Samsung UE D65 V Series Service Manual page 110

Level Loc. Part Code
...4 DR32 3301-000314
...4 T0568 3301-001236
...4 T0568 3301-002039
...4 F201 3601-001374
...4 CN401 3701-001724
...4 CN601 3701-001736
...4 CN303 3707-001104
...4 CN1601 3708-002909
...4 3710-002276
...4 3710-003374
...4 HB01A 3711-005509
...4 HB01A 3711-007319
...4 3711-007571
...4 EH01 3711-007742
...4 CN1501 3722-003044
...4 CN302 3722-003158
...4 CN1701 3722-003199
...4 CN501 3722-003207
...4 BN13-00042A
...4 ET01 BN40-00217A
...4 BN41-01587D
...4 BN97-05307A
....5 1301-001969
...4 BN97-05336A
....5 1107-001983
...4 BN97-05337A
....5 1107-001990
...4 BN97-05512A
....5 0903-001718
1 BN92-07567C
.2 BH68-00662A
.2 BN69-06007E
1 BN92-07932A
.2 6902-000379
.2 M040 6922-000003
.2 BN68-02422B
.2 BN69-00257Y
.2 BN69-03982F
.2 BN69-05184L
.2 BN69-05418A
Copyright© 1995-2011 SAMSUNG. All rights reserved.
Description & Specification
BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,-
BEAD-SMD;60ohm,1608
BEAD-SMD;26ohm,1608,TP
FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,Hi
CONNECTOR-DSUB;15P,3ROW,FEMALE,ANGLE,NI
CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-A
CONNECTOR-OPTICAL;SMD-A(Ultra Slim),SPDI
CONNECTOR-FPC/FFC/PIC;82P,0.5mm,SMD-S,AU
SOCKET-INTERFACE;24P,1R,0.5mm,SMD-A,AU,B
CONNECTOR-SOCKET;64P,2R,0.5mm,ANGLE,NI+S
HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S
HEADER-BOARD TO CABLE;SMD,4P,1R,2.50mm,S
CONNECTOR-HEADER;BOX,18P,2R,2.0mm,ANGLE,
HEADER-BOARD TO CABLE;BOX,20P,2R,2mm,ANG
JACK-USB;4P/1C,NI,BLK,SMD-A,A-TYPE
JACK-PHONE;1/6P,NI,BLK,ANGLE
JACK-MODULAR;8P/8C,ANGLE,AU,1P
JACK-PHONE;2P/9C,AU,LIMEGRN,SMD-A(DIP)
IC ASIC;SDP1005,PARMA,404P,3.3V,-25to+85
TUNER;DNSS243VH142A,DNSS243VH142A,DVB-TC
PCB MAIN;Genoa-S, LED6,FR-4,4,B,1.2T,192
ASSY MICOM;T-GAPACPLD-XXXX,U63A,2010-11-
IC-CPLD;EPM240T100C4N,TQFP,100P,16x16mm,
ASSY MICOM;T-GASDEUC-1006.0,2011.04.05
IC-NAND FLASH;SDIN5D2-2G-944D,2GByte,BGA
ASSY MICOM;T-GASDEUC-XXXX,U69A,2010.11.2
IC-NAND FLASH;KFG1GN6W2D-HIB6,1Gbit,64Mx
ASSY MICOM;T-GENDEUS1-XXXX,U69A, U68A,20
IC-MICROCONTROLLER;61P805-RG480WT,LQFP,4
ASSY BOX;UD6500 46
LABEL BOX-00;ALL MODEL,MOJO 90G,60,110,W
BOX-SET;46UD6500-GS,CB,A-01,DW3,ECT60,YE
ASSY P/MATERIAL;UD6500 46
BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0
BAND PP;PP,T0.8,W18,L1650M,TRP,DA69-9014
LABEL-WARNING SHIPPING;ALL MODEL,A/P 100
PACKING-SHEET PALLET;PACKING SHEET PALLE
PAD PACKING-EDGE;LB6T,PAPER,6,120,2160,-
PALLET;UE46D6400,WOOD,1330,1080,135,1750
PACKING-BAG WRAPPING;-,LDPE,-,0,019,500,
Exploded Views and Parts List
Qty. SA/SNA
12 SNA
3 SNA
58 SA
1 SA
1 SA
4 SA
1 SA
1 SA
1 SC
1 SA
1 SA
1 SA
1 SA
1 SA
3 SA
2 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
2 SNA
1 SNA
1 SNA
1 SNA
1 SNA
2410 SNA
11
