691 R-CHIP;3.3Mohm,5%,1/10W,TP,1608 ...4 2007-000726 R-CHIP;300ohm,1%,1/10W,TP,1608 ...4 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 127 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 ...4 AD480 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 ...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 ...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,TP,1005 Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 128 ...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 ...4 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366,0.015Ohm,700 ...4 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080,0.025Ohm,450 ...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,0.072Ohm,2450mA,W ...4 2703-004145 INDUCTOR-SMD;2.2uH,20%,0.2Ohm,900mA,Wire ...4 2703-004462 INDUCTOR-SMD;3.3uH,20%,0.0082Ohm,7500mA, ...4 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50Oh ...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz ...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, ...4 3301-002039 BEAD-SMD;26ohm,1608,TP ...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 129 CUSHION-SET FRONT;UH6300-60,EPS,16.7g/l, BN69-10618A CUSHION-SET;UH5200 58",EPS,16.7g/l,WHT,O BN69-12806A PACKING ANGLE;ALL,PAPER ACCE1 BN92-17477P ASSY ACCESSORY;LED_J6K BN96-38848Z ASSY ACCESSORY-MANUAL CABLE;UN58J5190AFX T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.2x4 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP BN59-01199F REMOCON-TV;2014 TV,Samsung,44KEY,3V,AMER HOLDER-WIRE BN61-08370A HOLDER-STAND CABLE;26UE4000,PA66,MOLD BN68-04972A LEAFLET-REGULATORY GUIDE;ALL,SAMSUNG,ENG Copyright© 1995-2016 SAMSUNG. All rights reserved.
  • Page 130 Exploded Views and Parts List Level Loc. Part Code Description & Specification Qty. SA/SNA BN68-05723A LABEL ETC;ALL,YUPO,T0.2,W20,L70 BN68-07181P MANUAL USERS;J5202,United States,W/P* BN92-19443X ASSY BOX;LED TV BH68-00697A LABEL BOX;ALL,ART PAPER,W60,L100,WHT,NO BN69-14791B BOX UNIT;58J5190,CB,SW2,F1,L1555,W160,H8 Copyright© 1995-2016 SAMSUNG. All rights reserved.
